A0136 12V 35A Alternator Fits Volvo 142, Volvo 144, Volvo 242
Price range: £150.00 through £240.00
Sahibs A0136 is a replacement alternator with a listed 12V 35A rating. Listed applications include selected Volvo 142, Volvo 144, Volvo 145 Estate/Combi, Volvo 242 models. Identification references include Lucas LRA00136, Bosch 120400604. Its listed 12V 35A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0136 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 35 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 54 mm |
| Mounting holes | 2 qty |
| Position | 20° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.92 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0136 | Dyno Electrics |
| 120400604 | Bosch |
| 120400605 | Bosch |
| 986032870 | Bosch Exchange |
| 1128801BO | WAI |
| 13011R | WAI |
| 241527 | Volvo |
| 243793 | Volvo |
| 5001611 | Volvo |
| 815038035 | PSH |
| LRA00136 | Lucas |
| LRA136 | Lucas |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A2561 | 35A | 55A | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| VOLVO | 142 | 1.8 (1778ccm) Petrol | B18B | 142 | 1966 - 1972 | ||
| VOLVO | 142 | 1.8 (1779ccm) Petrol | B18A | 142 | 1966 - 1968 | ||
| VOLVO | 142 | 2.0 (1986ccm) Petrol | B20A | 142 | 1968 - 1974 | ||
| VOLVO | 142 | 2.0 (1986ccm) Petrol | B20E | 142 | 1968 - 1975 | ||
| VOLVO | 144 | 1.8 (1778ccm) Petrol | B18B | 144 | 1966 - 1972 | ||
| VOLVO | 144 | 1.8 (1779ccm) Petrol | B18A | 144 | 1966 - 1972 | ||
| VOLVO | 144 | 2.0 (1986ccm) Petrol | B20B | 144 | 1968 - 1972 | ||
| VOLVO | 144 | 2.0 (1986ccm) Petrol | B20A | 144 | 1968 - 1974 | ||
| VOLVO | 144 | 2.0 (1986ccm) Petrol | B20E | 144 | 1970 - 1975 | ||
| VOLVO | 144 | 2.0 (1986ccm) Petrol | B20A | 144 | 1971 - 1972 | ||
| VOLVO | 144 | 2.0 (1986ccm) Petrol | B20D | 144 | 1971 - 1972 | ||
| VOLVO | 144 | 2.0 (1986ccm) Petrol | B20A | 144 | 1972 - 1973 | ||
| VOLVO | 144 | 2.0 (1998ccm) Petrol | B20F | 144 | 1972 - 1975 | ||
| VOLVO | 145 Estate/Combi | 1.8 (1778ccm) Petrol | B18B | 145 | 1966 - 1968 | ||
| VOLVO | 145 Estate/Combi | 1.8 (1779ccm) Petrol | B18A | 145 | 1966 - 1968 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1986ccm) Petrol | B20A/B20E | 145 | 1968 - 1974 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1986ccm) Petrol | B20E | 145 | 1969 - 1973 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1986ccm) Petrol | B20E | 145 | 1972 - 1973 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1986ccm) Petrol | B20D | 145 | 1972 - 1974 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1986ccm) Petrol | B20B | 145 | 1972 - 1974 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1986ccm) Petrol | B20B | 145 | 1972 - 1973 | ||
| VOLVO | 145 Estate/Combi | 2.0 (1998ccm) Petrol | B20F | 145 | 1973 - 1975 | ||
| VOLVO | 242 | 2.0 (1986ccm) Petrol | B19A/B20A | 242 | 1974 - 1982 | ||
| VOLVO | 245 Estate/Combi | 2.0 (1986ccm) Petrol | B20A | 245 | 1974 - 1975 | ||
| VOLVO | Amazone | 1.8 (1779ccm) Petrol | B18A | 120 | 1966 - 1972 | ||
| VOLVO | Amazone | 2.0 (1986ccm) Petrol | B20A | 121 | 1966 - 1972 | ||
| VOLVO | Amazone | 2.0 (1986ccm) Petrol | B20B | 121 | 1968 - 1972 | ||
| VOLVO | P1800 | 2.0 (1986ccm) Petrol | B20E | P18 | 1969 - 1973 |
Description
A0136 Replacement Alternator
The A0136 alternator is a replacement unit identified by Lucas reference LRA00136. The listed electrical rating is 12V 35A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Volvo 142 1.8 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 35A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Volvo 142 1.8 Petrol – selected applications 1966–1972 (engine code B18B).
- Volvo 144 1.8 Petrol – selected applications 1966–1972 (engine code B18B).
- Volvo 145 Estate/Combi 1.8 Petrol – selected applications 1966–1968 (engine code B18B).
- Volvo 242 2.0 Petrol – selected applications 1974–1982 (engine code B19A/B20A).
- Volvo 245 Estate/Combi 2.0 Petrol – selected applications 1974–1975 (engine code B20A).
- Volvo Amazone 1.8 Petrol – selected applications 1966–1972 (engine code B18A).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0136. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120400604, 120400605, 986032870, LRA00136, LRA136
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0136 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0136 fit my Volvo 142?
Volvo 142 1.8 Petrol (1966–1972) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0136 replace Lucas LRA00136?
Lucas LRA00136 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0136?
The listed details include 12V, 35A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0136 new or remanufactured?
Check the current product condition selection for A0136. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0136?
Compare 12V compatibility, 35A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
