A1124 12V 70A Alternator Fits Mazda 323, Mazda 323C, Mazda 323F
Price range: £106.26 through £135.52
Compare the A1124 12V 70A alternator from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Mazda 323, Mazda 323C, Mazda 323F, Mazda 323P models. Identification references include Lucas LRA01124, Bosch 986045551, Valeo 437650. Its listed 12V 70A rating provides an electrical matching point for your existing unit. Check the 4-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1124 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 70 A |
| Volt | 12 V |
| No. of Grooves | 4 qty |
| Pulley Diameter | 55 mm |
| Mounting holes | 3 qty |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.96 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1124 | Dyno Electrics |
| 401680191 | Euro Car Part |
| A5185 | AS-PL |
| UD90082A | AS-PL |
| 986045551 | BOSCH |
| 111384 | CARGO |
| F032111384 | CARGO |
| DRA3683 | DELCO |
| 8EL012429-601 | HELLA |
| 8EL737414-001 | HELLA |
| LR170-758 | HITACHI |
| MZ59918300A | HYUNDAI / KIA |
| B34P-18-300 | MAZDA |
| B34P-18-400 | MAZDA |
| B34P-18-400A | MAZDA |
| B34P18300A | MAZDA |
| B5D8-18-300A | MAZDA |
| BP4W-18-300 | MAZDA |
| BP4W-18-300C | MAZDA |
| Z599-18-300 | MAZDA |
| Z599-18-300A | MAZDA |
| Z599-18-300B | MAZDA |
| Z599-18-300C | MAZDA |
| Z599-18-300D | MAZDA |
| Z599-18-300E | MAZDA |
| Z599-18-300R | MAZDA |
| Z5A1-18-300 | MAZDA |
| A002TB0091 | MITSUBISHI |
| A002TB0091A | MITSUBISHI |
| A002TB0091AM | MITSUBISHI |
| A002TB0091B | MITSUBISHI |
| A002TB2391 | MITSUBISHI |
| A002TB6191 | MITSUBISHI |
| A002TB6192 | MITSUBISHI |
| A2TB0091 | MITSUBISHI |
| A2TB0091A | MITSUBISHI |
| A2TB0091AM | MITSUBISHI |
| A2TB0091B | MITSUBISHI |
| A2TB0091ZT | MITSUBISHI |
| A2TB2391 | MITSUBISHI |
| A2TB6191 | MITSUBISHI |
| A2TB6192 | MITSUBISHI |
| 20130234 | PRESTOLITE |
| 437650 | VALEO |
| ALTF003 | 3EFFE |
| ALTF881 | 3EFFE |
| ALTW291 | 3EFFE |
| ANM35903X | ANDEL |
| 002-M412 | ASHIKA |
| AEB1409 | AUTOELECTRO |
| CAL35143AS | CASCO |
| CAL35143GS | CASCO |
| 9325 | CEVAM |
| 57130 | EAI |
| ALT5132 | ELECTROLOG |
| 27-2853 | ELSTOCK |
| 209487 | ERA |
| 9051346 | FRIESEN |
| JA1283 | HC PARTS |
| JA1283IR | HC PARTS |
| ALM412 | JAPANPARTS |
| 2M412 | JAPKO |
| 401283 | KUHNER |
| 11.1283 | LAUBER |
| 446237 | LOGISTIK |
| LRA01124 | LUCAS |
| LRA1124 | LUCAS |
| 89212871 | POWERMAX |
| 9212871 | POWERMAX |
| 145.530.070 | PSH |
| 145.530.070.130 | PSH |
| 145.530.070.415 | PSH |
| 145.530.070.461 | PSH |
| 145.530.070.462 | PSH |
| 20137341BN | REAL |
| 20137341OE | REAL |
| 2035143 | SANDO |
| A12MH0356 | SIDAT |
| A12MH0356A2 | SIDAT |
| ALT371430 | SIOM |
| STX100143 | STARDAX |
| STX100143R | STARDAX |
| STX100255 | STARDAX |
| 13718N | WAI / TRANSPO |
| 13788N | WAI / TRANSPO |
| ALT31268 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A1143 | Placing of terminals | Placing of terminals | No |
| A1122 | 70A Placing of terminals, pulley alignment | 80A Placing of terminals, pulley alignment | No |
| A2925 | 70A Placing of terminals, pulley alignment | 80A Placing of terminals, pulley alignment | No |
| A2919 | Placing of terminals, pulley alignment | Placing of terminals, pulley alignment | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| MAZDA | 323 | 1.3 (1324ccm) Petrol | B32A/B3P7 | MK VII | BA1 | 1994 - 1998 | |
| MAZDA | 323 | 1.3 (1324ccm) Petrol | B33G | MK VIII | BJ12 | 1998 - 2001 | |
| MAZDA | 323 | 1.3 (1324ccm) Petrol | B35S | MK VIII | BJ12 | 2001 - 2004 | |
| MAZDA | 323 | 1.5 (1489ccm) Petrol | Z501 | MK VII | BA1 | 1996 - 1998 | |
| MAZDA | 323 | 1.5 (1498ccm) Petrol | ZL05/ZL06 | MK VIII | BJ12 | 1998 - 2001 | |
| MAZDA | 323C | 1.3 (1324ccm) Petrol | B3P7 | MK VII | BA1 | 1996 - 1998 | |
| MAZDA | 323C | 1.5 (1489ccm) Petrol | Z501 | MK VII | BA1 | 1996 - 1998 | |
| MAZDA | 323F | 1.3 (1324ccm) Petrol | B33G | MK VIII | Fastbreak | BJ14 | 1998 - 2001 |
| MAZDA | 323F | 1.3 (1324ccm) Petrol | B35S | MK VIII | Fastbreak | BJ14 | 2001 - 2004 |
| MAZDA | 323F | 1.5 (1489ccm) Petrol | Z501 | MK VII | BA1 | 1996 - 1998 | |
| MAZDA | 323F | 1.5 (1498ccm) Petrol | ZL05/ZL06 | MK VIII | Fastbreak | BJ14 | 1998 - 2001 |
| MAZDA | 323P | 1.5 (1489ccm) Petrol | Z501 | MK VII | Practical | BA1 | 1996 - 2001 |
| MAZDA | Demio | 1.5 (1498ccm) Petrol | B5E1/B5E2/B5E3/B5E4/B5F3/B5F5 | DW19 | 2000 - 2002 |
Description
A1124 Replacement Alternator
Start your A1124 alternator comparison with the linked Lucas reference LRA01124 and the specifications shown on this page. The listed electrical rating is 12V 70A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Mazda 323 1.3 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 70A output: compare the listed rating with the original alternator.
- 4-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Mazda 323 1.3 Petrol – selected applications 1994–1998 (engine code B32A/B3P7).
- Mazda 323C 1.3 Petrol – selected applications 1996–1998 (engine code B3P7).
- Mazda 323F 1.3 Petrol – selected applications 1998–2001 (engine code B33G).
- Mazda 323P 1.5 Petrol – selected applications 1996–2001 (engine code Z501).
- Mazda Demio 1.5 Petrol – selected applications 2000–2002 (engine code B5E1/B5E2/B5E3/B5E4/B5F3/B5F5).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1124. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986045551, 437650, LRA01124, LRA1124, A002TB0091, A002TB0091A, A002TB0091AM, A002TB0091B, A002TB2391, A002TB6191, A002TB6192, A2TB0091, A2TB0091A, A2TB0091AM, A2TB0091B, A2TB0091ZT, A2TB2391, A2TB6191, A2TB6192, LR170-758, LR170758, DRA3683, 20130234
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1124 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1124 fit my Mazda 323?
Mazda 323 1.3 Petrol (1994–1998) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1124 replace Lucas LRA01124?
Lucas LRA01124 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1124?
The listed details include 12V, 70A output, 4 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1124 new or remanufactured?
Check the current product condition selection for A1124. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1124?
Compare 12V compatibility, 70A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
