B0369 12V 120A Alternator Fits Land Rover Defender 110
Price range: £124.47 through £168.60
Compare the B0369 12V 120A alternator from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Land Rover Defender 110, Land Rover Defender 130, Land Rover Defender 90, Land Rover Discovery models. Identification references include Lucas LRB00369, Bosch 986046541, Valeo VA925. Its listed 12V 120A rating provides an electrical matching point for your existing unit. Check the 7-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0369 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 120 A |
| Volt | 12 V |
| No. of Grooves | 7 qty |
| Pulley Diameter | 55 mm |
| Mounting holes | 2 qty |
| Position | 0° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | Yes |
| Start/Stop | No |
| Weight | 6.9 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0369 | Dyno Electrics |
| 401670071 | Euro Car Part |
| A6230 | AS-PL |
| UD30025A | AS-PL |
| 986046541 | BOSCH |
| 114300 | CARGO |
| F032114300 | CARGO |
| 38522267F | CHRYSLER |
| ERR6999 | CHRYSLER |
| DRA3856 | DELCO |
| RAA14967 | DELCO |
| 100213-2391 | DENSO |
| 100213-2530 | DENSO |
| 976021-7253 | DENSO |
| DAN670 | DENSO |
| 8EL738079-001 | HELLA |
| ERR6999E | LAND ROVER |
| ERR6999ES | LAND ROVER |
| LR006190 | LAND ROVER |
| 63377497010 | MAGNETI MARELLI |
| 9.44E+11 | MAGNETI MARELLI |
| MAN7497 | MAGNETI MARELLI |
| 20110369 | PRESTOLITE |
| 20110369WP | PRESTOLITE |
| VA925 | VALEO |
| ALTS033 | 3EFFE |
| PRAS033 | 3EFFE |
| CGB-13856 | AINDE |
| ANM36076X | ANDEL |
| AEA3269 | AUTOELECTRO |
| NEA3269 | AUTOELECTRO |
| CAL40121AS | CASCO |
| CAL40121GS | CASCO |
| 9190 | CEVAM |
| 56949 | EAI |
| ALT6096 | ELECTROLOG |
| 28-3882 | ELSTOCK |
| 210961 | ERA |
| 9090277 | FRIESEN |
| GA132391-A | GPARTS |
| JA1710IR | HC PARTS |
| 32201202 | HERTH+BUSS |
| ALN1710 | KRAUF |
| 401710RI | KUHNER |
| 11.171 | LAUBER |
| 446759 | LOGISTIK |
| 446927 | LOGISTIK |
| LRB00369 | LUCAS |
| LRB369 | LUCAS |
| 455.702.120.050 | PSH |
| 455.702.120.260 | PSH |
| 455.702.120.266 | PSH |
| 20132121BN | REAL |
| 20132121OE | REAL |
| RNL1710JA | RNL |
| ALT336 | ROLLCO |
| 2040121 | SANDO |
| 2040121.1 | SANDO |
| A12DE0137A2 | SIDAT |
| ALT421210 | SIOM |
| STX100802 | STARDAX |
| STX100802R | STARDAX |
| 21369N | WAI / TRANSPO |
| 21369R | WAI / TRANSPO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| LAND ROVER | Defender 110 | 2.5 (2495ccm) Diesel | 10P/14P/15P | MK II | LDH | 1998 - 2012 | |
| LAND ROVER | Defender 110 | 2.5 (2495ccm) Diesel | 10P/14P | MK II | Pick Up | LDH | 1998 - 2006 |
| LAND ROVER | Defender 130 | 2.5 (2495ccm) Diesel | 10P/14P | MK II | Pick Up | LDK | 1998 - 2006 |
| LAND ROVER | Defender 130 | 2.5 (2495ccm) Diesel | 10P/14P/15P | MK II | Crewcab | LDK | 1998 - 2007 |
| LAND ROVER | Defender 90 | 2.5 (2495ccm) Diesel | 10P/14P/15P | MK II | Pick Up | LDV | 1998 - 2007 |
| LAND ROVER | Defender 90 | 2.5 (2495ccm) Diesel | 10P/14P/15P | MK II | LDV | 1998 - 2007 | |
| LAND ROVER | Discovery | 2.5 (2495ccm) Diesel | 15P | MK II | L318 | 1998 - 2004 | |
| LAND ROVER | Discovery | 2.5 (2495ccm) Diesel | 10P/15P | MK II | L318 | 1998 - 2004 |
Description
B0369 Replacement Alternator
For a B0369 alternator enquiry, use Lucas reference LRB00369 alongside the vehicle and original unit details. The listed electrical rating is 12V 120A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Land Rover Defender 110 2.5 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 120A output: compare the listed rating with the original alternator.
- 7-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Land Rover Defender 110 2.5 Diesel – selected applications 1998–2012 (engine code 10P/14P/15P).
- Land Rover Defender 130 2.5 Diesel – selected applications 1998–2006 (engine code 10P/14P).
- Land Rover Defender 90 2.5 Diesel – selected applications 1998–2007 (engine code 10P/14P/15P).
- Land Rover Discovery 2.5 Diesel – selected applications 1998–2004 (engine code 15P).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0369. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986046541, VA925, 100213-2391, 100213-2530, 976021-7253, DAN670, LRB00369, LRB369, DRA3856, RAA14967, 20110369, 20110369WP, 38522267F, ERR6999
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0369 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0369 fit my Land Rover Defender 110?
Land Rover Defender 110 2.5 Diesel (1998–2012) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0369 replace Lucas LRB00369?
Lucas LRB00369 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0369?
The listed details include 12V, 120A output, 7 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0369 new or remanufactured?
Check the current product condition selection for B0369. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0369?
Compare 12V compatibility, 120A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
