S0696 12V 2.0kW Starter Motor Fits Toyota Camry, Toyota Carina E
Price range: £109.94 through £129.73
Sahibs S0696 is a replacement starter motor with a listed 12V 2.0kW rating. Listed applications include selected Toyota Camry, Toyota Carina E, Toyota Carina II, Toyota Corolla models. Identification references include Lucas LRS00696, Denso 128000-9560, Ford ESA129. Its listed 12V 2.0kW rating provides an electrical matching point for your existing unit. Check the 9/10|||9/10-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0696 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2 kW |
| Volt | 12 V |
| Plug | M8 |
| Rotation | Clockwise |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 6.04 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0696 | Dyno Electrics |
| 402820371 | Euro Car Part |
| UD102523S | AS-PL |
| 111564 | CARGO |
| F032111564 | CARGO |
| 128000-9560 | DENSO |
| 228000-0460 | DENSO |
| 228000-0880 | DENSO |
| ESA129 | FORD |
| 9.44281E+11 | MAGNETI MARELLI |
| MRS52285 | MAGNETI MARELLI |
| 28100-64290 | TOYOTA |
| 281006-4190 | TOYOTA |
| 281006-4210 | TOYOTA |
| STR7241 | 3EFFE |
| CGB-23253 | AINDE |
| ANM15473 | ANDEL |
| A15760 | ATL AUTOTECHNIK |
| SDN188A | AUTOTEAM |
| S512035 | BTS TURBO |
| CST40188AS | CASCO |
| CMA-641379 | COMLINE |
| 11844 | EAI |
| 25-0418 | ELSTOCK |
| 103320 | FARCOM |
| 8052285 | FRIESEN |
| JS774 | HC PARTS |
| 10040188AV | ITAB AUTOMOTIVE |
| STN0774 | KRAUF |
| 30699 | LESTER |
| LRS00696 | LUCAS |
| LRS696 | LUCAS |
| T521A43 | NPS |
| 190.938.102.050 | PSH |
| QRS1535 | QUINTON HAZELL |
| 20432881BN | REAL |
| 011-001-000246R | REMANTE |
| 6040188 | SANDO |
| 30699N | WAI / TRANSPO |
| STR30000 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S0610 | 1.4KW Length 218MM | 2.0KW Length 195MM | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| TOYOTA | Camry | 1.8 (1839ccm) Diesel | 1CTL | Liftback | CV10 | 1982 - 1985 | |
| TOYOTA | Camry | 1.8 (1839ccm) Diesel | 1CTL/1CTLC | CV10 | 1982 - 1985 | ||
| TOYOTA | Camry | 2.0 (1974ccm) Diesel | 2CT | Customwagon | CV20 | 1986 - 1991 | |
| TOYOTA | Camry | 2.0 (1974ccm) Diesel | 2CT | CV20 | 1988 - 1991 | ||
| TOYOTA | Carina E | 2.0 (1974ccm) Diesel | 2C | MK VI | CT190 | 1992 - 1994 | |
| TOYOTA | Carina II | 2.0 (1974ccm) Diesel | 2CL | MK IV | CT150 | 1983 - 1987 | |
| TOYOTA | Carina II | 2.0 (1974ccm) Diesel | 2CL | MK IV | Liftback | CT150 | 1983 - 1987 |
| TOYOTA | Carina II | 2.0 (1974ccm) Diesel | 2CL | MK IV | Liftback | CT150 | 1985 - 1987 |
| TOYOTA | Carina II | 2.0 (1974ccm) Diesel | 2C | MK V | Liftback | CT170 | 1987 - 1992 |
| TOYOTA | Carina II | 2.0 (1974ccm) Diesel | 2C | MK V | CT170 | 1987 - 1992 | |
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1C | CE70 | 1983 - 1983 | ||
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1C | Liftback | CE80 | 1983 - 1988 | |
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1CL | CE80 | 1983 - 1987 | ||
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1CL | Liftback | CE80 | 1983 - 1987 | |
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1C | CE90 | 1987 - 1993 | ||
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1C | Liftback | CE90 | 1987 - 1992 | |
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1C | Liftback | CE90 | 1989 - 1992 | |
| TOYOTA | Corolla | 1.8 (1839ccm) Diesel | 1C | CE90 | 1989 - 1993 | ||
| TOYOTA | Corolla | 2.0 (1974ccm) Diesel | 2C | CE100 | 1992 - 1997 | ||
| TOYOTA | Corolla | 2.0 (1974ccm) Diesel | 2C | Compact/Liftback | CE100 | 1992 - 1997 | |
| TOYOTA | Corolla Estate/Wagon | 1.8 (1839ccm) Diesel | 1C | RV Wagon | CE90 | 1987 - 1992 | |
| TOYOTA | Corolla Estate/Wagon | 1.8 (1839ccm) Diesel | 1C | RV Wagon | CE90 | 1989 - 1992 | |
| TOYOTA | Corolla Estate/Wagon | 2.0 (1974ccm) Diesel | 2C | RV Wagon | CE100 | 1992 - 1997 | |
| TOYOTA | Liteace | 1.8 (1839ccm) Diesel | 1C | CM35 | 1985 - 1992 | ||
| TOYOTA | Liteace | 2.0 (1974ccm) Diesel | 2C | CM30 | 1985 - 1992 | ||
| TOYOTA | Liteace | 2.0 (1974ccm) Diesel | 2C | CM36 | 1988 - 1998 |
Description
S0696 Replacement Starter Motor
For a S0696 starter motor enquiry, use Lucas reference LRS00696 alongside the vehicle and original unit details. The listed electrical rating is 12V 2.0kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Toyota Camry 1.8 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.0kW power: compare the listed rating with the original starter motor.
- 9/10|||9/10-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Toyota Camry 1.8 Diesel – selected applications 1982–1985 (engine code 1CTL).
- Toyota Carina E 2.0 Diesel – selected applications 1992–1994 (engine code 2C).
- Toyota Carina II 2.0 Diesel – selected applications 1983–1987 (engine code 2CL).
- Toyota Corolla 1.8 Diesel – selected applications 1983–1983 (engine code 1C).
- Toyota Corolla Estate/Wagon 1.8 Diesel – selected applications 1987–1992 (engine code 1C).
- Toyota Liteace 1.8 Diesel – selected applications 1985–1992 (engine code 1C).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0696. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
128000-9560, 228000-0460, 228000-0880, LRS00696, LRS696, ESA129
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0696 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0696 fit my Toyota Camry?
Toyota Camry 1.8 Diesel (1982–1985) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0696 replace Lucas LRS00696?
Lucas LRS00696 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0696?
The listed details include 12V, 2.0kW power, 9/10|||9/10 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0696 new or remanufactured?
Check the current product condition selection for S0696. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0696?
Compare 12V compatibility, 2.0kW power, 9/10|||9/10 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
