B0487 12V 100A Alternator Fits Vauxhall Astra, Vauxhall Astra Van
B0487 12V 100A Alternator Fits Vauxhall Astra, Vauxhall Astra Van - Image 2
B0487 12V 100A Alternator Fits Vauxhall Astra, Vauxhall Astra Van - Image 3

B0487 12V 100A Alternator Fits Vauxhall Astra, Vauxhall Astra Van

Price range: £102.80 through £137.60

Sahibs B0487 is a replacement alternator with a listed 12V 100A rating. Listed applications include selected Vauxhall Astra, Vauxhall Astra Van, Vauxhall Combo, Vauxhall Corsa models. Identification references include Lucas LRB00487, Bosch 986043981, Valeo 437497. Its listed 12V 100A rating provides an electrical matching point for your existing unit. Check the 6-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0487 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.

SKU: B0487 Category:

Product Specification

DescriptionValue
AMP100 A
Volt12 V
No. of Grooves6 qty
Pulley Diameter60 mm
Mounting holes3 qty
Position-18°
B+M8
Insulated ReturnNo
Water cooledNo
Vacuum pumpYes
Start/StopNo
Weight6.6 Kg

Cross Reference

Reference NumberBrand
DYB0487Dyno Electrics
401721481Euro Car Part
A2003AS-PL
UD15481AAS-PL
UD47285AAS-PL
986043981BOSCH
986043983BOSCH
F002G90229BOSCH
F032UA0065BOSCH
F042305043BOSCH
112271CARGO
F032112271CARGO
DA4904DELCO
DA4904NDELCO
DRA3794DELCO
DRA3794NDELCO
DRA3794XDELCO
RAA14805DELCO
8EL011360-241HELLA
8EL011711-151HELLA
8EL011711-152HELLA
8EL737795-001HELLA
136101HITACHI
2506101HITACHI
LR1100-502HITACHI
LR1100-502AHITACHI
LR1100-502BHITACHI
LR1100-502CHITACHI
LR1100-502DHITACHI
LR1100-502EHITACHI
LR1100-502FHITACHI
LR1100-502GHITACHI
LR1100-502HHITACHI
LR1100-502IHITACHI
LR1100-502JHITACHI
LR1100-502KHITACHI
LR1100-502LHITACHI
LR1100-502MHITACHI
LR1100-502NHITACHI
LR1100-504HITACHI
LR1100-504AHITACHI
LR1100-504BHITACHI
LR1100-504CHITACHI
LR1100-504DHITACHI
LR1100-504EHITACHI
LR1100-504FHITACHI
LR1100-505HITACHI
LR1100-505AHITACHI
LR1100-505BHITACHI
LR1100-505CHITACHI
LR1100-505DHITACHI
LR1100-505EHITACHI
LR1100502PHITACHI
LR1100504HHITACHI
LR1100504JHITACHI
31100-PLZ-D00HONDA
6.3003.9IKA
11.209.424ISKRA / LETRIKA
AAK5574ISKRA / LETRIKA
IA9415ISKRA / LETRIKA
8-97326-180-2ISUZU
89708911380ISUZU
8971891120ISUZU
8971891130ISUZU
8971891133ISUZU
8971891134ISUZU
8971891135ISUZU
8971891136ISUZU
8971891137ISUZU
8971891138ISUZU
8971891139ISUZU
8972873921ISUZU
8972873923ISUZU
8972873924ISUZU
8973261800ISUZU
8973261801ISUZU
8980542550ISUZU
8980564450ISUZU
8980564451ISUZU
8980568670ISUZU
63730005010MAGNETI MARELLI
63731521010MAGNETI MARELLI
9.44E+11MAGNETI MARELLI
MQA1521MAGNETI MARELLI
MRA90006MAGNETI MARELLI
MG 506MAHLE
1204158OPEL
6204140OPEL
6204284OPEL
93175799OPEL
93175944OPEL
9512785OPEL
95520877OPEL
97189112OPEL
97189113OPEL
98054255OPEL
98056867OPEL
20110487PRESTOLITE
437497VALEO
746007VALEO
746807VALEO
ALTF2903EFFE
ALTL1303EFFE
ALTL130LU3EFFE
ALTL130M3EFFE
ALTL130NE3EFFE
PRAF2903EFFE
PRAL1303EFFE
PRAL130LU3EFFE
CGB-13794AINDE
CGB-83839AINDE
ANM36014XANDEL
AAL1382APEC
002-U914ASHIKA
002-U915ASHIKA
AEA4287AUTOELECTRO
NEA4287AUTOELECTRO
STA0020RBOVEZ
CAL20102ASCASCO
CAL20102GSCASCO
CAL20102OSCASCO
9001CEVAM
56815EAI
ALT3036ELECTROLOG
ALT79823ELECTROLOG
28-3839ELSTOCK
EZ4509ELTA AUTOMOTIVE
210062ERA
AG0466GHIBAUDI
97326180GM
GA100502-AGPARTS
JA1521IRHC PARTS
32068020HERTH+BUSS
ALU914JAPANPARTS
ALU915JAPANPARTS
2U914JAPKO
2U915JAPKO
ALH1521KRAUF
401521RIKUHNER
401521RILKUHNER
446570LOGISTIK
LRB00487LUCAS
LRB487LUCAS
5520039MEAT & DORIA
NPANAL1382NAPA
89212651POWERMAX
135.601.100.080PSH
135.601.100.265PSH
135.601.100.415PSH
20145201BNREAL
20145201OEREAL
20145201REREAL
311828RHIAG
RNLLR1100-502RNL
ALT328ROLLCO
2020102SANDO
2020102.1SANDO
2020102.4SANDO
A12HT0022A2SIDAT
ALT5610SIOM
STX100001STARDAX
STX100001RSTARDAX
STX100086STARDAX
STX100086RSTARDAX
STX100121STARDAX
STX100121RSTARDAX
STX100311STARDAX
STX100311RSTARDAX
AX1150STARLINE
R1530037VAUXHALL
21830NWAI / TRANSPO
21830RWAI / TRANSPO
LR1100502MDWOODAUTO

Vehicle Applications

BrandModelEngineEngine CodeSeriesModel TypeTypeYear
CHEVROLETCorsa1.7 (1686ccm) Diesel2H7352000 - 2002
CHEVROLETCorsa1.7 (1686ccm) Diesel2H7982000 - 2002
CHEVROLETCorsa Pick Up1.7 (1686ccm) Diesel2H7352000 - 2002
HONDACivic1.7 (1686ccm) Diesel4EE2MK VIIEP4/EU92001 - 2005
OPELAstra1.7 (1686ccm) DieselY17DTGF351999 - 2004
OPELAstra1.7 (1686ccm) DieselY17DTGF08/F481999 - 2004
OPELAstra1.7 (1686ccm) DieselY17DTGF692000 - 2004
OPELAstra1.7 (1686ccm) DieselZ17DTLGF352003 - 2004
OPELAstra1.7 (1686ccm) DieselZ17DTLGF692003 - 2005
OPELAstra1.7 (1686ccm) DieselZ17DTLGF08/F482003 - 2005
OPELAstra Classic1.7 (1686ccm) DieselZ17DTLGF352004 - 2009
OPELAstra Van1.7 (1686ccm) DieselY17DTGF702000 - 2003
OPELAstra Van1.7 (1686ccm) DieselZ17DTLGF702003 - 2004
OPELCombo1.7 (1686ccm) DieselY17DTLCF252001 - 2004
OPELCombo1.7 (1686ccm) DieselY17DTCF252001 - 2004
OPELCombo Tour1.7 (1686ccm) DieselY17DTLCF062001 - 2004
OPELCombo Tour1.7 (1686ccm) DieselY17DTCF062001 - 2004
OPELCorsa1.7 (1686ccm) DieselY17DTLCF08/F682000 - 2003
OPELCorsa1.7 (1686ccm) DieselY17DTCF08/F682000 - 2003
OPELCorsa Van1.7 (1686ccm) DieselY17DTLCF082000 - 2003
OPELCorsa Van1.7 (1686ccm) DieselY17DTCF082000 - 2003
OPELCorsa Van1.7 (1686ccm) DieselZ17DTHCF082003 - 2012
OPELMeriva1.7 (1686ccm) DieselY17DTAE752003 - 2004
VAUXHALLAstra1.7 (1686ccm) DieselY17DTGF352000 - 2005
VAUXHALLAstra1.7 (1686ccm) DieselY17DTGF08/F482000 - 2005
VAUXHALLAstra1.7 (1686ccm) DieselY17DTGF692000 - 2004
VAUXHALLAstra1.7 (1686ccm) DieselZ17DTLGF692003 - 2005
VAUXHALLAstra1.7 (1686ccm) DieselZ17DTLGF08/F482003 - 2005
VAUXHALLAstra1.7 (1686ccm) DieselZ17DTLGF352003 - 2005
VAUXHALLAstra Van1.7 (1686ccm) DieselY17DTGF702000 - 2005
VAUXHALLAstra Van1.7 (1686ccm) DieselZ17DTLGF702003 - 2005
VAUXHALLCombo1.7 (1686ccm) DieselY17DTCF062001 - 2012
VAUXHALLCombo1.7 (1686ccm) DieselY17DTLCF062001 - 2004
VAUXHALLCombo1.7 (1686ccm) DieselY17DTLCF252001 - 2004
VAUXHALLCombo1.7 (1686ccm) DieselY17DTCF252001 - 2006
VAUXHALLCorsa1.7 (1686ccm) DieselY17DTLCF08/F682000 - 2003
VAUXHALLCorsa1.7 (1686ccm) DieselY17DTCF08/F682000 - 2003
VAUXHALLCorsa1.7 (1686ccm) DieselZ17DTHCF08/F682003 - 2005
VAUXHALLCorsa Van1.7 (1686ccm) DieselY17DTLCF082000 - 2003
VAUXHALLCorsa Van1.7 (1686ccm) DieselY17DTCF082000 - 2006
VAUXHALLMeriva1.7 (1686ccm) DieselY17DTAE752003 - 2006

Description

B0487 Replacement Alternator

Choose a replacement by comparing the B0487 alternator and its Lucas reference, LRB00487, with your existing unit. The listed electrical rating is 12V 100A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Vauxhall Astra 1.7 Diesel variants.

Key Features and Benefits

  • 12V electrical system: match the vehicle voltage before selecting a unit.
  • 100A output: compare the listed rating with the original alternator.
  • 6-groove pulley: check belt profile and alignment against the existing unit.
  • 3 mounting holes: compare the fixing pattern and unit position.
  • M8 B+ terminal: check the connection against the original unit.

Compatible Vehicles and Applications

  • Vauxhall Astra 1.7 Diesel – selected applications 2000–2005 (engine code Y17DT).
  • Vauxhall Astra Van 1.7 Diesel – selected applications 2000–2005 (engine code Y17DT).
  • Vauxhall Combo 1.7 Diesel – selected applications 2001–2012 (engine code Y17DT).
  • Vauxhall Corsa 1.7 Diesel – selected applications 2000–2003 (engine code Y17DTL).
  • Vauxhall Corsa Van 1.7 Diesel – selected applications 2000–2003 (engine code Y17DTL).
  • Vauxhall Meriva 1.7 Diesel – selected applications 2003–2006 (engine code Y17DT).

These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.

OE Numbers and Cross-Reference Information

The following cross-reference numbers are associated with B0487. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.

986043981, 986043983, F002G90229, F032UA0065, F042305043, 437497, 746007, 746807, LRB00487, LRB487, 136101, 2506101, LR1100-502, LR1100-502A, LR1100-502B, LR1100-502C, LR1100-502D, LR1100-502E, LR1100-502F, LR1100-502G, LR1100-502H, LR1100-502I, LR1100-502J, LR1100-502K, LR1100-502L, LR1100-502M, LR1100-502N, LR1100-504, LR1100-504A, LR1100-504B, LR1100-504C, LR1100-504D, LR1100-504E, LR1100-504F, LR1100-505, LR1100-505A, LR1100-505B, LR1100-505C, LR1100-505D, LR1100-505E, LR1100502M, LR1100502P, LR1100504H, LR1100504J, LR1100505C, LR1100505E, DA4904, DA4904N, DRA3794, DRA3794N, DRA3794X, RAA14805, 20110487, MG 506, MG506, 11.209.424, AAK5574, IA9415

The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.

When Should You Replace Your Alternator?

Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.

Why Buy from Sahibs Auto Electrics?

Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0487 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.

Frequently Asked Questions

Will B0487 fit my Vauxhall Astra?

Vauxhall Astra 1.7 Diesel (2000–2005) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.

Does B0487 replace Lucas LRB00487?

Lucas LRB00487 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.

What specifications are listed for B0487?

The listed details include 12V, 100A output, 6 pulley grooves. Compare the complete specifications on this page with the unit being replaced.

Is B0487 new or remanufactured?

Check the current product condition selection for B0487. Confirm the supplier and availability of the option you want before completing the order.

What should I compare before ordering B0487?

Compare 12V compatibility, 100A output, pulley configuration, mounting points and electrical connections with the original alternator.

Does a battery warning light prove the alternator has failed?

No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
