A1313 12V 50A Alternator Fits Daihatsu Charade, Daihatsu Gran Move
Price range: £142.60 through £157.00
Compare the A1313 12V 50A alternator from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Daihatsu Charade, Daihatsu Gran Move, Daihatsu Pyzar, Daihatsu Valera models. Identification references include Lucas LRA01313, Denso 100211-1520. Its listed 12V 50A rating provides an electrical matching point for your existing unit. Check the 4-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1313 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 50 A |
| Volt | 12 V |
| No. of Grooves | 4 qty |
| Pulley Diameter | 50 mm |
| Mounting holes | 2 qty |
| Position | 0° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1313 | Dyno Electrics |
| 401560071 | Euro Car Part |
| UD102873A | AS-PL |
| 111610 | CARGO |
| F032111610 | CARGO |
| 27060-87606 | DAIHATSU |
| 27060-87606-000 | DAIHATSU |
| 27060-87607 | DAIHATSU |
| 27060-87607-000 | DAIHATSU |
| 100211-1520 | DENSO |
| 100211-6990 | DENSO |
| 101211-2100 | DENSO |
| 101211-2270 | DENSO |
| 101211-3050 | DENSO |
| 101211-3200 | DENSO |
| DAN969 | DENSO |
| 8EL012241-021 | HELLA |
| 63377508010 | MAGNETI MARELLI |
| MAN7508 | MAGNETI MARELLI |
| 27060-87604 | TOYOTA |
| 27060-87605 | TOYOTA |
| 27060-87608 | TOYOTA |
| 27060-87714 | TOYOTA |
| 27060-87721 | TOYOTA |
| ALTF595 | 3EFFE |
| PRAF595 | 3EFFE |
| 10441933 | ALANKO |
| ANM35613 | ANDEL |
| ADN119A | AUTOTEAM |
| G101470 | BTS TURBO |
| CAL40119AS | CASCO |
| 9138 | CEVAM |
| 217110452 | DRI |
| 56431 | EAI |
| ALT6198 | ELECTROLOG |
| 28-1641 | ELSTOCK |
| 111277 | FARCOM |
| 3110206 | HENKEL PARTS |
| 3110207 | HENKEL PARTS |
| J5116019 | HERTH+BUSS |
| 20040119AV | ITAB AUTOMOTIVE |
| ALN1121 | KRAUF |
| 40764RI | KUHNER |
| LRA01313 | LUCAS |
| LRA1313 | LUCAS |
| D511U27 | NPS |
| 89215621 | POWERMAX |
| IR6917 | PROTECH |
| 115.513.050.050 | PSH |
| 115.513.050.260 | PSH |
| 20132911BN | REAL |
| 2040119 | SANDO |
| ALT421190A | SIOM |
| DH8016 | SNRA |
| 431ST65 | STARTCAR |
| AL00838 | TMI |
| 13414N | WAI / TRANSPO |
| WG1916938 | WILMINK GROUP |
| ALT30113 | WOOD AUTO |
| ALT30671 | WOOD AUTO |
| WOOALT30113 | WOOD AUTO |
| WOOALT30671 | WOOD AUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0442 | Pulley PV4 OD52 Plug 13 | Pulley 1 Groove OD62 Plug 8 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| DAIHATSU | Charade | 1.3 (1295ccm) Petrol | HCE | MK III | G102 | 1988 - 1990 | |
| DAIHATSU | Charade | 1.3 (1295ccm) Petrol | HCE | MK IV | G200 | 1993 - 2000 | |
| DAIHATSU | Charade | 1.3 (1295ccm) Petrol | HCU | MK IV | G200 | 1996 - 1999 | |
| DAIHATSU | Charade | 1.3 (1295ccm) Petrol | HCU | MK IV | G200 | 1997 - 1999 | |
| DAIHATSU | Charade | 1.5 (1499ccm) Petrol | HEE/HEEG | MK IV | G203 | 1994 - 1999 | |
| DAIHATSU | Charade | 1.5 (1499ccm) Petrol | HEE | MK IV | G203 | 1994 - 2001 | |
| DAIHATSU | Charade | 1.6 (1589ccm) Petrol | HDE | MK IV | G201 | 1993 - 1996 | |
| DAIHATSU | Gran Move | 1.5 (1499ccm) Petrol | HEEG | G303 | 1996 - 1998 | ||
| DAIHATSU | Gran Move | 1.5 (1499ccm) Petrol | HEEG | G303 | 1996 - 1999 | ||
| DAIHATSU | Pyzar | 1.5 (1499ccm) Petrol | HEEG | G303 | 1997 - 1998 | ||
| DAIHATSU | Valera | 1.5 (1499ccm) Petrol | HEE/HEEG | MK IV | G203 | 1994 - 1999 |
Description
A1313 Replacement Alternator
The A1313 alternator is a replacement unit identified by Lucas reference LRA01313. The listed electrical rating is 12V 50A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Daihatsu Charade 1.3 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 50A output: compare the listed rating with the original alternator.
- 4-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Daihatsu Charade 1.3 Petrol – selected applications 1988–1990 (engine code HCE).
- Daihatsu Gran Move 1.5 Petrol – selected applications 1996–1998 (engine code HEEG).
- Daihatsu Pyzar 1.5 Petrol – selected applications 1997–1998 (engine code HEEG).
- Daihatsu Valera 1.5 Petrol – selected applications 1994–1999 (engine code HEE/HEEG).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1313. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
100211-1520, 100211-6990, 101211-2100, 101211-2270, 101211-3050, 101211-3200, DAN969, LRA01313, LRA1313
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1313 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1313 fit my Daihatsu Charade?
Daihatsu Charade 1.3 Petrol (1988–1990) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1313 replace Lucas LRA01313?
Lucas LRA01313 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1313?
The listed details include 12V, 50A output, 4 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1313 new or remanufactured?
Check the current product condition selection for A1313. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1313?
Compare 12V compatibility, 50A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
