S0828 12V 2.5kW Starter Motor Fits Alfa Romeo AR6, Fiat 131 Mirafiori
Price range: £123.34 through £146.63
The S0828 12V 2.5kW Starter Motor is a replacement starting unit from Sahibs Auto Electrics. Listed applications include selected Alfa Romeo AR6, Fiat 131 Mirafiori, Fiat 132, Fiat Argenta models. Identification references include Lucas LRS00828, Bosch 1218024, Valeo 436045. Its listed 12V 2.5kW rating provides an electrical matching point for your existing unit. Check the 9-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0828 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.5 kW |
| Volt | 12 V |
| Plug | M10 |
| Rotation | Clockwise |
| Teeth | 9 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 10.6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0828 | Dyno Electrics |
| 402650201 | Euro Car Part |
| S0148 | AS-PL |
| 1218024 | BOSCH |
| 1218103 | BOSCH |
| 1218703 | BOSCH |
| 986013660 | BOSCH |
| 113846 | CARGO |
| F032113846 | CARGO |
| 1516765R | DAF |
| DRS3660 | DELCO |
| 46231640 | FIAT |
| 46231642 | FIAT |
| 4741699 | FIAT |
| 7565668 | FIAT |
| 7580575 | FIAT |
| 7666132 | FIAT |
| 7666135 | FIAT |
| 77671430 | FIAT |
| 8EA726158-001 | HELLA |
| 943252858 | MAGNETI MARELLI |
| 436045 | VALEO |
| STRL895 | 3EFFE |
| ANM15880X | ANDEL |
| AES8128 | AUTOELECTRO |
| CST10140AS | CASCO |
| CST10140RS | CASCO |
| 3454 | CEVAM |
| 33545 | EAI |
| STR10149 | ELECTROLOG |
| STR10158 | ELECTROLOG |
| STR10159 | ELECTROLOG |
| 25-1147 | ELSTOCK |
| 220050 | ERA |
| 220183 | ERA |
| 8813660 | FRIESEN |
| CS510 | HC PARTS |
| 10510 | KUHNER |
| 22.051 | LAUBER |
| 331710 | LOGISTIK |
| LRS00828 | LUCAS |
| LRS828 | LUCAS |
| 8212981 | POWERMAX |
| 500.505.093.010 | PSH |
| 500.505.093.550 | PSH |
| 20401041BN | REAL |
| 20401041RC | REAL |
| 6010140 | SANDO |
| S12BH0262A2 | SIDAT |
| MAV2120 | SIOM |
| MAV6720 | SIOM |
| SS669 | SOVEREIGN |
| SS671 | SOVEREIGN |
| STX200299 | STARDAX |
| STX200341 | STARDAX |
| STX200691 | STARDAX |
| 32160R | WAI / TRANSPO |
| STR50140 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S1160 | 2.5KW Conventionel | 2.2KW G/R | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| ALFA ROMEO | AR6 | 2.4 (2445ccm) Diesel | 814061 | 280 | 1985 - 1986 | ||
| ALFA ROMEO | AR6 | 2.5 (2499ccm) Diesel | 814467 | 280 | 1986 - 1989 | ||
| FIAT | 131 Mirafiori | 2.0 (1995ccm) Diesel | 814465 | Panorama | 131AB/131AF | 1977 - 1983 | |
| FIAT | 131 Mirafiori | 2.0 (1995ccm) Diesel | 814465 | 131A/131AA | 1977 - 1983 | ||
| FIAT | 131 Mirafiori | 2.5 (2445ccm) Diesel | 814061 | Panorama | 131AB/131AFZ | 1977 - 1984 | |
| FIAT | 132 | 2.0 (1995ccm) Diesel | 814465 | 132A | 1975 - 1981 | ||
| FIAT | 132 | 2.4 (2445ccm) Diesel | 814061 | 132A | 1978 - 1981 | ||
| FIAT | Argenta | 2.4 (2445ccm) Diesel | 814481 | 132A3 | 1983 - 1985 | ||
| FIAT | Ducato 10 | 2.4 (2445ccm) Diesel | 814061 | 280A | 1981 - 1990 | ||
| FIAT | Ducato 14 | 2.4 (2445ccm) Diesel | 814061 | 280A | 1981 - 1986 | ||
| FIAT | Ducato 14 | 2.5 (2499ccm) Diesel | 814467 | 290EH5W/290EH7W | 1990 - 1994 | ||
| FIAT | Ducato 14 | 2.5 (2499ccm) Diesel | 814467 | 290B7/290D7 | 1990 - 1994 | ||
| FIAT | Ducato 14 | 2.5 (2499ccm) Diesel | 814467 | 290MA7W | 1990 - 1994 | ||
| FIAT | Ducato 14 | 2.5 (2499ccm) Diesel | 814467 | 290EH5V | 1990 - 1994 | ||
| FIAT | Ducato 14 | 2.5 (2499ccm) Diesel | 814467 | Camping Car | 290MA7/290MT7/290NA7/290NT7/290NZ7/290PA7/290RAP7/290RTP7 | 1990 - 1994 | |
| FIAT | Ducato 15 | 2.4 (2445ccm) Diesel | 814061 | Supercoach | 280E | 1986 - 1990 | |
| FIAT | Ducato 15 | 2.5 (2499ccm) Diesel | 814467 | 280A | 1982 - 1990 | ||
| FIAT | Ducato 15 | 2.5 (2499ccm) Diesel | 814467 | Supercoach | 280A | 1982 - 1990 | |
| FIAT | Ducato 15 | 2.5 (2499ccm) Diesel | 814467 | Panorama | 280A | 1986 - 1990 | |
| FIAT | Ducato 15 | 2.5 (2499ccm) Diesel | 814467 | Supercoach | 280E | 1989 - 1990 | |
| FIAT | Ducato 15 | 2.5 (2499ccm) Diesel | 814467 | 280E | 1989 - 1990 | ||
| FIAT | Ducato 15 | 2.5 (2499ccm) Diesel | 814467 | Panorama | 290EP5 | 1990 - 1994 | |
| FIAT | Ducato 18 | 2.4 (2445ccm) Diesel | 814061 | 280A | 1981 - 1990 | ||
| FIAT | Ducato 18 | 2.4 (2445ccm) Diesel | 814061 | Supercoach | 280E | 1986 - 1990 | |
| FIAT | Ducato 18 | 2.5 (2499ccm) Diesel | 814467 | 280A | 1982 - 1990 | ||
| FIAT | Ducato 18 | 2.5 (2499ccm) Diesel | 814467 | Panorama | 280E | 1986 - 1990 | |
| FIAT | Ducato 18 | 2.5 (2499ccm) Diesel | 814467 | Panorama | 280A | 1986 - 1990 | |
| FIAT | Ducato 18 | 2.5 (2499ccm) Diesel | 814467 | 280E | 1989 - 1990 | ||
| FIAT | Ducato 18 | 2.5 (2499ccm) Diesel | 814467 | 290RTP7 | 1990 - 1994 | ||
| FIAT | Ducato 18 | 2.5 (2499ccm) Diesel | 814467 | 290R7/290RAC7 | 1990 - 1994 | ||
| SEAT | 131 | 2.4 (2445ccm) Diesel | 131D24 | 131A | 1979 - 1983 |
Description
S0828 Replacement Starter Motor
The S0828 starter motor is a replacement unit identified by Lucas reference LRS00828. The listed electrical rating is 12V 2.5kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Alfa Romeo AR6 2.4 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.5kW power: compare the listed rating with the original starter motor.
- 9-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M10 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Alfa Romeo AR6 2.4 Diesel – selected applications 1985–1986 (engine code 814061).
- Fiat 131 Mirafiori 2.0 Diesel – selected applications 1977–1983 (engine code 814465).
- Fiat 132 2.0 Diesel – selected applications 1975–1981 (engine code 814465).
- Fiat Argenta 2.4 Diesel – selected applications 1983–1985 (engine code 814481).
- Fiat Ducato 10 2.4 Diesel – selected applications 1981–1990 (engine code 814061).
- Fiat Ducato 14 2.4 Diesel – selected applications 1981–1986 (engine code 814061).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0828. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1218024, 1218103, 1218703, 986013660, 436045, LRS00828, LRS828, DRS3660, 1516765R
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0828 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0828 fit my Alfa Romeo AR6?
Alfa Romeo AR6 2.4 Diesel (1985–1986) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0828 replace Lucas LRS00828?
Lucas LRS00828 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0828?
The listed details include 12V, 2.5kW power, 9 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0828 new or remanufactured?
Check the current product condition selection for S0828. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0828?
Compare 12V compatibility, 2.5kW power, 9 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
