A0705 12V 60A Alternator Fits Mitsubishi Eclipse, Mitsubishi Galant
Price range: £101.78 through £134.21
Identify a replacement alternator using Sahibs A0705, listed at 12V 60A. Listed applications include selected Mitsubishi Eclipse, Mitsubishi Galant, Mitsubishi Lancer, Mitsubishi Lancer Estate/Wagon models. Identification references include Lucas LRA00705, Bosch 986037731, Valeo 436503. Its listed 12V 60A rating provides an electrical matching point for your existing unit. Check the 4-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0705 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 60 A |
| Volt | 12 V |
| No. of Grooves | 4 qty |
| Pulley Diameter | 54.5 mm |
| Mounting holes | 3 qty |
| Position | 60° |
| B+ | M5 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.5 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0705 | Dyno Electrics |
| UD11216A | AS-PL |
| 986037731 | BOSCH |
| 986037981 | BOSCH |
| 37300-21013 | HYUNDAI / KIA |
| 37300-32511 | HYUNDAI / KIA |
| 9.43E+11 | MAGNETI MARELLI |
| Mar-77 | MAGNETI MARELLI |
| A002T09691 | MITSUBISHI |
| A002T48791 | MITSUBISHI |
| A00T48791ZC | MITSUBISHI |
| A2T09691 | MITSUBISHI |
| A2T48791 | MITSUBISHI |
| A2T48791ZC | MITSUBISHI |
| A2T49992 | MITSUBISHI |
| M102088D | MITSUBISHI |
| MD097405 | MITSUBISHI |
| MD099624 | MITSUBISHI |
| MD102084 | MITSUBISHI |
| MD102085 | MITSUBISHI |
| MD102088 | MITSUBISHI |
| MD125096 | MITSUBISHI |
| 20100707 | PRESTOLITE |
| 436503 | VALEO |
| 437684 | VALEO |
| 600045 | VALEO |
| TA000A47001 | VALEO |
| ALTF535 | 3EFFE |
| CGB-13184 | AINDE |
| 002-C323 | ASHIKA |
| AEA7105 | AUTOELECTRO |
| CAL35150 | CASCO |
| CAL35150AS | CASCO |
| CAL35150ES | CASCO |
| CAL35150GS | CASCO |
| CAL35150OS | CASCO |
| CAL35150RS | CASCO |
| 9011 | CEVAM |
| 56449 | EAI |
| ALT5198 | ELECTROLOG |
| 28-1655 | ELSTOCK |
| AG0339 | GHIBAUDI |
| JA666IR | HC PARTS |
| ALC323 | JAPANPARTS |
| 2C323 | JAPKO |
| 40598RI | KUHNER |
| 40598RIR | KUHNER |
| 40666RI | KUHNER |
| 11.0666 | LAUBER |
| 445715 | LOGISTIK |
| LRA00705 | LUCAS |
| LRA705 | LUCAS |
| 155.503.065 | PSH |
| 20137051BN | REAL |
| 2035150 | SANDO |
| ALT341270 | SIOM |
| ALT6110 | SIOM |
| SA557 | SOVEREIGN |
| STX100638 | STARDAX |
| STX101149 | STARDAX |
| STX102057 | STARDAX |
| STX102075 | STARDAX |
| 13197R | WAI / TRANSPO |
| 13332N | WAI / TRANSPO |
| 90-27-3078 | WILSON |
| ALT31042 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A1617 | 60/65A | 75A | Yes |
| A0759 | 60-65A Pulley PV4/55 | 40-50A Pulley 1GR/52 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| MITSUBISHI | Eclipse | 1.8 (1755ccm) Petrol | 4G37OHC | MK I | D21A | 1989 - 1994 | |
| MITSUBISHI | Galant | 1.6 (1597ccm) Petrol | 4G32 | MK V | E11A | 1984 - 1987 | |
| MITSUBISHI | Galant | 1.6 (1597ccm) Petrol | 4G32 | MK VI | E31A | 1988 - 1989 | |
| MITSUBISHI | Galant | 1.8 (1755ccm) Petrol | 4G37 | MK VI | E32A | 1987 - 1990 | |
| MITSUBISHI | Galant | 1.8 (1755ccm) Petrol | 4G37 | MK VI | E32A | 1988 - 1992 | |
| MITSUBISHI | Lancer | 1.8 (1755ccm) Petrol | 4G37 | MK III | C77A | 1989 - 1992 | |
| MITSUBISHI | Lancer Estate/Wagon | 1.8 (1755ccm) Petrol | 4G37 | MK III | C37V | 1990 - 1992 | |
| MITSUBISHI | Space Wagon | 1.8 (1755ccm) Petrol | 4G37 | D05W | 1987 - 1988 |
Description
A0705 Replacement Alternator
The Sahibs A0705 alternator is associated with Lucas reference LRA00705 for replacement identification. The listed electrical rating is 12V 60A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Mitsubishi Eclipse 1.8 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 60A output: compare the listed rating with the original alternator.
- 4-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M5 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Mitsubishi Eclipse 1.8 Petrol – selected applications 1989–1994 (engine code 4G37OHC).
- Mitsubishi Galant 1.6 Petrol – selected applications 1984–1987 (engine code 4G32).
- Mitsubishi Lancer 1.8 Petrol – selected applications 1989–1992 (engine code 4G37).
- Mitsubishi Lancer Estate/Wagon 1.8 Petrol – selected applications 1990–1992 (engine code 4G37).
- Mitsubishi Space Wagon 1.8 Petrol – selected applications 1987–1988 (engine code 4G37).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0705. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986037731, 986037981, 436503, 437684, 600045, TA000A47001, LRA00705, LRA705, A002T09691, A002T48791, A00T48791ZC, A2T09691, A2T48791, A2T48791ZC, A2T49992, M102088D, MD097405, MD099624, MD102084, MD102085, MD102088, MD125096, 20100707
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0705 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0705 fit my Mitsubishi Eclipse?
Mitsubishi Eclipse 1.8 Petrol (1989–1994) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0705 replace Lucas LRA00705?
Lucas LRA00705 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0705?
The listed details include 12V, 60A output, 4 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A0705 new or remanufactured?
Check the current product condition selection for A0705. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0705?
Compare 12V compatibility, 60A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
