A0596 12V 65A Alternator Fits Autobianchi Y10, Fiat Elba CSL
Price range: £90.33 through £116.49
Identify a replacement alternator using Sahibs A0596, listed at 12V 65A. Listed applications include selected Autobianchi Y10, Fiat Elba CSL, Fiat Fiorino, Fiat Regata models. Identification references include Lucas LRA00596, Valeo 2565993, Denso DAN550. Its listed 12V 65A rating provides an electrical matching point for your existing unit. Check the 5-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0596 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 65 A |
| Volt | 12 V |
| No. of Grooves | 5 qty |
| Pulley Diameter | 60 mm |
| Mounting holes | 3 qty |
| Position | 33° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.8 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0596 | Dyno Electrics |
| 63320048 | Magneti Marelli |
| 63320073 | Magneti Marelli |
| 63321156 | Magneti Marelli |
| 63321156010 | Magneti Marelli |
| 63321157 | Magneti Marelli |
| 763321156 | Magneti Marelli |
| 986037130 | Bosch Exchange |
| 986037170 | Bosch Exchange |
| 111148 | HC-Cargo |
| 11201698 | Mahle |
| 113473 | HC-Cargo |
| 21178N | WAI |
| 2565993 | Valeo |
| 436242 | Valeo |
| 436244 | Valeo |
| 46231690 | Fiat Group |
| 46231721 | Fiat Group |
| 46445100 | Fiat Group |
| 505024065 | PSH |
| 63320048010 | Magneti Marelli |
| 63320131 | Magneti Marelli |
| 63320132 | Magneti Marelli |
| 63321089 | Magneti Marelli |
| 63321090 | Magneti Marelli |
| 63321090010 | Magneti Marelli |
| 63321097 | Magneti Marelli |
| 63321097010 | Magneti Marelli |
| 63321098 | Magneti Marelli |
| 63321137 | Magneti Marelli |
| 63321150 | Magneti Marelli |
| 63321157010 | Magneti Marelli |
| 72735207 | Mahle |
| 7596859 | Fiat Group |
| 7647441 | Fiat Group |
| 7650210 | Fiat Group |
| 7651050 | Fiat Group |
| 7651051 | Fiat Group |
| 7702242 | Fiat Group |
| 7702372 | Fiat Group |
| 77547410 | Fiat Group |
| 77603410 | Fiat Group |
| 943321090 | Magneti Marelli |
| 943321098 | Magneti Marelli |
| 943321137 | Magneti Marelli |
| 943321150 | Magneti Marelli |
| 9.44E+11 | Magneti Marelli |
| A13E66 | Valeo |
| A13E67 | Valeo |
| AAK4559 | Mahle |
| CA596IR | HC-Parts |
| DAN550 | Denso |
| DAN617 | Denso |
| DRA3283 | Delco Remy |
| F032111148 | HC-Cargo |
| HCA596IR | HC-Parts |
| IA0698 | Mahle |
| LRA00596 | Lucas |
| LRA596 | Lucas |
| LRB00178 | Lucas |
| LRB178 | Lucas |
| MAN323 | Magneti Marelli |
| MG208 | Mahle |
| NA488 | Valeo |
| NA489 | Valeo |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0178 | Pulley | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| AUTOBIANCHI | Y10 | 1.3 (1301ccm) Petrol | 146A5046/156A5046 | 156AC/156AF | 1989 - 1996 | ||
| AUTOBIANCHI | Y10 | 1.3 (1301ccm) Petrol | 156B000 | 156AB | 1989 - 1996 | ||
| FIAT | Elba CSL | 1.5 (1498ccm) Petrol | 149C1000 | Panorama | 146C9 | 1991 - 1997 | |
| FIAT | Fiorino | 1.5 (1498ccm) Petrol | 149C1000 | 146A9 | 1988 - 1993 | ||
| FIAT | Regata | 1.6 (1585ccm) Petrol | 138R0000/149A000 | 138A/138B | 1983 - 1989 | ||
| FIAT | Uno | 1.3 (1301ccm) Petrol | 146A2000/146A2246 | 146A | 1985 - 1988 | ||
| FIAT | Uno | 1.3 (1301ccm) Petrol | 146A2146 | 146A | 1987 - 1987 | ||
| FIAT | Uno | 1.3 (1301ccm) Petrol | 146A2246 | 146E | 1989 - 1991 | ||
| FIAT | Uno | 1.4 (1372ccm) Petrol | 146A8000 | 146E | 1989 - 1996 | ||
| FIAT | Uno | 1.5 (1498ccm) Petrol | 138C2000/138C2048/146C2028/149C1000 | 146A/146E | 1989 - 1993 | ||
| INNOCENTI | Elba | 1.5 (1498ccm) Petrol | 149C1000 | Panorama | 146C9 | 1992 - 1994 | |
| LANCIA | Delta | 1.3 (1301ccm) Petrol | 831A2000/831B000 | 831AB | 1986 - 1992 | ||
| LANCIA | Delta | 1.3 (1301ccm) Petrol | 831A200/831B000 | 831AB | 1983 - 1992 | ||
| LANCIA | Delta | 1.5 (1498ccm) Petrol | 831A1000/831A300 | 831AB | 1982 - 1987 | ||
| LANCIA | Prisma | 1.5 (1498ccm) Petrol | 831A300 | 831AB | 1983 - 1986 | ||
| LANCIA | Prisma | 1.5 (1498ccm) Petrol | 138C000 | 831AB | 1985 - 1986 | ||
| LANCIA | Prisma | 1.5 (1498ccm) Petrol | 831A3000 | 831AB | 1986 - 1989 |
Description
A0596 Replacement Alternator
The Sahibs A0596 alternator is associated with Lucas reference LRA00596 for replacement identification. The listed electrical rating is 12V 65A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Autobianchi Y10 1.3 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 65A output: compare the listed rating with the original alternator.
- 5-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Autobianchi Y10 1.3 Petrol – selected applications 1989–1996 (engine code 146A5046/156A5046).
- Fiat Elba CSL 1.5 Petrol – selected applications 1991–1997 (engine code 149C1000).
- Fiat Fiorino 1.5 Petrol – selected applications 1988–1993 (engine code 149C1000).
- Fiat Regata 1.6 Petrol – selected applications 1983–1989 (engine code 138R0000/149A000).
- Fiat Uno 1.3 Petrol – selected applications 1985–1988 (engine code 146A2000/146A2246).
- Innocenti Elba 1.5 Petrol – selected applications 1992–1994 (engine code 149C1000).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0596. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986037130, 986037170, 2565993, 436242, 436244, A13E66, A13E67, NA488, NA489, DAN550, DAN617, LRA00596, LRA596, LRB00178, LRB178, DRA3283, 11201698, 72735207, AAK4559, IA0698, MG208
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0596 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0596 fit my Autobianchi Y10?
Autobianchi Y10 1.3 Petrol (1989–1996) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0596 replace Lucas LRA00596?
Lucas LRA00596 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0596?
The listed details include 12V, 65A output, 5 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A0596 new or remanufactured?
Check the current product condition selection for A0596. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0596?
Compare 12V compatibility, 65A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
