B0308 12V 70A Alternator Fits Toyota Hiace, Toyota Hilux
Price range: £165.00 through £264.00
Sahibs B0308 is a replacement alternator with a listed 12V 70A rating. Listed applications include selected Toyota Hiace, Toyota Hilux models. Identification references include Lucas LRB00308, Valeo 437776, Denso 1002115250. Its listed 12V 70A rating provides an electrical matching point for your existing unit. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0308 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 70 A |
| Volt | 12 V |
| No. of Grooves | 2 qty |
| Pulley Diameter | 72 mm |
| Mounting holes | 2 qty |
| Position | 10° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0308 | Dyno Electrics |
| 401821651 | Euro Car Part |
| 986046381 | Bosch Exchange |
| 1002115250 | Denso |
| 1002115310 | Denso |
| 1002131900 | Denso |
| 1002131910 | Denso |
| 1002131911 | Denso |
| 1002131912 | Denso |
| 1002131913 | Denso |
| 1002132240 | Denso |
| 1002132241 | Denso |
| 1002132250 | Denso |
| 1002132440 | Denso |
| 1002132471 | Denso |
| 1002132500 | Denso |
| 1002132580 | Denso |
| 111601 | HC-Cargo |
| 195704070 | PSH |
| 20110308WP | Prestolite |
| 21311R | WAI |
| 2704054320 | Toyota |
| 2704054340 | Toyota |
| 2704054341 | Toyota |
| 2704054370 | Toyota |
| 2704054380 | Toyota |
| 2706054150 | Toyota |
| 2706054210 | Toyota |
| 437776 | Valeo |
| ALT30017 | Wood Auto |
| ALT30025 | Wood Auto |
| ATA529 | ATK |
| DRA3745 | Delco Remy |
| F032111601 | HC-Cargo |
| HJA989IR | HC-Parts |
| JA989IR | HC-Parts |
| LRB00308 | Lucas |
| LRB308 | Lucas |
| Mar-58 | Magneti Marelli |
| OAN10497 | Optimum |
| WOOALT30017 | Wood Auto |
| WOOALT30025 | Wood Auto |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A3332 | 70A | 80A | Yes |
| A1436 | Round Nippon-Denso plug | No | |
| A2710 | Without M6 thread hole for cable clamp. Bent oil pipe | With M6 thread hole for cable clamp. Angled oil pipe | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| TOYOTA | Hiace | 2.4 (2446ccm) Diesel | 2L | MK IV | LH112 | 1993 - 1995 | |
| TOYOTA | Hiace | 2.4 (2446ccm) Diesel | 2L | MK IV | LH118 | 1993 - 1995 | |
| TOYOTA | Hiace | 2.4 (2446ccm) Diesel | 2L | MK IV | Commuter | LH102 | 1989 - 1995 |
| TOYOTA | Hiace | 2.4 (2446ccm) Diesel | 2L | MK IV | LXH12/LXH22 | 1995 - 2001 | |
| TOYOTA | Hiace | 2.4 (2446ccm) Diesel | 2LT | MK IV | LXH12/LXH22 | 1995 - 2001 | |
| TOYOTA | Hiace | 2.4 (2446ccm) Diesel | 2LT | MK IV | LXH18/LXH28 | 1997 - 2001 | |
| TOYOTA | Hilux | 2.4 (2446ccm) Diesel | 2LT | MK VI | LN165/LN170 | 1998 - 2001 |
Description
B0308 Replacement Alternator
Choose a replacement by comparing the B0308 alternator and its Lucas reference, LRB00308, with your existing unit. The listed electrical rating is 12V 70A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Toyota Hiace 2.4 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 70A output: compare the listed rating with the original alternator.
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Toyota Hiace 2.4 Diesel – selected applications 1993–1995 (engine code 2L).
- Toyota Hilux 2.4 Diesel – selected applications 1998–2001 (engine code 2LT).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0308. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986046381, 437776, 1002115250, 1002115310, 1002131900, 1002131910, 1002131911, 1002131912, 1002131913, 1002132240, 1002132241, 1002132250, 1002132440, 1002132471, 1002132500, 1002132580, LRB00308, LRB308, DRA3745, 20110308WP
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0308 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0308 fit my Toyota Hiace?
Toyota Hiace 2.4 Diesel (1993–1995) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0308 replace Lucas LRB00308?
Lucas LRB00308 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0308?
The listed details include 12V, 70A output, 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0308 new or remanufactured?
Check the current product condition selection for B0308. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0308?
Compare 12V compatibility, 70A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
