S0665 12V 1.7kW Starter Motor Fits Fiat Duna, Fiat Elba CSL, Fiat Uno
Price range: £97.99 through £113.06
Compare the S0665 12V 1.7kW starter motor from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Fiat Duna, Fiat Elba CSL, Fiat Fiorino, Fiat Fiorino Pick Up models. Identification references include Lucas LRS00665, Bosch 1110025, Valeo 436049. Its listed 12V 1.7kW rating provides an electrical matching point for your existing unit. Check the 10-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0665 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 1.7 kW |
| Volt | 12 V |
| Rotation | Clockwise |
| Teeth | 10 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 4.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0665 | Dyno Electrics |
| 402650131 | Euro Car Part |
| S0433 | AS-PL |
| 1110025 | BOSCH |
| 1110082 | BOSCH |
| 1110125 | BOSCH |
| 986014700 | BOSCH |
| 986014701 | BOSCH |
| 986016900 | BOSCH |
| 111619 | CARGO |
| F032111619 | CARGO |
| DRS4700 | DELCO |
| 46231601 | FIAT |
| 46231602 | FIAT |
| 46446291 | FIAT |
| 5996771 | FIAT |
| 5997309 | FIAT |
| 7580192 | FIAT |
| 7716766 | FIAT |
| 77167660 | FIAT |
| 77323430 | FIAT |
| 8EA011610-381 | HELLA |
| 8EA726122-001 | HELLA |
| 63521101250 | MAGNETI MARELLI |
| 9.43251E+11 | MAGNETI MARELLI |
| 9.4428E+11 | MAGNETI MARELLI |
| MRS16900 | MAGNETI MARELLI |
| MSR902 | MAGNETI MARELLI |
| 436049 | VALEO |
| D7R42 | VALEO |
| D7R7 | VALEO |
| 8111509 | VOLVO |
| CGB-51053 | AINDE |
| AES6165 | AUTOELECTRO |
| CST10149AS | CASCO |
| CST10149GS | CASCO |
| CST10149RS | CASCO |
| 3614 | CEVAM |
| STR1712 | ELECTROLOG |
| 25-1053 | ELSTOCK |
| 220216A | ERA |
| 220216R | ERA |
| SG0115 | GHIBAUDI |
| GS110025-A | GPARTS |
| SS110025-A | GPARTS |
| 42014701 | HERTH+BUSS |
| STB0374 | KRAUF |
| 10374 | KUHNER |
| 10374R | KUHNER |
| 330526 | LOGISTIK |
| LRS00665 | LUCAS |
| LRS665 | LUCAS |
| 5010093 | MEAT & DORIA |
| 88213120 | POWERMAX |
| 500.506.103.010 | PSH |
| 500.506.103.018 | PSH |
| 500.506.103.216 | PSH |
| 500.506.103.395 | PSH |
| 500.506.103.608 | PSH |
| 20401941BN | REAL |
| 20401941OE | REAL |
| 20401941RC | REAL |
| STM1049 | ROLLCO |
| 6010149 | SANDO |
| 6010149.1 | SANDO |
| 6010149.2 | SANDO |
| STX200370 | STARDAX |
| STX200370R | STARDAX |
| STX200464 | STARDAX |
| STX200690 | STARDAX |
| 30665N | WAI / TRANSPO |
| STR2214 | WOODAUTO |
| STR50425 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S2111 | 1.7KW Connection 50 Spade Terminal | 1.7KW M6 Terminal 50 | No |
| T0150 | 1.7KW Connection 50 Spade Terminal | 1.7/1.8KW Connection 50 M6 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| FIAT | Duna | 1.7 (1698ccm) Diesel | 149B3000 | Weekend | 146AF | 1987 - 1991 | |
| FIAT | Duna | 1.7 (1698ccm) Diesel | 149B3000 | 146AF | 1987 - 1990 | ||
| FIAT | Elba CSL | 1.7 (1698ccm) Diesel | 146B2000 | Panorama | 146DI/146EI | 1995 - 1997 | |
| FIAT | Fiorino | 1.7 (1697ccm) Diesel | 149B2000 | 146AF | 1993 - 2000 | ||
| FIAT | Fiorino | 1.7 (1698ccm) Diesel | 146B2000/149B3000 | 146CI/146RD | 1988 - 2000 | ||
| FIAT | Fiorino Pick Up | 1.7 (1698ccm) Diesel | 149B3000 | 146AF | 1988 - 1999 | ||
| FIAT | Regata | 1.7 (1698ccm) Diesel | 149B3000 | 138A | 1986 - 1988 | ||
| FIAT | Regata | 1.7 (1714ccm) Diesel | 138B6000 | 138A | 1983 - 1986 | ||
| FIAT | Regata S.W./Weekend | 1.7 (1698ccm) Diesel | 149B3000 | 138A | 1984 - 1989 | ||
| FIAT | Ritmo | 1.7 (1698ccm) Diesel | 149B3000 | 138A | 1985 - 1987 | ||
| FIAT | Ritmo | 1.7 (1714ccm) Diesel | 138A5000 | 138A | 1979 - 1982 | ||
| FIAT | Tipo | 1.7 (1697ccm) Diesel | 149B4000 | 160AG | 1988 - 1995 | ||
| FIAT | Tipo | 1.7 (1697ccm) Diesel | 149B4000 | 160EG | 1988 - 1994 | ||
| FIAT | Uno | 1.3 (1301ccm) Diesel | 146B1000 | 146A | 1983 - 1992 | ||
| FIAT | Uno | 1.4 (1367ccm) Diesel | 146B000/146B3000/160B3000 | 146A/146E | 1986 - 1990 | ||
| FIAT | Uno | 1.7 (1698ccm) Diesel | 146B2000 | 146A | 1986 - 1989 | ||
| FIAT | Uno | 1.7 (1698ccm) Diesel | 146B2000 | 146E | 1989 - 1993 | ||
| FIAT | Uno | 1.7 (1698ccm) Diesel | 146B2000 | Cargo | 146E | 1989 - 1991 | |
| SEAT | Ibiza | 1.7 (1675ccm) Petrol | 1700I | I | 21A | 1991 - 1993 |
Description
S0665 Replacement Starter Motor
The S0665 starter motor is a replacement unit identified by Lucas reference LRS00665. The listed electrical rating is 12V 1.7kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Fiat Duna 1.7 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 1.7kW power: compare the listed rating with the original starter motor.
- 10-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
Compatible Vehicles and Applications
- Fiat Duna 1.7 Diesel – selected applications 1987–1991 (engine code 149B3000).
- Fiat Elba CSL 1.7 Diesel – selected applications 1995–1997 (engine code 146B2000).
- Fiat Fiorino 1.7 Diesel – selected applications 1993–2000 (engine code 149B2000).
- Fiat Fiorino Pick Up 1.7 Diesel – selected applications 1988–1999 (engine code 149B3000).
- Fiat Regata 1.7 Diesel – selected applications 1986–1988 (engine code 149B3000).
- Fiat Regata S.W./Weekend 1.7 Diesel – selected applications 1984–1989 (engine code 149B3000).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0665. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1110025, 1110082, 1110125, 986014700, 986014701, 986016900, 436049, D7R42, D7R7, LRS00665, LRS665, DRS4700
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0665 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0665 fit my Fiat Duna?
Fiat Duna 1.7 Diesel (1987–1991) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0665 replace Lucas LRS00665?
Lucas LRS00665 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0665?
The listed details include 12V, 1.7kW power, 10 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0665 new or remanufactured?
Check the current product condition selection for S0665. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0665?
Compare 12V compatibility, 1.7kW power, 10 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
