S0765 24V 4.0kW Starter Motor Fits Man Bus EL202, Man Bus NG272

Description

S0765 Replacement Starter Motor

The Sahibs S0765 starter motor is associated with Lucas reference LRS00765 for replacement identification. The listed electrical rating is 24V 4.0kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Man Bus EL202 variants.

Key Features and Benefits

• 24V electrical system: match the vehicle voltage before selecting a unit.
• 4.0kW power: compare the listed rating with the original starter motor.
• 11-tooth pinion: compare gear engagement and pinion position.
• Clockwise rotation: check the specified direction before fitting.
• M10 connector / terminal: check the connection against the original unit.

Compatible Vehicles and Applications

• Man Bus EL202 – selected applications 1993–1997 (engine code D0826LUH..).
• Man Bus NG272 – selected applications 1990–1995 (engine code D0826LUH..).
• Man Engines D0226 Industrial Engine – selected applications 1983 -.
• Man Engines D0826LUH11 – selected applications 1994–1998.
• Man Truck 10.136 – selected applications 1983–1987 (engine code D0226MF).
• Man Truck 10.15 – selected applications 1987–1993 (engine code D0826GF..).

These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.

OE Numbers and Cross-Reference Information

The following cross-reference numbers are associated with S0765. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.

1368056, 1368305, 1368310, 1368317, 986013720, 986017870, B001816592, 455622, 458343, LRS00765, LRS765, 19024286, DRS3720, DRS7870, 860818, 72735984, MS356, 11.130.626, 11.131.085, 11.131.144, AZJ3199, AZJ3374, AZJ3388, IS0626, 1516780R

The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.

When Should You Replace Your Starter Motor?

Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.

Why Buy from Sahibs Auto Electrics?

Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0765 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.

Frequently Asked Questions

Will S0765 fit my Man Bus EL202?

Man Bus EL202 (1993–1997) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.

Does S0765 replace Lucas LRS00765?

Lucas LRS00765 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.

What specifications are listed for S0765?

The listed details include 24V, 4.0kW power, 11 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.

Is S0765 new or remanufactured?

Check the current product condition selection for S0765. Confirm the supplier and availability of the option you want before completing the order.

What should I compare before ordering S0765?

Compare 24V compatibility, 4.0kW power, 11 pinion teeth, rotation, mounting and electrical connections with the original starter.

Does clicking prove the starter motor has failed?

No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
