S0106 12V 2.8kW Starter Motor Fits Leyland 245 Tractor, Jcb 2B Loader
Price range: £131.03 through £157.07
Compare the S0106 12V 2.8kW starter motor from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Leyland 245 Tractor, Leyland 262 Tractor, Leyland 270 Tractor, Leyland 285 Tractor models. Identification references include Lucas LRS00106, Bosch 1359116, Prestolite 20500106. Its listed 12V 2.8kW rating provides an electrical matching point for your existing unit. Check the 10-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0106 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.8 kW |
| Volt | 12 V |
| Plug | M8 |
| Rotation | Clockwise |
| Teeth | 10 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 13.6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0106 | Dyno Electrics |
| S4054 | AS-PL |
| UD12401S | AS-PL |
| 1359116 | BOSCH |
| 111573 | CARGO |
| F032111573 | CARGO |
| 20500106 | PRESTOLITE |
| STRS092 | 3EFFE |
| CGB-23456 | AINDE |
| AES1106 | AUTOELECTRO |
| AES2112 | AUTOELECTRO |
| CST25110 | CASCO |
| CST25110AS | CASCO |
| CST25110ES | CASCO |
| CST25110GS | CASCO |
| CST25110OS | CASCO |
| CST25110RS | CASCO |
| TS-4048 | DIXIE |
| STR4139 | ELECTROLOG |
| 25-0081 | ELSTOCK |
| SG0164 | GHIBAUDI |
| 26294 | JCB |
| 714-03000R | JCB |
| 714-11200 | JCB |
| 714-40006 | JCB |
| 714/11200 | JCB |
| 254103P | KUHNER |
| 336227 | LOGISTIK |
| 26025183 | LUCAS |
| 26025183A | LUCAS |
| 26246 | LUCAS |
| 26246A | LUCAS |
| 26246E | LUCAS |
| 26246F | LUCAS |
| 26246J | LUCAS |
| 26246K | LUCAS |
| 26246L | LUCAS |
| 26246M | LUCAS |
| 26304 | LUCAS |
| 26304A | LUCAS |
| 26304B | LUCAS |
| 26304D | LUCAS |
| 26343 | LUCAS |
| 26343A | LUCAS |
| 26343B | LUCAS |
| 26343D | LUCAS |
| 26343E | LUCAS |
| 26343F | LUCAS |
| 26343K | LUCAS |
| 26351 | LUCAS |
| 26351B | LUCAS |
| 26351D | LUCAS |
| 26376 | LUCAS |
| 26376A | LUCAS |
| 26376E | LUCAS |
| 26376K | LUCAS |
| 26376L | LUCAS |
| 27513 | LUCAS |
| 27513A | LUCAS |
| 27526 | LUCAS |
| 27526A | LUCAS |
| 27526D | LUCAS |
| LRD132 | LUCAS |
| LRS00106 | LUCAS |
| LRS0106 | LUCAS |
| LRS106 | LUCAS |
| 700.014.103 | PSH |
| 20405011BN | REAL |
| 20405011OE | REAL |
| 6025110 | SANDO |
| MAV3620 | SIOM |
| MAV3810 | SIOM |
| STX200542 | STARDAX |
| 17071N | WAI / TRANSPO |
| 17071R | WAI / TRANSPO |
| STR25007 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| DENNIS EAGLE | Bulkmaster 50/70 Municipal | 5655ccm Diesel | Leyland | 1972 - 1979 | |||
| HEDEN FORK LIFT | HEDEN FORK LIFT | 0ccm Diesel | BLMC | ||||
| JCB | 2B Loader | 0ccm Diesel | |||||
| JCB | 2D Loader | 0ccm Diesel | Leyland 384/4 | ||||
| JCB | 2D/2DS Loader | 0ccm Diesel | Leyland 4/65 | 1971 - | |||
| JCB | 3/3C Loader | 0ccm Diesel | Leyland 4/65 | 1971 - | |||
| JCB | 3/3C Loader | 0ccm Diesel | Leyland 384/4 | 1972 - | |||
| JCB | 3CX Backhoe-Loader | 3770ccm Diesel | Leyland | 1980 - 1981 | |||
| JCB | 3D Loader | 0ccm Diesel | Leyland 4/65 | 1971 - | |||
| JCB | 3D Loader | 0ccm Diesel | Leyland 384/4 | 1972 - | |||
| JCB | 410 Loader | 3860ccm Diesel | 1982 - 1994 | ||||
| JCB | 4D Loader | 0ccm Diesel | Leyland 384/4 & 4/65 | 1969 - 1980 | |||
| JCB | 520 Loadall | 3770ccm Diesel | 1975 - 1981 | ||||
| JCB | 520M Loader | 3860ccm Diesel | 1986 - 1997 | ||||
| LEYLAND | 245 Tractor | 0ccm Diesel | Perkins D3.152 | 1974 - 1977 | |||
| LEYLAND | 262 Tractor | 0ccm Diesel | Leyland 4/98DT | 1976 - 1979 | |||
| LEYLAND | 270 Tractor | 0ccm Diesel | Leyland 4/98NT | 1974 - 1976 | |||
| LEYLAND | 285 Tractor | 0ccm Diesel | Leyland 6/98DT | 1977 - 1979 | |||
| LEYLAND | Terrier Boxer | 0ccm Diesel | 1971 - 1976 |
Description
S0106 Replacement Starter Motor
The Sahibs S0106 starter motor is associated with Lucas reference LRS00106 for replacement identification. The listed electrical rating is 12V 2.8kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Leyland 245 Tractor variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.8kW power: compare the listed rating with the original starter motor.
- 10-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Leyland 245 Tractor – selected applications 1974–1977 (engine code Perkins D3.152).
- Leyland 262 Tractor – selected applications 1976–1979 (engine code Leyland 4/98DT).
- Leyland 270 Tractor – selected applications 1974–1976 (engine code Leyland 4/98NT).
- Leyland 285 Tractor – selected applications 1977–1979 (engine code Leyland 6/98DT).
- Leyland Terrier Boxer – selected applications 1971–1976.
- Dennis Eagle Bulkmaster 50/70 Municipal 5655ccm Diesel – selected applications 1972–1979 (engine code Leyland).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0106. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1359116, LRS00106, 26025183, 26025183A, 26246, 26246A, 26246E, 26246F, 26246J, 26246K, 26246L, 26246M, 26304, 26304A, 26304B, 26304D, 26343, 26343A, 26343B, 26343D, 26343E, 26343F, 26343K, 26351, 26351B, 26351D, 26376, 26376A, 26376E, 26376K, 26376L, 27513, 27513A, 27526, 27526A, 27526D, LRD132, LRS0106, LRS106, 20500106
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0106 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0106 fit my Leyland 245 Tractor?
Leyland 245 Tractor (1974–1977) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0106 replace Lucas LRS00106?
Lucas LRS00106 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0106?
The listed details include 12V, 2.8kW power, 10 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0106 new or remanufactured?
Check the current product condition selection for S0106. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0106?
Compare 12V compatibility, 2.8kW power, 10 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
