B0391 12V 120A Alternator Fits VW Golf, VW New Beetle, VW Sharan
Price range: £119.46 through £159.89
Sahibs B0391 is a replacement alternator with a listed 12V 120A rating. Listed applications include selected VW Golf, VW New Beetle, VW Sharan, VW Vento models. Identification references include Lucas LRB00391, Bosch 123510047, Delco Remy DRB1010. Its listed 12V 120A rating provides an electrical matching point for your existing unit. Check the 6-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0391 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 120 A |
| Volt | 12 V |
| No. of Grooves | 6 qty |
| Pulley Diameter | 56 mm |
| Mounting holes | 4 qty |
| Position | -90° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 7.3 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0391 | Dyno Electrics |
| A0377 | AS-PL |
| UD02235A | AS-PL |
| 123510047 | BOSCH |
| 123515021 | BOSCH |
| 986041010 | BOSCH |
| DRB1010 | DELCO |
| 98VW-10300-AA | FORD |
| 8EL737164-001 | HELLA |
| 038903023J | VW |
| ALTS133 | 3EFFE |
| ALTS133B | 3EFFE |
| ALTS133NE | 3EFFE |
| PRAS133 | 3EFFE |
| ANM43230X | ANDEL |
| AEA3291 | AUTOELECTRO |
| STA0525R | BOVEZ |
| CAL10221 | CASCO |
| CAL10221AS | CASCO |
| CAL10221ES | CASCO |
| CAL10221GS | CASCO |
| CAL10221OS | CASCO |
| CAL10221RS | CASCO |
| 4494 | CEVAM |
| 56693 | EAI |
| ALT1973 | ELECTROLOG |
| 28-2867 | ELSTOCK |
| 210170 | ERA |
| 9041010 | FRIESEN |
| CA1144IR | HC PARTS |
| 301144RI | KUHNER |
| 11.1144 | LAUBER |
| 11.1144M | LAUBER |
| 441291 | LOGISTIK |
| LRB00391 | LUCAS |
| LRB391 | LUCAS |
| 89212101 | POWERMAX |
| 20101122BN | REAL |
| 20101122RC | REAL |
| 310655 | RHIAG |
| 2010221 | SANDO |
| ALT122210 | SIOM |
| SB044 | SOVEREIGN |
| STX100508 | STARDAX |
| 21391R | WAI / TRANSPO |
| ALT10296 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0385 | Clutch pulley PV6/54 | Pulley without clutch PV6/49 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| AUDI | A3 | 1.9 (1896ccm) Diesel | AGR/ALH | 8L1 | 1996 - 1998 | ||
| AUDI | A3 | 1.9 (1896ccm) Diesel | AHF/ASV | 8L1 | 1997 - 1998 | ||
| SEAT | Alhambra | 1.8 (1781ccm) Petrol | AJH/AWC | 7V8/7V9 | 1999 - 2000 | ||
| SKODA | Octavia | 1.9 (1896ccm) Diesel | AGR/ALH | I | Combi | 1U5 | 1996 - 1998 |
| SKODA | Octavia | 1.9 (1896ccm) Diesel | AGR/ALH | I | 1U2 | 1996 - 1998 | |
| SKODA | Octavia | 1.9 (1896ccm) Diesel | AGP/AQM | I | 1U2 | 1997 - 1998 | |
| SKODA | Octavia | 1.9 (1896ccm) Diesel | AHF/ASV | I | 1U2 | 1997 - 2006 | |
| SKODA | Octavia | 1.9 (1896ccm) Diesel | AGP/AQM | I | Combi | 1U5 | 1998 - 1998 |
| VW | Golf | 1.9 (1896ccm) Diesel | AHF/ASV | IV | 1J1 | 1997 - 1998 | |
| VW | Golf | 1.9 (1896ccm) Diesel | AGR/ALH | IV | 1J1 | 1997 - 1998 | |
| VW | Golf | 1.9 (1896ccm) Diesel | AGP/AQM | IV | 1J1 | 1997 - 1998 | |
| VW | Golf | 1.9 (1896ccm) Diesel | AGR/ALH | IV | 1J5 | 1999 - 2006 | |
| VW | New Beetle | 1.9 (1896ccm) Diesel | ALH | 1C1/9C1 | 1998 - 1998 | ||
| VW | Sharan | 1.8 (1781ccm) Petrol | AJH/AWC | 7M6/7M8/7M9 | 1997 - 1998 | ||
| VW | Vento | 1.9 (1896ccm) Diesel | AFN | III | 1H2 | 1996 - 1997 |
Description
B0391 Replacement Alternator
The Sahibs B0391 alternator is associated with Lucas reference LRB00391 for replacement identification. The listed electrical rating is 12V 120A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected VW Golf 1.9 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 120A output: compare the listed rating with the original alternator.
- 6-groove pulley: check belt profile and alignment against the existing unit.
- 4 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- VW Golf 1.9 Diesel – selected applications 1997–1998 (engine code AHF/ASV).
- VW New Beetle 1.9 Diesel – selected applications 1998–1998 (engine code ALH).
- VW Sharan 1.8 Petrol – selected applications 1997–1998 (engine code AJH/AWC).
- VW Vento 1.9 Diesel – selected applications 1996–1997 (engine code AFN).
- Audi A3 1.9 Diesel – selected applications 1996–1998 (engine code AGR/ALH).
- Seat Alhambra 1.8 Petrol – selected applications 1999–2000 (engine code AJH/AWC).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0391. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
123510047, 123515021, 986041010, LRB00391, LRB391, DRB1010, 98VW-10300-AA, 98VW10300AA
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0391 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0391 fit my VW Golf?
VW Golf 1.9 Diesel (1997–1998) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0391 replace Lucas LRB00391?
Lucas LRB00391 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0391?
The listed details include 12V, 120A output, 6 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0391 new or remanufactured?
Check the current product condition selection for B0391. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0391?
Compare 12V compatibility, 120A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
