A1199 12V 28A Alternator Fits Claas Consul, Claas Dominator 56
Price range: £92.18 through £115.61
Identify a replacement alternator using Sahibs A1199, listed at 12V 28A. Listed applications include selected Claas Consul, Claas Dominator 56, Claas Dominator 66, Claas Mercator 50 models. Identification references include Lucas LRA01199, Bosch 120143003, Valeo 432994. Its listed 12V 28A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1199 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 28 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 55 mm |
| Mounting holes | 2 qty |
| Position | 180° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1199 | Dyno Electrics |
| UD12251A | AS-PL |
| 120143003 | BOSCH |
| 120300512 | BOSCH |
| 120300516 | BOSCH |
| 120300517 | BOSCH |
| 120300535 | BOSCH |
| 120300562 | BOSCH |
| 120339511 | BOSCH |
| 120339512 | BOSCH |
| 120339513 | BOSCH |
| 120339532 | BOSCH |
| 120339543 | BOSCH |
| 120339544 | BOSCH |
| 120339545 | BOSCH |
| 120400775 | BOSCH |
| 986030110 | BOSCH |
| 111649 | CARGO |
| F032111649 | CARGO |
| E019083A | CASE |
| 6005706662 | CLAAS |
| 7901820 | CLAAS |
| CT6005706662 | CLAAS |
| 19093094 | DELCO |
| DA1220 | DELCO |
| DRA0110 | DELCO |
| 11.201.119 | ISKRA / LETRIKA |
| 11.201.784 | ISKRA / LETRIKA |
| 11.209.641 | ISKRA / LETRIKA |
| 72520553 | ISKRA / LETRIKA |
| AAG1316 | ISKRA / LETRIKA |
| AAG1343 | ISKRA / LETRIKA |
| AAG1364 | ISKRA / LETRIKA |
| IA0784 | ISKRA / LETRIKA |
| AL28516 | JOHN DEERE |
| AL32141 | JOHN DEERE |
| AL35998 | JOHN DEERE |
| AL36100 | JOHN DEERE |
| AL62401 | JOHN DEERE |
| AR62401 | JOHN DEERE |
| AZ23314 | JOHN DEERE |
| AZ23575 | JOHN DEERE |
| AZ26910 | JOHN DEERE |
| TY6605 | JOHN DEERE |
| 72735437 | MAHLE |
| MG438 | MAHLE |
| 3165252M1 | MASSEY FERGUSON |
| 61542902 | MERCEDES |
| 6154290280 | MERCEDES |
| A0061542902 | MERCEDES |
| A006154290280 | MERCEDES |
| 432994 | VALEO |
| 436268 | VALEO |
| 9AL2969F | VALEO |
| 9AR2862K | VALEO |
| 9AR2968 | VALEO |
| 9AR2968K | VALEO |
| 6204754 | VOLVO |
| ALTL269 | 3EFFE |
| PRAL269 | 3EFFE |
| C00090001018 | AGCO |
| C000900010180 | AGCO |
| 51750 | AGRIA |
| CGB-10560 | AINDE |
| ANM32330X | ANDEL |
| CAL10159AS | CASCO |
| 2384 | CEVAM |
| 160-39102 | DIXIE |
| A-6107 | DIXIE |
| 75642 | EAI |
| ALT1953 | ELECTROLOG |
| ALT79187 | ELECTROLOG |
| 28-0730 | ELSTOCK |
| CA734IR | HC PARTS |
| ALB0734 | KRAUF |
| 30734RI | KUHNER |
| 30734RIM | KUHNER |
| 440881 | LOGISTIK |
| LRA01199 | LUCAS |
| LRA1199 | LUCAS |
| 5548957 | MEAT & DORIA |
| 6.06E+11 | MWM |
| 727549 | O&K |
| 555.001.033.010 | PSH |
| 555.001.033.098 | PSH |
| 555.001.033.099 | PSH |
| 555.001.033.311 | PSH |
| 20101951BN | REAL |
| 220-10143 | ROBERT'S |
| 294390300 | SAME |
| 294390700 | SAME |
| 294391700 | SAME |
| 2010159 | SANDO |
| A12BH0056A2 | SIDAT |
| STX100959 | STARDAX |
| STX101193 | STARDAX |
| 13194N | WAI / TRANSPO |
| ALT20029 | WOODAUTO |
| MAHMG438 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CLAAS | Consul | 0ccm Diesel | MB-OM314 | 1976 - 1978 | |||
| CLAAS | Consul | 0ccm Diesel | Ford 2712E | 1976 - 1978 | |||
| CLAAS | Consul | 0ccm Diesel | Perkins 4.236 | 1976 - 1978 | |||
| CLAAS | Dominator 56 | 0ccm Diesel | Perkins 4.248 | 1978 - 1982 | |||
| CLAAS | Dominator 66 | 0ccm Diesel | Perkins 6.354.4 | 1979 - 1985 | |||
| CLAAS | Mercator 50 | 0ccm Diesel | Ford 2712E | 1977 - 1981 | |||
| CLAAS | Mercator 60 | 0ccm Diesel | Ford 2715E | 1977 - 1981 | |||
| CLAAS | Mercator 60 | 0ccm Diesel | Perkins 6.354 | 1977 - 1981 | |||
| CLAAS | Mercator 75 | 0ccm Diesel | Ford 2715E | 1977 - 1982 | |||
| CLAAS | Mercator 75 | 0ccm Diesel | Perkins 6.354 | 1977 - 1981 | |||
| HATZ | HATZ | 4020ccm Diesel | |||||
| JOHN DEERE | 1040 | 0ccm Diesel | 3.179 DL-06 | 1979 - 1985 | |||
| JOHN DEERE | 1140 | 0ccm Diesel | 3.179 DL-01 | 1980 - 1985 | |||
| JOHN DEERE | 1630 | 0ccm Diesel | 3.179 DL-01 | 1975 - 1979 | |||
| JOHN DEERE | 1640 | 0ccm Diesel | 4.239 DL-03 | 1980 - 1985 | |||
| JOHN DEERE | 2040 | 0ccm Diesel | 4.239 DL-04 | 1980 - 1985 | |||
| JOHN DEERE | 2140 | 0ccm Diesel | 4.239 TL-02 | 1980 - 1985 | |||
| JOHN DEERE | 3040 | 0ccm Diesel | 6.359 DL-01 | 1980 - 1985 | |||
| JOHN DEERE | 3140 | 0ccm Diesel | 6.359 DL-03 | 1980 - 1985 | |||
| JOHN DEERE | 820 | 0ccm Diesel | 3.153 | 1979 - 1986 | |||
| JOHN DEERE | 840 | 0ccm Diesel | 3.179 DL-04 | 1980 - 1985 | |||
| JOHN DEERE | 925 Combine | 0ccm Diesel | 3.164 DZ-02 | 1974 - 1978 | |||
| JOHN DEERE | 935 Combine | 0ccm Diesel | 4.219 DZ-05 | 1975 - 1979 | |||
| JOHN DEERE | 940 | 0ccm Diesel | 3.179 DL-05 | 1980 - 1985 | |||
| JOHN DEERE | 945 Combine | 0ccm Diesel | 4.239 TZ-01 | 1975 - 1977 | |||
| JOHN DEERE | 952 Combine | 0ccm Diesel | 4.239 TZ-01 | 1977 - 1981 | |||
| JOHN DEERE | 955 Combine | 0ccm Diesel | 6.329 DZ-02 | 1975 - 1981 | |||
| JOHN DEERE | 965 Combine | 0ccm Diesel | 6.359 TZ-03 | 1975 - 1980 | |||
| JOHN DEERE | 975 Combine | 0ccm Diesel | 6.359 TZ-02 | 1975 - 1981 | |||
| LAMBORGHINI TRACTOR | R513 DT | 0ccm Diesel | 983L | 1983 - 1985 |
Description
A1199 Replacement Alternator
Choose a replacement by comparing the A1199 alternator and its Lucas reference, LRA01199, with your existing unit. The listed electrical rating is 12V 28A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Claas Consul variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 28A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Claas Consul – selected applications 1976–1978 (engine code MB-OM314).
- Claas Dominator 56 – selected applications 1978–1982 (engine code Perkins 4.248).
- Claas Dominator 66 – selected applications 1979–1985 (engine code Perkins 6.354.4).
- Claas Mercator 50 – selected applications 1977–1981 (engine code Ford 2712E).
- Claas Mercator 60 – selected applications 1977–1981 (engine code Ford 2715E).
- Claas Mercator 75 – selected applications 1977–1982 (engine code Ford 2715E).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1199. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120143003, 120300512, 120300516, 120300517, 120300535, 120300562, 120339511, 120339512, 120339513, 120339532, 120339543, 120339544, 120339545, 120400775, 986030110, 432994, 436268, 9AL2969F, 9AR2862K, 9AR2968, 9AR2968K, LRA01199, LRA1199, 19093094, DA1220, DRA0110, 72735437, MG438, 11.201.119, 11.201.784, 11.209.641, 72520553, AAG1316, AAG1343, AAG1364, IA0784, 3165252M1
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1199 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1199 fit my Claas Consul?
Claas Consul (1976–1978) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1199 replace Lucas LRA01199?
Lucas LRA01199 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1199?
The listed details include 12V, 28A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A1199 new or remanufactured?
Check the current product condition selection for A1199. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1199?
Compare 12V compatibility, 28A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
