A0188 12V 28A Alternator Fits Case I.H. 1046, Case I.H. 1246
Price range: £150.00 through £240.00
The A0188 12V 28A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Case IH 1046, Case IH 1246, Case IH 824, Case IH 946 models. Identification references include Lucas LRA00188, Bosch 9120144243, Valeo 2541477. Its listed 12V 28A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0188 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 28 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 42 mm |
| Mounting holes | 2 qty |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0188 | Dyno Electrics |
| 986031008 | Bosch Exchange |
| 986031980 | Bosch Exchange |
| 986031981 | Bosch Exchange |
| 986032070 | Bosch Exchange |
| 986032071 | Bosch Exchange |
| 986032760 | Bosch Exchange |
| 986032761 | Bosch Exchange |
| 11201255 | Mahle |
| 11201256 | Mahle |
| 14201173 | AES |
| 20437R | WAI |
| 225002070 | PSH |
| 2541477 | Valeo |
| 306005000 | Carrier |
| 306005002 | Carrier |
| 432754 | Valeo |
| 432768 | Valeo |
| 432804 | Valeo |
| 432809 | Valeo |
| 433036 | Valeo |
| 433355 | Valeo |
| 433356 | Valeo |
| 433359 | Valeo |
| 436373 | Valeo |
| 451036 | RNL |
| 570511 | PSA |
| 570554 | PSA |
| 5705Z1 | PSA |
| 7101798 | Carrier |
| 72735093 | Mahle |
| 7700590227 | Renault |
| 7701348200 | Renault |
| 7701349279 | Renault |
| 9120144243 | Bosch |
| 9120330723 | Bosch |
| 91514788 | PSA |
| 9151478880 | PSA |
| 91515434 | PSA |
| 943356132 | Magneti Marelli |
| 943356150 | Magneti Marelli |
| 943356160 | Magneti Marelli |
| 95495192 | PSA |
| 95619190 | PSA |
| 96619190 | PSA |
| 9AR2728F | Motorola |
| 9AR2728G | Motorola |
| A12R37 | Valeo |
| A12R9 | Valeo |
| A13N237 | Valeo |
| A13N94 | Valeo |
| A13R124 | Valeo |
| A13R143 | Valeo |
| A13R158 | Valeo |
| AAK4105 | Mahle |
| ALT14053 | Wood Auto |
| BSPALS12X28 | PSA |
| CA164IR | HC-Parts |
| CA176IR | HC-Parts |
| DRA1871 | Delco Remy |
| IA0256 | Mahle |
| LRA00188 | Lucas |
| LRA00287 | Lucas |
| LRA00763 | Lucas |
| LRA00864 | Lucas |
| LRA02328 | Lucas |
| LRA188 | Lucas |
| LRA2328 | Lucas |
| LRA287 | Lucas |
| LRA763 | Lucas |
| LRA864 | Lucas |
| MAHMG94 | Wood Auto |
| MAR397 | Magneti Marelli |
| MAR405 | Magneti Marelli |
| MAR406 | Magneti Marelli |
| MAR418 | Magneti Marelli |
| MG94 | Mahle |
| NA227 | Valeo |
| NA248 | Valeo |
| NA273 | Valeo |
| VA113 | Valeo |
| VA125 | Valeo |
| WOOALT14053 | Wood Auto |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CASE I.H. | 1046 | 0ccm Diesel | IH D-358 | 1974 - 1979 | |||
| CASE I.H. | 1246 | 0ccm Diesel | IH DT-358 | 1970 - 1979 | |||
| CASE I.H. | 824 | 0ccm Diesel | IH D-239 | 1970 - 1973 | |||
| CASE I.H. | 946 | 0ccm Diesel | IH D-310 | 1974 - 1979 | |||
| DEUTZ-FAHR | D4506 | 2827ccm Diesel | F3L912 | 1974 - 1979 | |||
| DEUTZ-FAHR | D5206 | 2827ccm Diesel | F3L912 | 1974 - 1979 | |||
| DEUTZ-FAHR | D6006 | 3770ccm Diesel | F4L912 | 1970 - 1974 | |||
| DEUTZ-FAHR | D6206 | 3770ccm Diesel | F4L912 | 1974 - 1979 | |||
| DEUTZ-FAHR | D6806 | 3770ccm Diesel | F4L912 | 1974 - 1979 | |||
| DEUTZ-FAHR | D7206 | 3770ccm Diesel | F4L912 | 1974 - 1979 | |||
| FENDT | Farmer 200S | 2827ccm Diesel | KHD-F3L912 | 1974 - 1979 |
Description
A0188 Replacement Alternator
The Sahibs A0188 alternator is associated with Lucas reference LRA00188 for replacement identification. The listed electrical rating is 12V 28A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Case IH 1046 variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 28A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Case IH 1046 – selected applications 1974–1979 (engine code IH D-358).
- Case IH 1246 – selected applications 1970–1979 (engine code IH DT-358).
- Case IH 824 – selected applications 1970–1973 (engine code IH D-239).
- Case IH 946 – selected applications 1974–1979 (engine code IH D-310).
- Deutz-Fahr D4506 2827ccm Diesel – selected applications 1974–1979 (engine code F3L912).
- Deutz-Fahr D5206 2827ccm Diesel – selected applications 1974–1979 (engine code F3L912).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0188. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986031008, 986031980, 986031981, 986032070, 986032071, 986032760, 986032761, 9120144243, 9120330723, 2541477, 432754, 432768, 432804, 432809, 433036, 433355, 433356, 433359, 436373, A12R37, A12R9, A13N237, A13N94, A13R124, A13R143, A13R158, NA227, NA248, NA273, VA113, VA125, LRA00188, LRA00287, LRA00763, LRA00864, LRA02328, LRA188, LRA2328, LRA287, LRA763, LRA864, DRA1871, 11201255, 11201256, 72735093, AAK4105, IA0256, MG94, 7700590227, 7701348200, 7701349279
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0188 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0188 fit my Case IH 1046?
Case IH 1046 (1974–1979) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0188 replace Lucas LRA00188?
Lucas LRA00188 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0188?
The listed details include 12V, 28A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0188 new or remanufactured?
Check the current product condition selection for A0188. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0188?
Compare 12V compatibility, 28A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
