A0864 12V 40A Alternator Fits Peugeot 104, Peugeot 205, Citroën C15
Price range: £107.00 through £171.20
Sahibs A0864 is a replacement alternator with a listed 12V 40A rating. Listed applications include selected Peugeot 104, Peugeot 205, CitroËN C15, Talbot Samba models. Identification references include Lucas LRA00864, Bosch 9120144243, Valeo 2541477. Its listed 12V 40A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0864 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 40 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 42 mm |
| Mounting holes | 2 qty |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.7 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0864 | Dyno Electrics |
| 986031008 | Bosch Exchange |
| 986031980 | Bosch Exchange |
| 986031981 | Bosch Exchange |
| 986032070 | Bosch Exchange |
| 986032071 | Bosch Exchange |
| 986032760 | Bosch Exchange |
| 986032761 | Bosch Exchange |
| 11201255 | Mahle |
| 11201256 | Mahle |
| 14201173 | AES |
| 20437R | WAI |
| 225002070 | PSH |
| 2541477 | Valeo |
| 306005000 | Carrier |
| 306005002 | Carrier |
| 432754 | Valeo |
| 432768 | Valeo |
| 432804 | Valeo |
| 432809 | Valeo |
| 433036 | Valeo |
| 433355 | Valeo |
| 433356 | Valeo |
| 433359 | Valeo |
| 436373 | Valeo |
| 451036 | RNL |
| 570511 | PSA |
| 570554 | PSA |
| 5705Z1 | PSA |
| 7101798 | Carrier |
| 72735093 | Mahle |
| 7700590227 | Renault |
| 7701348200 | Renault |
| 7701349279 | Renault |
| 9120144243 | Bosch |
| 9120330723 | Bosch |
| 91514788 | PSA |
| 9151478880 | PSA |
| 91515434 | PSA |
| 943356132 | Magneti Marelli |
| 943356150 | Magneti Marelli |
| 943356160 | Magneti Marelli |
| 95495192 | PSA |
| 95619190 | PSA |
| 96619190 | PSA |
| 9AR2728F | Motorola |
| 9AR2728G | Motorola |
| A12R37 | Valeo |
| A12R9 | Valeo |
| A13N237 | Valeo |
| A13N94 | Valeo |
| A13R124 | Valeo |
| A13R143 | Valeo |
| A13R158 | Valeo |
| AAK4105 | Mahle |
| ALT14053 | Wood Auto |
| BSPALS12X28 | PSA |
| CA164IR | HC-Parts |
| CA176IR | HC-Parts |
| DRA1871 | Delco Remy |
| IA0256 | Mahle |
| LRA00188 | Lucas |
| LRA00287 | Lucas |
| LRA00763 | Lucas |
| LRA00864 | Lucas |
| LRA02328 | Lucas |
| LRA188 | Lucas |
| LRA2328 | Lucas |
| LRA287 | Lucas |
| LRA763 | Lucas |
| LRA864 | Lucas |
| MAHMG94 | Wood Auto |
| MAR397 | Magneti Marelli |
| MAR405 | Magneti Marelli |
| MAR406 | Magneti Marelli |
| MAR418 | Magneti Marelli |
| MG94 | Mahle |
| NA227 | Valeo |
| NA248 | Valeo |
| NA273 | Valeo |
| VA113 | Valeo |
| VA125 | Valeo |
| WOOALT14053 | Wood Auto |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A0445 | 40A Small version | 50A Large version | No |
| A0816 | 40A | 35A | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CITROËN | C15 | 1.4 (1360ccm) Petrol | XY7 | Service | VDPK | 1987 - 1987 | |
| PEUGEOT | 104 | 1.0 (954ccm) Petrol | XV5 | 549/A41/C01 | 1979 - 1983 | ||
| PEUGEOT | 104 | 1.0 (954ccm) Petrol | XV5 | C01/S01 | 1983 - 1985 | ||
| PEUGEOT | 104 | 1.1 (1124ccm) Petrol | XW3S | C11/C12 | 1975 - 1980 | ||
| PEUGEOT | 104 | 1.1 (1124ccm) Petrol | XW3 | C11/C12 | 1975 - 1983 | ||
| PEUGEOT | 104 | 1.1 (1124ccm) Petrol | XW3 | A11 | 1976 - 1982 | ||
| PEUGEOT | 104 | 1.1 (1124ccm) Petrol | XW7 | A11/A17/C11/C17/C42 | 1980 - 1988 | ||
| PEUGEOT | 104 | 1.4 (1360ccm) Petrol | XY6B | C11/C17 | 1979 - 1984 | ||
| PEUGEOT | 104 | 1.4 (1360ccm) Petrol | XY6B | A31/A37/C31 | 1979 - 1983 | ||
| PEUGEOT | 205 | 1.1 (1124ccm) Petrol | XW7 | 741A/741C | 1983 - 1987 | ||
| PEUGEOT | 205 | 1.4 (1360ccm) Petrol | XY6B | 20A/20C | 1987 - 1988 | ||
| TALBOT | Samba | 1.0 (954ccm) Petrol | XV5/XV8 | 51A591/51A601 | 1981 - 1985 | ||
| TALBOT | Samba | 1.1 (1124ccm) Petrol | XW7 | 51A611/51A702 | 1981 - 1986 | ||
| TALBOT | Samba | 1.2 (1219ccm) Petrol | XZ7R | 51A692 | 1983 - 1986 | ||
| TALBOT | Samba | 1.4 (1360ccm) Petrol | XY8 | 51E642 | 1981 - 1986 |
Description
A0864 Replacement Alternator
Choose a replacement by comparing the A0864 alternator and its Lucas reference, LRA00864, with your existing unit. The listed electrical rating is 12V 40A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Peugeot 104 1.0 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 40A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Peugeot 104 1.0 Petrol – selected applications 1979–1983 (engine code XV5).
- Peugeot 205 1.1 Petrol – selected applications 1983–1987 (engine code XW7).
- CitroËN C15 1.4 Petrol – selected applications 1987–1987 (engine code XY7).
- Talbot Samba 1.0 Petrol – selected applications 1981–1985 (engine code XV5/XV8).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0864. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986031008, 986031980, 986031981, 986032070, 986032071, 986032760, 986032761, 9120144243, 9120330723, 2541477, 432754, 432768, 432804, 432809, 433036, 433355, 433356, 433359, 436373, A12R37, A12R9, A13N237, A13N94, A13R124, A13R143, A13R158, NA227, NA248, NA273, VA113, VA125, LRA00864, LRA00188, LRA00287, LRA00763, LRA02328, LRA188, LRA2328, LRA287, LRA763, LRA864, DRA1871, 11201255, 11201256, 72735093, AAK4105, IA0256, MG94, 7700590227, 7701348200, 7701349279
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0864 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0864 fit my Peugeot 104?
Peugeot 104 1.0 Petrol (1979–1983) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0864 replace Lucas LRA00864?
Lucas LRA00864 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0864?
The listed details include 12V, 40A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0864 new or remanufactured?
Check the current product condition selection for A0864. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0864?
Compare 12V compatibility, 40A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
