A1648 12V 90A Alternator Fits Hyundai H1, Hyundai H200
Price range: £116.89 through £156.46
The A1648 12V 90A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Hyundai H1, Hyundai H200, Hyundai Starex, Mitsubishi L200 models. Identification references include Lucas LRA01648, Bosch 986045561, Mitsubishi Electric 1800A005. Its listed 12V 90A rating provides an electrical matching point for your existing unit. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1648 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 90 A |
| Volt | 12 V |
| No. of Grooves | 2 qty |
| Pulley Diameter | 51 mm |
| Mounting holes | 3 qty |
| Position | 20° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | Yes |
| Start/Stop | No |
| Weight | 7.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1648 | Dyno Electrics |
| 401690371 | Euro Car Part |
| A5003 | AS-PL |
| 986045561 | BOSCH |
| 986049930 | BOSCH |
| F042303112 | BOSCH |
| F042A03112 | BOSCH |
| F042A0H086 | BOSCH |
| 112205 | CARGO |
| F032112205 | CARGO |
| DRA3869 | DELCO |
| 8EL737675-001 | HELLA |
| 1800A005 | MITSUBISHI |
| A002T82899 | MITSUBISHI |
| A002T82899A | MITSUBISHI |
| A002T82899AT | MITSUBISHI |
| A002T82899ZT | MITSUBISHI |
| A002TN0499 | MITSUBISHI |
| A002TN0499AT | MITSUBISHI |
| A002TN0499ZT | MITSUBISHI |
| A003TN0699 | MITSUBISHI |
| A003TN0699A | MITSUBISHI |
| A003TN0699AM | MITSUBISHI |
| A003TN0899 | MITSUBISHI |
| A003TN1199 | MITSUBISHI |
| A2T82899 | MITSUBISHI |
| A2T82899A | MITSUBISHI |
| A2T82899AT | MITSUBISHI |
| A2T82899ZT | MITSUBISHI |
| A2TN0499 | MITSUBISHI |
| A2TN0499AT | MITSUBISHI |
| A2TN0499ZT | MITSUBISHI |
| A3TN0699 | MITSUBISHI |
| A3TN0699A | MITSUBISHI |
| A3TN0699AM | MITSUBISHI |
| A3TN0899 | MITSUBISHI |
| A3TN1199 | MITSUBISHI |
| MD230359 | MITSUBISHI |
| MD306649 | MITSUBISHI |
| MD313939 | MITSUBISHI |
| MD320354 | MITSUBISHI |
| MD334176 | MITSUBISHI |
| MD335227 | MITSUBISHI |
| MD366050 | MITSUBISHI |
| MN137866 | MITSUBISHI |
| MN137867 | MITSUBISHI |
| 20110236 | PRESTOLITE |
| ALTL049 | 3EFFE |
| PRAL049 | 3EFFE |
| CGB-13869 | AINDE |
| ANM36089X | ANDEL |
| AAL1750 | APEC |
| 002-C980 | ASHIKA |
| AEB1419 | AUTOELECTRO |
| STA0249 | BOVEZ |
| STA0249R | BOVEZ |
| CAL35110AS | CASCO |
| CAL35110GS | CASCO |
| 9341 | CEVAM |
| 11.1419 | CQ |
| 56953 | EAI |
| ALT5428 | ELECTROLOG |
| 28-2848 | ELSTOCK |
| 210114 | ERA |
| JA1419IR | HC PARTS |
| ALC980 | JAPANPARTS |
| 2C980 | JAPKO |
| ALM1419 | KRAUF |
| 401419RI | KUHNER |
| 401419RIV | KUHNER |
| 446468 | LOGISTIK |
| LRA01648 | LUCAS |
| LRA1648 | LUCAS |
| 5535132 | MEAT & DORIA |
| NPANAL1750 | NAPA |
| 89213908 | POWERMAX |
| 155.604.090.130 | PSH |
| 155.604.090.360 | PSH |
| 20137011BN | REAL |
| 20137011OE | REAL |
| RNL980CA | RNL |
| 2035110 | SANDO |
| 2035110.1 | SANDO |
| A12MH0044A2 | SIDAT |
| ALT6240 | SIOM |
| ALT6320 | SIOM |
| STX100123 | STARDAX |
| STX100123R | STARDAX |
| STX100173 | STARDAX |
| STX100173R | STARDAX |
| STX100432 | STARDAX |
| STX101598 | STARDAX |
| 12667N | WAI / TRANSPO |
| 12667RW | WAI / TRANSPO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A2006 | 90A Placing of terminals | 75A Placing of terminals | No |
| A2002 | Placing of terminals | Placing of terminals | No |
| A1913 | Placing of terminals | Placing of terminals | No |
| A2714 | 90A | 65A | No |
| A3151 | 90A | 105A | Yes |
| B0236 | 90A | 75A | No |
| A1918 | 90A Placing of terminals | 65A Placing of terminals | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| HYUNDAI | H1 | 2.5 (2476ccm) Diesel | D4BH | A1 | 2000 - 2006 | ||
| HYUNDAI | H1 | 2.5 (2476ccm) Diesel | D4BH | A1 | 2004 - 2007 | ||
| HYUNDAI | H200 | 2.5 (2476ccm) Diesel | D4BH | A1 | 2001 - 2004 | ||
| HYUNDAI | Starex | 2.5 (2476ccm) Diesel | D4BH | A1 | 2000 - 2007 | ||
| MITSUBISHI | L200 | 2.5 (2477ccm) Diesel | 4D56(SOHC8VPENA) | K64T | 1996 - 2005 | ||
| MITSUBISHI | Montero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24W/V44W | 1993 - 2000 | |
| MITSUBISHI | Montero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24C | 1993 - 2000 | |
| MITSUBISHI | Pajero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24C | 1993 - 2000 | |
| MITSUBISHI | Pajero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24W/V44W | 1993 - 1999 | |
| MITSUBISHI | Shogun | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24W/V44W | 1993 - 2000 | |
| MITSUBISHI | Strakar | 2.5 (2477ccm) Diesel | 4D56(SOHC8VPENA) | K64T | 1996 - 2001 |
Description
A1648 Replacement Alternator
Start your A1648 alternator comparison with the linked Lucas reference LRA01648 and the specifications shown on this page. The listed electrical rating is 12V 90A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Hyundai H1 2.5 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 90A output: compare the listed rating with the original alternator.
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Hyundai H1 2.5 Diesel – selected applications 2000–2006 (engine code D4BH).
- Hyundai H200 2.5 Diesel – selected applications 2001–2004 (engine code D4BH).
- Hyundai Starex 2.5 Diesel – selected applications 2000–2007 (engine code D4BH).
- Mitsubishi L200 2.5 Diesel – selected applications 1996–2005 (engine code 4D56(SOHC8VPENA)).
- Mitsubishi Montero 2.5 Diesel – selected applications 1993–2000 (engine code 4D56).
- Mitsubishi Pajero 2.5 Diesel – selected applications 1993–2000 (engine code 4D56).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1648. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986045561, 986049930, F042303112, F042A03112, F042A0H086, LRA01648, LRA1648, 1800A005, A002T82899, A002T82899A, A002T82899AT, A002T82899ZT, A002TN0499, A002TN0499AT, A002TN0499ZT, A003TN0699, A003TN0699A, A003TN0699AM, A003TN0899, A003TN1199, A2T82899, A2T82899A, A2T82899AT, A2T82899ZT, A2TN0499, A2TN0499AT, A2TN0499ZT, A3TN0699, A3TN0699A, A3TN0699AM, A3TN0899, A3TN1199, MD230359, MD306649, MD313939, MD320354, MD334176, MD335227, MD366050, MN137866, MN137867, DRA3869, 20110236
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1648 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1648 fit my Hyundai H1?
Hyundai H1 2.5 Diesel (2000–2006) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1648 replace Lucas LRA01648?
Lucas LRA01648 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1648?
The listed details include 12V, 90A output, 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1648 new or remanufactured?
Check the current product condition selection for A1648. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1648?
Compare 12V compatibility, 90A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
