B0236 12V 75A Alternator Fits Mitsubishi L200, Mitsubishi L300
Price range: £103.70 through £138.79
Sahibs B0236 is a replacement alternator with a listed 12V 75A rating. Listed applications include selected Mitsubishi L200, Mitsubishi L300, Mitsubishi L400, Mitsubishi Montero models. Identification references include Lucas LRB00236, Bosch 986042291, Valeo 437706. Its listed 12V 75A rating provides an electrical matching point for your existing unit. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0236 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 75 A |
| Volt | 12 V |
| No. of Grooves | 2 qty |
| Pulley Diameter | 56 mm |
| Mounting holes | 3 qty |
| Position | 20° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | Yes |
| Start/Stop | No |
| Weight | 6.5 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0236 | Dyno Electrics |
| 401691041 | Euro Car Part |
| A5072 | AS-PL |
| UD10985A | AS-PL |
| 986042291 | BOSCH |
| 986045571 | BOSCH |
| 112128 | CARGO |
| F032112128 | CARGO |
| DA4584 | DELCO |
| DA4584N | DELCO |
| DA5336 | DELCO |
| DRA3474 | DELCO |
| DRA3474N | DELCO |
| DRA4226 | DELCO |
| RAA14585 | DELCO |
| 8EL011711-091 | HELLA |
| 8EL737375-001 | HELLA |
| 63731271010 | MAGNETI MARELLI |
| 9.44E+11 | MAGNETI MARELLI |
| MQA1271 | MAGNETI MARELLI |
| MRA42291 | MAGNETI MARELLI |
| A002T1199AT | MITSUBISHI |
| A002T82899 | MITSUBISHI |
| A002T82899A | MITSUBISHI |
| A002T82899AM | MITSUBISHI |
| A002TN1199 | MITSUBISHI |
| A002TN1199A | MITSUBISHI |
| A002TN1199AM | MITSUBISHI |
| A002TN1199AT | MITSUBISHI |
| A002TN1199ZT | MITSUBISHI |
| A003T15099 | MITSUBISHI |
| A003T82899 | MITSUBISHI |
| A003TN0299 | MITSUBISHI |
| A003TN0399 | MITSUBISHI |
| A003TN0499 | MITSUBISHI |
| A003TN0999 | MITSUBISHI |
| A2T1199AT | MITSUBISHI |
| A2T82899 | MITSUBISHI |
| A2T82899A | MITSUBISHI |
| A2T82899AM | MITSUBISHI |
| A2TN1199 | MITSUBISHI |
| A2TN1199A | MITSUBISHI |
| A2TN1199AM | MITSUBISHI |
| A2TN1199AT | MITSUBISHI |
| A2TN1199ZT | MITSUBISHI |
| A3T15099 | MITSUBISHI |
| A3T82899 | MITSUBISHI |
| A3TN0299 | MITSUBISHI |
| A3TN0399 | MITSUBISHI |
| A3TN0499 | MITSUBISHI |
| A3TN0999 | MITSUBISHI |
| MD306649 | MITSUBISHI |
| MD306834 | MITSUBISHI |
| MD313940 | MITSUBISHI |
| MD313942 | MITSUBISHI |
| MD315432 | MITSUBISHI |
| MD327514 | MITSUBISHI |
| MD332547 | MITSUBISHI |
| MD366050 | MITSUBISHI |
| MD366051 | MITSUBISHI |
| 437706 | VALEO |
| 600054 | VALEO |
| ALTL702 | 3EFFE |
| PRAL702 | 3EFFE |
| ANM36446 | ANDEL |
| STA0499R | BOVEZ |
| CAL35101AS | CASCO |
| CAL35101GS | CASCO |
| 9372 | CEVAM |
| 56718 | EAI |
| 28-2844 | ELSTOCK |
| 210018 | ERA |
| AG0400 | GHIBAUDI |
| JA1271IR | HC PARTS |
| J5110501 | HERTH+BUSS |
| ALM1271 | KRAUF |
| 401271RI | KUHNER |
| 401271RIL | KUHNER |
| 401271RIV | KUHNER |
| LRB00236 | LUCAS |
| LRB236 | LUCAS |
| 89212236 | POWERMAX |
| 155.604.065.130 | PSH |
| 155.604.065.360 | PSH |
| 155.604.065.370 | PSH |
| 155.604.075.130 | PSH |
| 155.604.075.360 | PSH |
| 155.604.075.780 | PSH |
| 20137101BN | REAL |
| 20137101OE | REAL |
| 311788 | RHIAG |
| 2035101 | SANDO |
| 2035101.1 | SANDO |
| A12MH1144A2 | SIDAT |
| STX100103 | STARDAX |
| STX100103R | STARDAX |
| STX100173 | STARDAX |
| STX100173R | STARDAX |
| STX100786 | STARDAX |
| STX101598 | STARDAX |
| ALT31078 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A2714 | 75A | 65A | No |
| A2205 | 75A 100MM distance between center and M8 thread | 75A 90MM distance between center and M8 thread | No |
| A1717 | 75A Pulley 2GR/77 | 80A Pulley 2GR/72 | No |
| A2002 | 75A Placing of terminals | 90A Placing of terminals | No |
| A1648 | 75A | 90A | Yes |
| A1918 | 75A Placing of terminals | 65A Placing of terminals | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| MITSUBISHI | L200 | 2.5 (2477ccm) Diesel | 4D56(SOHC8VPENA) | K64T | 1996 - 2005 | ||
| MITSUBISHI | L300 | 2.5 (2477ccm) Diesel | 4D56(SOHC8VPENA) | P05V/P15V | 1986 - 2013 | ||
| MITSUBISHI | L400 | 2.5 (2477ccm) Diesel | 4D56 | PA5W | 1995 - 2000 | ||
| MITSUBISHI | L400 | 2.5 (2477ccm) Diesel | 4D56 | PD5W | 1995 - 2000 | ||
| MITSUBISHI | Montero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24C | 1993 - 2000 | |
| MITSUBISHI | Montero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24W/V44W | 1993 - 2000 | |
| MITSUBISHI | Pajero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24C | 1993 - 2000 | |
| MITSUBISHI | Pajero | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24W/V44W | 1993 - 1999 | |
| MITSUBISHI | Shogun | 2.5 (2477ccm) Diesel | 4D56 | MK II | V24W/V44W | 1993 - 2000 | |
| MITSUBISHI | Strakar | 2.5 (2477ccm) Diesel | 4D56(SOHC8VPENA) | K64T | 1996 - 2001 |
Description
B0236 Replacement Alternator
For a B0236 alternator enquiry, use Lucas reference LRB00236 alongside the vehicle and original unit details. The listed electrical rating is 12V 75A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Mitsubishi L200 2.5 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 75A output: compare the listed rating with the original alternator.
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Mitsubishi L200 2.5 Diesel – selected applications 1996–2005 (engine code 4D56(SOHC8VPENA)).
- Mitsubishi L300 2.5 Diesel – selected applications 1986–2013 (engine code 4D56(SOHC8VPENA)).
- Mitsubishi L400 2.5 Diesel – selected applications 1995–2000 (engine code 4D56).
- Mitsubishi Montero 2.5 Diesel – selected applications 1993–2000 (engine code 4D56).
- Mitsubishi Pajero 2.5 Diesel – selected applications 1993–2000 (engine code 4D56).
- Mitsubishi Shogun 2.5 Diesel – selected applications 1993–2000 (engine code 4D56).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0236. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986042291, 986045571, 437706, 600054, LRB00236, LRB236, A002T1199AT, A002T82899, A002T82899A, A002T82899AM, A002TN1199, A002TN1199A, A002TN1199AM, A002TN1199AT, A002TN1199ZT, A003T15099, A003T82899, A003TN0299, A003TN0399, A003TN0499, A003TN0999, A2T1199AT, A2T82899, A2T82899A, A2T82899AM, A2TN1199, A2TN1199A, A2TN1199AM, A2TN1199AT, A2TN1199ZT, A3T15099, A3T82899, A3TN0299, A3TN0399, A3TN0499, A3TN0999, MD306649, MD306834, MD313940, MD313942, MD315432, MD327514, MD332547, MD366050, MD366051, DA4584, DA4584N, DA5336, DRA3474, DRA3474N, DRA4226, RAA14585
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0236 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0236 fit my Mitsubishi L200?
Mitsubishi L200 2.5 Diesel (1996–2005) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0236 replace Lucas LRB00236?
Lucas LRB00236 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0236?
The listed details include 12V, 75A output, 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0236 new or remanufactured?
Check the current product condition selection for B0236. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0236?
Compare 12V compatibility, 75A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
