A0535 12V 42A Alternator Fits Trabant Trabi, Wartburg 353
Price range: £137.84 through £220.55
Identify a replacement alternator using Sahibs A0535, listed at 12V 42A. Listed applications include selected Trabant Trabi, Wartburg 353 models. Identification references include Lucas LRA00535, Bosch 120488114, Valeo 2926380. Its listed 12V 42A rating provides an electrical matching point for your existing unit. Compare the pulley, connections and mounting arrangement with your existing alternator. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0535 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 42 A |
| Volt | 12 V |
| Mounting holes | 2 qty |
| Position | -60° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0535 | Dyno Electrics |
| 1175731 | KHD |
| 1178299 | KHD |
| 1178606 | KHD |
| 1182151 | KHD |
| 1183638 | KHD |
| 1183852 | KHD |
| 120488114 | Bosch |
| 120488185 | Bosch |
| 120488209 | Bosch |
| 120488309 | Bosch |
| 120489043 | Bosch |
| 120489044 | Bosch |
| 120489183 | Bosch |
| 120489309 | Bosch |
| 120489686 | Bosch |
| 046903015B | Volkswagen AG |
| 5710960 | Bomag |
| 986031237 | Bosch Exchange |
| 986031240 | Bosch Exchange |
| 986032940 | Bosch Exchange |
| 986037890 | Bosch Exchange |
| 1000164335 | Weidemann |
| 11201117 | Mahle |
| 11201215 | Mahle |
| 11201226 | Mahle |
| 11201478 | Mahle |
| 11203405 | Mahle |
| 11204050 | Mahle |
| 11204713 | Mahle |
| 1178521 | KHD |
| 1183447 | KHD |
| 14394N | WAI |
| 1516536R | DAF |
| 1530710 | Ford |
| 18201078 | AES |
| 19025123 | Delco Remy |
| 19093093 | Delco Remy |
| 291317870 | Atlas |
| 2926380 | Valeo |
| 2940944 | Valeo |
| 3040714 | KHD |
| 31100090048 | Suzuki |
| 3110090048 | Steyr |
| 436136 | Valeo |
| 436198 | Valeo |
| 436286 | Valeo |
| 565004055 | PSH |
| 66021162 | Prestolite |
| 72735208 | Mahle |
| 72740588 | Mahle |
| 72740589 | Mahle |
| 90156223 | Wilson |
| 90156299 | Wilson |
| 943356727 | Magneti Marelli |
| 9AR2638 | Valeo |
| 9AR2810 | Valeo |
| AAK1165 | Mahle |
| AAK1189 | Mahle |
| AAK11B9 | Mahle |
| AAK1336 | Mahle |
| AAK3818 | Mahle |
| AAK4349 | Mahle |
| AAK4950 | Mahle |
| AL5048X | Bosch (USA) |
| ALT20738 | Wood Auto |
| ALTH013 | Unipoint |
| BXC1233A | Bosch (USA) |
| CA192IR | HC-Parts |
| CA215IR | HC-Parts |
| CA238 | HC-Parts |
| DRA1240 | Delco Remy |
| DRA7890 | Delco Remy |
| DRA7890N | Delco Remy |
| F042A0H013 | Bosch |
| G205900010010 | Steyr |
| IA1078 | Mahle |
| IA91078 | Mahle |
| IA91078C | Mahle |
| LEA0071 | Lucas |
| LEA0502 | Lucas |
| LETIA1078 | Wood Auto |
| LRA00535 | Lucas |
| LRA00744 | Lucas |
| LRA00982 | Lucas |
| LRA535 | Lucas |
| LRA744 | Lucas |
| LRA982 | Lucas |
| LRB00134 | Lucas |
| LRB134 | Lucas |
| MAHMG209 | Wood Auto |
| MAR499 | Magneti Marelli |
| MAR872 | Magneti Marelli |
| MG1173 | Mahle |
| MG209 | Mahle |
| NA051 | Valeo |
| PBNA1134 | Prestolite |
| PNBA1134 | Prestolite |
| RNL3789 | RNL |
| WOOALT20738 | Wood Auto |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| TRABANT | Trabi | 1.0 (1043ccm) Petrol | GL | Universal | T7 | 1990 - 1991 | |
| TRABANT | Trabi | 1.0 (1043ccm) Petrol | GL | Tramp | T7 | 1990 - 1991 | |
| WARTBURG | 353 | 1.0 (992ccm) Petrol | 2B/2BA | 35308 | 1969 - 1988 | ||
| WARTBURG | 353 | 1.0 (992ccm) Petrol | 2B/2BA | Tourist | 35318 | 1969 - 1989 |
Description
A0535 Replacement Alternator
The Sahibs A0535 alternator is associated with Lucas reference LRA00535 for replacement identification. The listed electrical rating is 12V 42A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Trabant Trabi 1.0 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 42A output: compare the listed rating with the original alternator.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Trabant Trabi 1.0 Petrol – selected applications 1990–1991 (engine code GL).
- Wartburg 353 1.0 Petrol – selected applications 1969–1988 (engine code 2B/2BA).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0535. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120488114, 120488185, 120488209, 120488309, 120489043, 120489044, 120489183, 120489309, 120489686, 986031237, 986031240, 986032940, 986037890, F042A0H013, 2926380, 2940944, 436136, 436198, 436286, 9AR2638, 9AR2810, NA051, LRA00535, LEA0071, LEA0502, LRA00744, LRA00982, LRA535, LRA744, LRA982, LRB00134, LRB134, 19025123, 19093093, DRA1240, DRA7890, DRA7890N, 66021162, PBNA1134, PNBA1134, 11201117, 11201215, 11201226, 11201478, 11203405, 11204050, 11204713, 72735208, 72740588, 72740589, AAK1165, AAK1189, AAK11B9, AAK1336, AAK3818, AAK4349, AAK4950, IA1078, IA91078, IA91078C, MG1173, MG209, 1530710, 1516536R
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0535 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0535 fit my Trabant Trabi?
Trabant Trabi 1.0 Petrol (1990–1991) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0535 replace Lucas LRA00535?
Lucas LRA00535 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0535?
The listed details include 12V, 42A output. Compare the complete specifications on this page with the unit being replaced.
Is A0535 new or remanufactured?
Check the current product condition selection for A0535. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0535?
Compare 12V compatibility, 42A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
