A1511 12V 110A Alternator Fits Case I.H. 7110 Magnum
Price range: £149.21 through £195.12
Sahibs A1511 is a replacement alternator with a listed 12V 110A rating. Listed applications include selected Case IH 7110 Magnum, Case IH 7120 Magnum, Case IH 7130 Magnum, Case IH 7140 Magnum models. Identification references include Lucas LRA01511, Bosch 120468028, Delco Remy DRA3793. Its listed 12V 110A rating provides an electrical matching point for your existing unit. Check the 8-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1511 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 110 A |
| Volt | 12 V |
| No. of Grooves | 8 qty |
| Pulley Diameter | 68.5 mm |
| Mounting holes | 3 qty |
| Position | 180° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 7.49 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1511 | Dyno Electrics |
| A0112 | AS-PL |
| 120468028 | BOSCH |
| 120468055 | BOSCH |
| 986043480 | BOSCH |
| 112000 | CARGO |
| F032112000 | CARGO |
| 125849A1 | CASE |
| 202360T91 | CASE |
| 91448C2 | CASE |
| DRA3793 | DELCO |
| 605576460 | FIAT |
| 8EL737561-001 | HELLA |
| 860567 | PRESTOLITE |
| ALTS662 | 3EFFE |
| ALTS797 | 3EFFE |
| ALTS797L | 3EFFE |
| PRAS662 | 3EFFE |
| CGB-13793 | AINDE |
| CAL10162AS | CASCO |
| 2429 | CEVAM |
| 75918 | EAI |
| ALT1254 | ELECTROLOG |
| ALT1435 | ELECTROLOG |
| 28-2578 | ELSTOCK |
| CA1381IR | HC PARTS |
| 301381RI | KUHNER |
| 553311RI | KUHNER |
| 11.1381 | LAUBER |
| 18.1381 | LAUBER |
| 18.1381M | LAUBER |
| 441983 | LOGISTIK |
| LRA01511 | LUCAS |
| LRA1511 | LUCAS |
| PTC-3070 | POWER TRUCK |
| 89213516 | POWERMAX |
| 20101261BN | REAL |
| 310791 | RHIAG |
| 2010162 | SANDO |
| A12BH1056A2 | SIDAT |
| ALT121620 | SIOM |
| ALT121620A | SIOM |
| STX110046 | STARDAX |
| 12162N | WAI / TRANSPO |
| ALT10237 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A3294 | 110A | 135A | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CASE I.H. | 7110 Magnum | 8277ccm Diesel | 6T-830 | 1988 - 1994 | |||
| CASE I.H. | 7120 Magnum | 8277ccm Diesel | 6T-830 | 1988 - 1994 | |||
| CASE I.H. | 7130 Magnum | 8277ccm Diesel | 6T-830 | 1988 - 1994 | |||
| CASE I.H. | 7140 Magnum | 8277ccm Diesel | 6TA-830 | 1988 - 1994 |
Description
A1511 Replacement Alternator
Start your A1511 alternator comparison with the linked Lucas reference LRA01511 and the specifications shown on this page. The listed electrical rating is 12V 110A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Case IH 7110 Magnum 8277ccm Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 110A output: compare the listed rating with the original alternator.
- 8-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Case IH 7110 Magnum 8277ccm Diesel – selected applications 1988–1994 (engine code 6T-830).
- Case IH 7120 Magnum 8277ccm Diesel – selected applications 1988–1994 (engine code 6T-830).
- Case IH 7130 Magnum 8277ccm Diesel – selected applications 1988–1994 (engine code 6T-830).
- Case IH 7140 Magnum 8277ccm Diesel – selected applications 1988–1994 (engine code 6TA-830).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1511. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120468028, 120468055, 986043480, LRA01511, LRA1511, DRA3793, 860567
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1511 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1511 fit my Case IH 7110 Magnum?
Case IH 7110 Magnum 8277ccm Diesel (1988–1994) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1511 replace Lucas LRA01511?
Lucas LRA01511 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1511?
The listed details include 12V, 110A output, 8 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1511 new or remanufactured?
Check the current product condition selection for A1511. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1511?
Compare 12V compatibility, 110A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
