A0698 12V 75A Alternator Fits Renault Master P35, Renault Master T30
Price range: £96.10 through £124.75
Identify a replacement alternator using Sahibs A0698, listed at 12V 75A. Listed applications include selected Renault Master P35, Renault Master T30, Renault Master T35, Renault Trafic P1400 models. Identification references include Lucas LRA00698, Bosch 986034860, Valeo 2541204. Its listed 12V 75A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0698 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 75 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 63 mm |
| Mounting holes | 3 qty |
| Position | 20° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.84 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0698 | Dyno Electrics |
| 401745081 | Euro Car Part |
| A3001 | AS-PL |
| 986034860 | BOSCH |
| 986034861 | BOSCH |
| 110889 | CARGO |
| F032110889 | CARGO |
| 1516551R | DAF |
| DRA4861 | DELCO |
| 8EL725716-001 | HELLA |
| 9AR2950P | MOTOROLA |
| 4400332 | OPEL |
| 9108332 | OPEL |
| 35215030 | PRESTOLITE |
| 66021574 | PRESTOLITE |
| 66021575 | PRESTOLITE |
| 5000725698 | RENAULT |
| 5001011181 | RENAULT |
| 5001014178 | RENAULT |
| 5001014181 | RENAULT |
| 542058 | RENAULT |
| 542075 | RENAULT |
| 6006000076 | RENAULT |
| 7700714313 | RENAULT |
| 7700729300 | RENAULT |
| 7700731740 | RENAULT |
| 7700748171 | RENAULT |
| 7700802518 | RENAULT |
| 7701352052 | RENAULT |
| 7701352125 | RENAULT |
| 7701362052 | RENAULT |
| 7701381535 | RENAULT |
| 7701499249 | RENAULT |
| 7701499492 | RENAULT |
| 2541204 | VALEO |
| 2541324 | VALEO |
| 432783 | VALEO |
| 433449 | VALEO |
| 433453 | VALEO |
| 436349 | VALEO |
| 436360 | VALEO |
| 436453 | VALEO |
| 436460 | VALEO |
| 439240 | VALEO |
| A14N144 | VALEO |
| A14N163 | VALEO |
| A14N4 | VALEO |
| A14R25T | VALEO |
| NA251 | VALEO |
| NA553 | VALEO |
| VA143 | VALEO |
| 9031081 | VOLVO |
| ALTS007 | 3EFFE |
| PRAS007 | 3EFFE |
| CGB-80815 | AINDE |
| ANM37081X | ANDEL |
| AEA6198 | AUTOELECTRO |
| CAL15267AS | CASCO |
| CAL15267RS | CASCO |
| 4227 | CEVAM |
| 55890 | EAI |
| ALT00867 | ELECTROLOG |
| 28-0815 | ELSTOCK |
| 210031 | ERA |
| 9034861 | FRIESEN |
| CA314IR | HC PARTS |
| 30229RI | KUHNER |
| 30301RI | KUHNER |
| 30314RI | KUHNER |
| 11.0314 | LAUBER |
| 440461 | LOGISTIK |
| LRA00698 | LUCAS |
| LRA698 | LUCAS |
| 5515298 | MEAT & DORIA |
| 89212372 | POWERMAX |
| 9212372 | POWERMAX |
| 20179762BN | REAL |
| 20179762RC | REAL |
| 311155 | RHIAG |
| 2015267 | SANDO |
| A12VA1004A2 | SIDAT |
| ALT171370 | SIOM |
| ALT172670 | SIOM |
| ALT4520 | SIOM |
| SA709 | SOVEREIGN |
| STX100344 | STARDAX |
| STX100635 | STARDAX |
| STX101003 | STARDAX |
| STX101040 | STARDAX |
| 20698R | WAI / TRANSPO |
| ALT14075 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| RENAULT | Master P35 | 2.4 (2445ccm) Diesel | 814061/S8U730 | PHASE I | QH74/QH94/QHA4/QJ74/QJ94 | 1980 - 1989 | |
| RENAULT | Master P35 | 2.4 (2445ccm) Diesel | S8U730 | PHASE I | QJ54 | 1986 - 1989 | |
| RENAULT | Master T30 | 2.5 (2499ccm) Diesel | S8U742 | PHASE I | RF16 | 1980 - 1998 | |
| RENAULT | Master T35 | 2.4 (2445ccm) Diesel | S8U731/S8U748 | PHASE I | RC7G/RC7L/RC9G/RC9L/RH94/RH9G/RH9L/RJ94/RJ9G/RJ9L/RL7G/RL7L/RL9G/RL9L | 1980 - 1998 | |
| RENAULT | Master T35 | 2.5 (2499ccm) Diesel | S9U700/S9U702/S9U704/S9U714/S9U740 | PHASE I | RC77/RC7C/RC7H/RC7J/RC7K/RC97/RC9C/RC9H/RC9K/RH95/RH97/RH9C/RH9H/RH9K/RJ95/RJ97/RJ9C/RJ9H/RJ9J/RJ9K/RL75/RL77/RL7C/RL7H/RL7J/RL7K/RL95/RL97/RL9C/RL9H/RL9J/RL9K | 1980 - 1998 | |
| RENAULT | Master T35 | 2.5 (2499ccm) Diesel | S9U700/S9U704/S9U714/S9U740 | PHASE I | R8D5/R8D7/R8DH/R8DK | 1981 - 1998 | |
| RENAULT | Master T35 | 2.5 (2499ccm) Diesel | S8U742 | PHASE I | R8D6 | 1989 - 1998 | |
| RENAULT | Master T35 | 2.5 (2499ccm) Diesel | S8U742 | PHASE I | RH16/RH26/RJ16/RJ26/RJ56/RJ66 | 1989 - 1998 | |
| RENAULT | Master T35 | 2.5 (2499ccm) Diesel | S9U702 | PHASE I | RH1C/RH2C/RH5C/RJ1C/RJ2C/RJ5C/RJ6C | 1989 - 1998 | |
| RENAULT | Master T35 | 2.5 (2499ccm) Diesel | S9U740 | PHASE I | RC9J/RC9K/RH9J/RH9K/RJ9J/RJ9K/RL9J/RL9K | 1993 - 1998 | |
| RENAULT | Trafic P1400 | 2.4 (2445ccm) Diesel | S8U720 | PHASE I | P315/P515 | 1983 - 1989 | |
| RENAULT | Trafic T1000 | 2.5 (2499ccm) Diesel | S8U780 | PHASE I | THBM | 1999 - 2001 | |
| RENAULT | Trafic T1100 | 2.5 (2499ccm) Diesel | S8U750 | PHASE I | T414/T424 | 1989 - 2001 | |
| RENAULT | Trafic T1100 | 2.5 (2499ccm) Diesel | S8U750 | PHASE I | T2B4 | 1989 - 1994 | |
| RENAULT | Trafic T1100 | 2.5 (2499ccm) Diesel | S8U750/S8U780 | PHASE I | T2B4/T55M | 1989 - 2001 | |
| RENAULT | Trafic T1400 | 2.5 (2499ccm) Diesel | S8U750 | PHASE I | TB94 | 1989 - 1994 | |
| RENAULT | Trafic T1400 | 2.5 (2499ccm) Diesel | S8U758 | PHASE I | TB3G | 1994 - 1998 | |
| RENAULT | Trafic T1400 | 2.5 (2499ccm) Diesel | S8U758 | PHASE I | TC9G | 1994 - 1998 | |
| RENAULT | Trafic T1400 | 2.5 (2499ccm) Diesel | S8U758/S8U780 | PHASE I | TC9G/TC9M/TCJM | 1998 - 2001 | |
| RENAULT | Trafic T900 | 2.5 (2499ccm) Diesel | S8U780 | PHASE I | THBM | 1999 - 2001 | |
| RENAULT | Trafic V1400 | 2.5 (2499ccm) Diesel | S8U750 | PHASE I | V414/V424 | 1989 - 1994 | |
| RENAULT | Trafic V1400 | 2.5 (2499ccm) Diesel | S8U750 | PHASE I | V494 | 1989 - 1994 |
Description
A0698 Replacement Alternator
Start your A0698 alternator comparison with the linked Lucas reference LRA00698 and the specifications shown on this page. The listed electrical rating is 12V 75A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Renault Master P35 2.4 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 75A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Renault Master P35 2.4 Diesel – selected applications 1980–1989 (engine code 814061/S8U730).
- Renault Master T30 2.5 Diesel – selected applications 1980–1998 (engine code S8U742).
- Renault Master T35 2.4 Diesel – selected applications 1980–1998 (engine code S8U731/S8U748).
- Renault Trafic P1400 2.4 Diesel – selected applications 1983–1989 (engine code S8U720).
- Renault Trafic T1000 2.5 Diesel – selected applications 1999–2001 (engine code S8U780).
- Renault Trafic T1100 2.5 Diesel – selected applications 1989–2001 (engine code S8U750).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0698. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986034860, 986034861, 2541204, 2541324, 432783, 433449, 433453, 436349, 436360, 436453, 436460, 439240, A14N144, A14N163, A14N4, A14R25T, NA251, NA553, VA143, LRA00698, LRA698, DRA4861, 35215030, 66021574, 66021575, 5000725698, 5001011181, 5001014178, 5001014181, 542058, 542075, 6006000076, 7700714313, 7700729300, 7700731740, 7700748171, 7700802518, 7701352052, 7701352125, 7701362052, 7701381535, 7701499249, 7701499492, 1516551R
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0698 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0698 fit my Renault Master P35?
Renault Master P35 2.4 Diesel (1980–1989) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0698 replace Lucas LRA00698?
Lucas LRA00698 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0698?
The listed details include 12V, 75A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0698 new or remanufactured?
Check the current product condition selection for A0698. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0698?
Compare 12V compatibility, 75A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
