A0574 12V 50A Alternator Fits Nissan Laurel, Subaru 1800
Price range: £130.00 through £208.00
The A0574 12V 50A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Nissan Laurel, Subaru 1800, Subaru 1800 Estate/Wagon models. Identification references include Lucas LRA00574, Bosch F042A0H002, Valeo 436505. Its listed 12V 50A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0574 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 50 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 73 mm |
| Mounting holes | 3 qty |
| Position | 180° |
| B+ | M5 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.69 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0574 | Dyno Electrics |
| 986032620 | Bosch Exchange |
| 986032650 | Bosch Exchange |
| 986032651 | Bosch Exchange |
| 986032681 | Bosch Exchange |
| 986033431 | Bosch Exchange |
| 986033470 | Bosch Exchange |
| 986035401 | Bosch Exchange |
| 0986CR0914 | Bosch Exchange |
| 0986CR0929 | Bosch Exchange |
| 0986UR0914 | Bosch Exchange |
| 110168 | HC-Cargo |
| 110330 | HC-Cargo |
| 1248077201 | Yanmar |
| 1360815 | Hyster |
| 14255N | WAI |
| 165003050 | PSH |
| 20100348 | Prestolite |
| 2310001B10 | Nissan |
| 2310001BR5EX | Nissan |
| 2310004M10 | Nissan |
| 2310005B10 | Nissan |
| 2310010B10 | Nissan |
| 2310010W01 | Nissan |
| 2310027G00 | Nissan |
| 2310027G10 | Nissan |
| 23100A4M10 | Nissan |
| 23100B9800 | Nissan |
| 23100B9801 | Nissan |
| 23100B9805 | Nissan |
| 23100B9810 | Nissan |
| 23100G3706 | Nissan |
| 23100H7700 | Nissan |
| 23100H7701 | Nissan |
| 23100H7701EP | Nissan |
| 23100H7702 | Nissan |
| 23100H7702L | Nissan |
| 23100H7703 | Nissan |
| 23100H7710 | Nissan |
| 23100H7711 | Nissan |
| 23100M5960 | Nissan |
| 23100M5961 | Nissan |
| 23100M6601 | Nissan |
| 23100M6601EP | Nissan |
| 23100M6610 | Nissan |
| 23100M66R1EX | Nissan |
| 23100N9500 | Nissan |
| 23100N9501 | Nissan |
| 23100N9502 | Nissan |
| 23100N9510 | Nissan |
| 23100N9511 | Nissan |
| 23100N9512 | Nissan |
| 23100N9512EP | Nissan |
| 23100P2503 | Nissan |
| 23100P2504 | Nissan |
| 23100P2505 | Nissan |
| 23100P2506 | Nissan |
| 23100P2507 | Nissan |
| 23100P2508 | Nissan |
| 23100Q4500 | Nissan |
| 23100Q4501 | Nissan |
| 23100Q4510 | Nissan |
| 23100Q4511 | Nissan |
| 23100R9011 | Nissan |
| 23100U9502 | Nissan |
| 23100U9502L | Nissan |
| 23100U9503 | Nissan |
| 23100U9510 | Nissan |
| 23100U9511 | Nissan |
| 23100U9512 | Nissan |
| 23100U9513 | Nissan |
| 23100W5800 | Nissan |
| 23100W5801 | Nissan |
| 23100W5802 | Nissan |
| 23100W5803 | Nissan |
| 23100W5810 | Nissan |
| 23100W5811 | Nissan |
| 23100W6811 | Nissan |
| 23100W7015 | Nissan |
| 23100W7101 | Nissan |
| 23100W7111 | Nissan |
| 3068340 | Hyster |
| 3122810 | Hyster |
| 436505 | Valeo |
| 436506 | Valeo |
| 561009 | Valeo |
| 582003470 | Isuzu |
| 8941271860 | Isuzu |
| 8EA2011NA | Prestolite |
| 90251010 | Wilson |
| 90251011 | Wilson |
| 90251019 | Wilson |
| 90251094 | Wilson |
| 90273052 | Wilson |
| 90273176 | Wilson |
| 90273187 | Wilson |
| 90273301 | Wilson |
| A001T24571 | Mitsubishi |
| A001T24597 | Mitsubishi |
| A001T32497 | Mitsubishi |
| A002T14472 | Mitsubishi |
| A002T17172 | Mitsubishi |
| A002T21474 | Mitsubishi |
| A002T21782 | Mitsubishi |
| A002T22272 | Mitsubishi |
| A002T22282 | Mitsubishi |
| A002T22871 | Mitsubishi |
| A002T24072 | Mitsubishi |
| A002T24272 | Mitsubishi |
| A002T24371 | Mitsubishi |
| A002T24372 | Mitsubishi |
| A002T24971 | Mitsubishi |
| A002T24972 | Mitsubishi |
| A002T40971 | Mitsubishi |
| A005T00272 | Mitsubishi |
| A005T06671 | Mitsubishi |
| A005T20871 | Mitsubishi |
| A005T20872 | Mitsubishi |
| A005T20972 | Mitsubishi |
| A005T21871 | Mitsubishi |
| A005T21879 | Mitsubishi |
| A005T21897 | Mitsubishi |
| A1T24571 | Mitsubishi |
| A1T24597 | Mitsubishi |
| A1T32497 | Mitsubishi |
| A2T14472 | Mitsubishi |
| A2T17172 | Mitsubishi |
| A2T21474 | Mitsubishi |
| A2T21782 | Mitsubishi |
| A2T22272 | Mitsubishi |
| A2T22282 | Mitsubishi |
| A2T22871 | Mitsubishi |
| A2T24072 | Mitsubishi |
| A2T24272 | Mitsubishi |
| A2T24371 | Mitsubishi |
| A2T24372 | Mitsubishi |
| A2T24971 | Mitsubishi |
| A2T24972 | Mitsubishi |
| A2T40971 | Mitsubishi |
| A5T00272 | Mitsubishi |
| A5T06671 | Mitsubishi |
| A5T20871 | Mitsubishi |
| A5T20872 | Mitsubishi |
| A5T20972 | Mitsubishi |
| A5T21871 | Mitsubishi |
| A5T21879 | Mitsubishi |
| A5T21897 | Mitsubishi |
| ACA389 | ATK |
| ADA327 | ATK |
| ADA330 | ATK |
| AH2060N31 | Mitsubishi |
| AL238X | Bosch (USA) |
| AL242X | Bosch (USA) |
| ALT23001 | Wood Auto |
| ALT31012 | Wood Auto |
| ALT32050 | Wood Auto |
| ALT32184 | Wood Auto |
| ALT32345 | Wood Auto |
| ALTH002 | Unipoint |
| AQ2050A24 | Mitsubishi |
| AQ2050N12 | Mitsubishi |
| AQ2060N7 | Mitsubishi |
| AQ2250C2 | Mitsubishi |
| AQ2250C31 | Mitsubishi |
| AQ2250D32 | Mitsubishi |
| DRA2651 | Delco Remy |
| DRA2681 | Delco Remy |
| F032110168 | HC-Cargo |
| F042A0H002 | Bosch |
| HJA104IR | HC-Parts |
| JA103 | HC-Parts |
| JA104 | HC-Parts |
| JA104IR | HC-Parts |
| JA119 | HC-Parts |
| LR1344 | Hitachi |
| LR13561 | Hitachi |
| LR13801 | Hitachi |
| LR150100 | Hitachi |
| LR150101 | Hitachi |
| LR150101B | Hitachi |
| LR150123 | Hitachi |
| LR150125 | Hitachi |
| LR150125B | Hitachi |
| LR150129 | Hitachi |
| LR150177 | Hitachi |
| LR15030 | Hitachi |
| LR15030B | Hitachi |
| LR15035 | Hitachi |
| LR15036 | Hitachi |
| LR15036A | Hitachi |
| LR15039 | Hitachi |
| LR15050 | Hitachi |
| LR15051 | Hitachi |
| LR15052 | Hitachi |
| LR15053 | Hitachi |
| LR15058 | Hitachi |
| LR15066 | Hitachi |
| LR15067 | Hitachi |
| LR15085 | Hitachi |
| LR15096 | Hitachi |
| LR15098 | Hitachi |
| LR15098B | Hitachi |
| LR15098E | Hitachi |
| LR15099 | Hitachi |
| LR15099B | Hitachi |
| LR16035 | Hitachi |
| LR16039 | Hitachi |
| LR16085 | Hitachi |
| LRA00251 | Lucas |
| LRA00335 | Lucas |
| LRA00348 | Lucas |
| LRA00368 | Lucas |
| LRA00441 | Lucas |
| LRA00475 | Lucas |
| LRA00476 | Lucas |
| LRA00574 | Lucas |
| LRA01176 | Lucas |
| LRA1176 | Lucas |
| LRA251 | Lucas |
| LRA335 | Lucas |
| LRA348 | Lucas |
| LRA368 | Lucas |
| LRA441 | Lucas |
| LRA475 | Lucas |
| LRA476 | Lucas |
| LRA574 | Lucas |
| 12-Mar | Magneti Marelli |
| 23-Mar | Magneti Marelli |
| Mar-59 | Magneti Marelli |
| Mar-80 | Magneti Marelli |
| MAR984 | Magneti Marelli |
| MAR989 | Magneti Marelli |
| MITA1T22971 | Wood Auto |
| SA454 | Lombardini |
| TRA041 | TWA |
| WOOALT32050 | Wood Auto |
| WOOALT32184 | Wood Auto |
| WOOALT32345 | Wood Auto |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A1218 | 50A | 40A | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| NISSAN | Laurel | 2.0 (1998ccm) Petrol | L20A | C31 | 1981 - 1984 | ||
| SUBARU | 1800 | 1.8 (1781ccm) Petrol | EA82 | A10AC | 1985 - 1986 | ||
| SUBARU | 1800 | 1.8 (1781ccm) Petrol | EA82T | A10AC | 1988 - 1990 | ||
| SUBARU | 1800 Estate/Wagon | 1.8 (1781ccm) Petrol | EA82T | A10AK | 1988 - 1990 |
Description
A0574 Replacement Alternator
The A0574 alternator is a replacement unit identified by Lucas reference LRA00574. The listed electrical rating is 12V 50A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Nissan Laurel 2.0 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 50A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M5 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Nissan Laurel 2.0 Petrol – selected applications 1981–1984 (engine code L20A).
- Subaru 1800 1.8 Petrol – selected applications 1985–1986 (engine code EA82).
- Subaru 1800 Estate/Wagon 1.8 Petrol – selected applications 1988–1990 (engine code EA82T).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0574. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986032620, 986032650, 986032651, 986032681, 986033431, 986033470, 986035401, 0986CR0914, 0986CR0929, 0986UR0914, F042A0H002, 436505, 436506, 561009, LRA00574, LRA00251, LRA00335, LRA00348, LRA00368, LRA00441, LRA00475, LRA00476, LRA01176, LRA1176, LRA251, LRA335, LRA348, LRA368, LRA441, LRA475, LRA476, LRA574, A001T24571, A001T24597, A001T32497, A002T14472, A002T17172, A002T21474, A002T21782, A002T22272, A002T22282, A002T22871, A002T24072, A002T24272, A002T24371, A002T24372, A002T24971, A002T24972, A002T40971, A005T00272, A005T06671, A005T20871, A005T20872, A005T20972, A005T21871, A005T21879, A005T21897, A1T24571, A1T24597, A1T32497, A2T14472, A2T17172, A2T21474, A2T21782, A2T22272, A2T22282, A2T22871, A2T24072, A2T24272, A2T24371, A2T24372, A2T24971, A2T24972, A2T40971, A5T00272, A5T06671, A5T20871, A5T20872, A5T20972, A5T21871, A5T21879, A5T21897, AH2060N31, AQ2050A24, AQ2050N12, AQ2060N7, AQ2250C2, AQ2250C31, AQ2250D32, LR1344, LR13561, LR13801, LR150100, LR150101, LR150101B, LR150123, LR150125, LR150125B, LR150129, LR150177, LR15030, LR15030B, LR15035, LR15036, LR15036A, LR15039, LR15050, LR15051, LR15052, LR15053, LR15058, LR15066, LR15067, LR15085, LR15096, LR15098, LR15098B, LR15098E, LR15099, LR15099B, LR16035, LR16039, LR16085, DRA2651, DRA2681, 20100348, 8EA2011NA
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0574 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0574 fit my Nissan Laurel?
Nissan Laurel 2.0 Petrol (1981–1984) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0574 replace Lucas LRA00574?
Lucas LRA00574 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0574?
The listed details include 12V, 50A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0574 new or remanufactured?
Check the current product condition selection for A0574. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0574?
Compare 12V compatibility, 50A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
