B0305 12V 65A Alternator Fits Case 580SK Loader, Hesston HESSTON
Price range: £79.75 through £106.74
The B0305 12V 65A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Case 580SK Loader, Case IH 5130 Maxxum, Case IH 5140 Maxxum, Case IH 5150 Maxxum models. Identification references include Lucas LRB00305, Bosch 120488205, Delco Remy DRB0290. Its listed 12V 65A rating provides an electrical matching point for your existing unit. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0305 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 65 A |
| Volt | 12 V |
| No. of Grooves | 2 qty |
| Pulley Diameter | 60 mm |
| Mounting holes | 2 qty |
| Position | 180° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.8 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0305 | Dyno Electrics |
| A0018 | AS-PL |
| 120488205 | BOSCH |
| 120488293 | BOSCH |
| 120489475 | BOSCH |
| 986040290 | BOSCH |
| F005A00023 | BOSCH |
| 111888 | CARGO |
| F032111888 | CARGO |
| 47977898 | CASE |
| A181873 | CASE |
| A186125 | CASE |
| A187873 | CASE |
| 3E7285 | CATERPILLAR |
| 3604448RX | CUMMINS |
| 3911248 | CUMMINS |
| 3920679 | CUMMINS |
| 39206791 | CUMMINS |
| DRB0290 | DELCO |
| 8EL737217-001 | HELLA |
| 11.201.595 | ISKRA / LETRIKA |
| 11.201.935 | ISKRA / LETRIKA |
| AAK1363 | ISKRA / LETRIKA |
| AAK3330 | ISKRA / LETRIKA |
| IA0595 | ISKRA / LETRIKA |
| AT173624 | JOHN DEERE |
| RE509106 | JOHN DEERE |
| RE533516 | JOHN DEERE |
| SE501387 | JOHN DEERE |
| 9515170 | MAGNETON |
| MG 279 | MAHLE |
| 20110305 | PRESTOLITE |
| ALTL425 | 3EFFE |
| PRAL425 | 3EFFE |
| CGB-10290 | AINDE |
| ANM42510X | ANDEL |
| AEA3205 | AUTOELECTRO |
| CAL10238 | CASCO |
| CAL10238AS | CASCO |
| CAL10238ES | CASCO |
| CAL10238GS | CASCO |
| CAL10238OS | CASCO |
| CAL10238RS | CASCO |
| 2077 | CEVAM |
| 75869 | EAI |
| ALT1443 | ELECTROLOG |
| 28-2574 | ELSTOCK |
| 210321 | ERA |
| 9940290 | FRIESEN |
| CA1197IR | HC PARTS |
| 301197RI | KUHNER |
| 301197RIM | KUHNER |
| 11.1197 | LAUBER |
| 441220 | LOGISTIK |
| 441344 | LOGISTIK |
| LRB00305 | LUCAS |
| LRB305 | LUCAS |
| 89213596 | POWERMAX |
| 9213596 | POWERMAX |
| 20101832BN | REAL |
| 2010238 | SANDO |
| A12BH0311A2 | SIDAT |
| ALT122380 | SIOM |
| ALT122380A | SIOM |
| STX100383 | STARDAX |
| 12161N | WAI / TRANSPO |
| ALT10105 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A2731 | 65A | 90A | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CASE | 580SK Loader | 0ccm Diesel | Cummins 4-390 | 1988 - 1994 | |||
| CASE I.H. | 5130 Maxxum | 5883ccm Diesel | B6-590 | 1990 - 1996 | |||
| CASE I.H. | 5140 Maxxum | 5883ccm Diesel | B6T-590 | 1990 - 1996 | |||
| CASE I.H. | 5150 Maxxum | 5883ccm Diesel | B6T-590 | 1990 - 1996 | |||
| CASE I.H. | MX100 Maxxum | 5883ccm Diesel | B6T-590 | 1996 - | |||
| CASE I.H. | MX110 Maxxum | 5883ccm Diesel | B6T-590 | 1996 - | |||
| CASE I.H. | MX120 Maxxum | 5883ccm Diesel | B6T-590 | 1996 - | |||
| CASE I.H. | MX135 Maxxum | 5883ccm Diesel | B6T-590 | 1996 - | |||
| CASE I.H. | MX150 Maxxum | 5883ccm Diesel | B6T-590 | 1996 - 2002 | |||
| HESSTON | HESSTON | 0ccm Diesel |
Description
B0305 Replacement Alternator
The Sahibs B0305 alternator is associated with Lucas reference LRB00305 for replacement identification. The listed electrical rating is 12V 65A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Case 580SK Loader variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 65A output: compare the listed rating with the original alternator.
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Case 580SK Loader – selected applications 1988–1994 (engine code Cummins 4-390).
- Case IH 5130 Maxxum 5883ccm Diesel – selected applications 1990–1996 (engine code B6-590).
- Case IH 5140 Maxxum 5883ccm Diesel – selected applications 1990–1996 (engine code B6T-590).
- Case IH 5150 Maxxum 5883ccm Diesel – selected applications 1990–1996 (engine code B6T-590).
- Case IH MX100 Maxxum 5883ccm Diesel – selected applications 1996 – (engine code B6T-590).
- Case IH MX110 Maxxum 5883ccm Diesel – selected applications 1996 – (engine code B6T-590).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0305. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120488205, 120488293, 120489475, 986040290, F005A00023, LRB00305, LRB305, DRB0290, 20110305, MG 279, 11.201.595, 11.201.935, AAK1363, AAK3330, IA0595
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0305 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0305 fit my Case 580SK Loader?
Case 580SK Loader (1988–1994) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0305 replace Lucas LRB00305?
Lucas LRB00305 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0305?
The listed details include 12V, 65A output, 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0305 new or remanufactured?
Check the current product condition selection for B0305. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0305?
Compare 12V compatibility, 65A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
