A4543 12V 105A Alternator Fits Fiat 500, Fiat 500C, Fiat Panda
Price range: £119.59 through £160.07
Sahibs A4543 is a replacement alternator with a listed 12V 105A rating. Listed applications include selected Fiat 500, Fiat 500C, Fiat Panda, Fiat Panda Van models. Identification references include Lucas LRA04543. Its listed 12V 105A rating provides an electrical matching point for your existing unit. Check the 5-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A4543 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 105 A |
| Volt | 12 V |
| No. of Grooves | 5 qty |
| Pulley Diameter | 54 mm |
| Mounting holes | 3 qty |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA4543 | Dyno Electrics |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A3659 | 105A | 120A | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| FIAT | 500 | 0.9 (875ccm) Petrol | 312A5000 | 312AXN1A | 2013 - | ||
| FIAT | 500C | 0.9 (875ccm) Petrol | 312A5000 | 312AXN11/312AXN1A | 2013 - | ||
| FIAT | Panda | 0.9 (875ccm) CNG (with or without Petrol) | 312A2000/46337566 | 312PXG1A/312PYC1A | 2012 - | ||
| FIAT | Panda | 0.9 (875ccm) CNG (with or without Petrol) | 312A2000CNG | 312PXN1A | 2015 - | ||
| FIAT | Panda | 0.9 (875ccm) CNG (with or without Petrol) | 46337566 | 312PXN1A | 2019 - | ||
| FIAT | Panda | 0.9 (875ccm) Petrol | 312A2000 | 312PXG1A | 2012 - | ||
| FIAT | Panda | 0.9 (875ccm) Petrol | 312A2000 | Trekking | 312PXG1A | 2012 - | |
| FIAT | Panda | 0.9 (875ccm) Petrol | 312A5000 | 312PXN11/312PXN1A | 2013 - | ||
| FIAT | Panda | 0.9 (875ccm) Petrol | 312A7000 | Cross | 312PXR2B | 2014 - | |
| FIAT | Panda Van | 0.9 (875ccm) CNG (with or without Petrol) | 312A2000CNG | 312PXG1A | 2013 - | ||
| FIAT | Panda Van | 0.9 (875ccm) CNG (with or without Petrol) | 312A2000CNG | 312PXN1A | 2015 - | ||
| FIAT | Panda Van | 0.9 (875ccm) Petrol | 312A2000 | 312DXG1A | 2012 - | ||
| FIAT | Panda Van | 0.9 (875ccm) Petrol | 312A2000 | 312PXG1A | 2013 - | ||
| FIAT | Panda Van | 0.9 (875ccm) Petrol | 312A2000 | 312PXN1A | 2013 - | ||
| FIAT | Punto Van | 0.9 (875ccm) Petrol | 312A2000 | 199AYA1B | 2012 - | ||
| LANCIA | Ypsilon | 0.9 (875ccm) CNG (with or without Petrol) | 312A2000CNG | 312YXG1A | 2011 - | ||
| LANCIA | Ypsilon | 0.9 (875ccm) CNG (with or without Petrol) | 312A5000CNG | 312YXN1A | 2014 - | ||
| LANCIA | Ypsilon | 0.9 (875ccm) Petrol | 312A5000 | 312YXN1A | 2013 - 2018 |
Description
A4543 Replacement Alternator
The Sahibs A4543 alternator is associated with Lucas reference LRA04543 for replacement identification. The listed electrical rating is 12V 105A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Fiat 500 0.9 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 105A output: compare the listed rating with the original alternator.
- 5-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Fiat 500 0.9 Petrol – selected applications 2013 – (engine code 312A5000).
- Fiat 500C 0.9 Petrol – selected applications 2013 – (engine code 312A5000).
- Fiat Panda 0.9 CNG (with or without Petrol) – selected applications 2012 – (engine code 312A2000/46337566).
- Fiat Panda Van 0.9 CNG (with or without Petrol) – selected applications 2013 – (engine code 312A2000CNG).
- Fiat Punto Van 0.9 Petrol – selected applications 2012 – (engine code 312A2000).
- Lancia Ypsilon 0.9 CNG (with or without Petrol) – selected applications 2011 – (engine code 312A2000CNG).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A4543. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
LRA04543
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A4543 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A4543 fit my Fiat 500?
Fiat 500 0.9 Petrol (2013 -) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A4543 replace Lucas LRA04543?
Lucas LRA04543 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A4543?
The listed details include 12V, 105A output, 5 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A4543 new or remanufactured?
Check the current product condition selection for A4543. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A4543?
Compare 12V compatibility, 105A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
