S0932 12V 3.0kW Starter Motor Fits Hürlimann HÜRLIMANN
Price range: £86.39 through £101.94
Compare the S0932 12V 3.0kW starter motor from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected HÜRlimann HÜRLIMANN, Lamborghini Tractor 115 Formula, Lamborghini Tractor 135 Formula, Lamborghini Tractor 674-70 models. Identification references include Lucas LRS00932, Bosch 1358020, Valeo 406090009. Its listed 12V 3.0kW rating provides an electrical matching point for your existing unit. Check the 11-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0932 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 3 kW |
| Volt | 12 V |
| Plug | M10 |
| Rotation | Clockwise |
| Teeth | 11 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 13.34 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0932 | Dyno Electrics |
| S0114 | AS-PL |
| UD12954S | AS-PL |
| 1358020 | BOSCH |
| 1358051 | BOSCH |
| 1359108 | BOSCH |
| 1367013 | BOSCH |
| 1367035 | BOSCH |
| 986012710 | BOSCH |
| 110530 | CARGO |
| F032110530 | CARGO |
| 19024238 | DELCO |
| DRS2710 | DELCO |
| 8EA726083-001 | HELLA |
| 11.130.201 | ISKRA / LETRIKA |
| AZJ3537 | ISKRA / LETRIKA |
| IS0201 | ISKRA / LETRIKA |
| 63216814 | MAGNETI MARELLI |
| 63216876 | MAGNETI MARELLI |
| 63216884 | MAGNETI MARELLI |
| 943216876 | MAGNETI MARELLI |
| MT41B | MAGNETI MARELLI |
| MT68P | MAGNETI MARELLI |
| MT68PA | MAGNETI MARELLI |
| MT68PB | MAGNETI MARELLI |
| 9142880 | MAGNETON |
| MS58 | MAHLE |
| 406090009 | VALEO |
| CGB-22710 | AINDE |
| ANM14930X | ANDEL |
| CST10151AS | CASCO |
| CST10151ES | CASCO |
| CST10151GS | CASCO |
| 8049 | CEVAM |
| 260-67117 | DIXIE |
| STR10056 | ELECTROLOG |
| STR1331 | ELECTROLOG |
| STR7883 | ELECTROLOG |
| 25-0287 | ELSTOCK |
| CS335 | HC PARTS |
| STB0202 | KRAUF |
| 10335 | KUHNER |
| 10335B | KUHNER |
| 10335I | KUHNER |
| 10335M | KUHNER |
| 296191400 | LAMBORGHINI |
| 296191800 | LAMBORGHINI |
| 330487 | LOGISTIK |
| LRS00932 | LUCAS |
| LRS932 | LUCAS |
| 610.001.112.010 | PSH |
| 610.001.112.016 | PSH |
| 610.001.112.311 | PSH |
| 610.001.112.350 | PSH |
| 20401151BN | REAL |
| 20401151EL | REAL |
| 20401151OE | REAL |
| 120-30232 | ROBERT'S |
| 29619400 | SAME |
| 296194000 | SAME |
| 6010151 | SANDO |
| 6010151.1 | SANDO |
| 6010151.3 | SANDO |
| MAV121510 | SIOM |
| MAV121510A | SIOM |
| STX210069 | STARDAX |
| 407090009 | STEYR |
| 40800090008 | STEYR |
| 91-15-7061 | WILSON |
| STR50155 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S2242 | 3.0 kW | 2.2 kW | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | H-1104/9T | 1984 - 1989 | |||
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | 1000.4WT | 1986 - 2001 | |||
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | 1000.4W | 1988 - 1991 | |||
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | 1000.6W | 1989 - 2004 | |||
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | 1000.6WT | 1989 - 2004 | |||
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | 1000.6WTI | 1991 - | |||
| HÜRLIMANN | HÜRLIMANN | 0ccm Diesel | 1000.6WTIR | 1992 - | |||
| LAMBORGHINI TRACTOR | 115 Formula | 0ccm Diesel | 1000.6W | 1989 - 1999 | |||
| LAMBORGHINI TRACTOR | 135 Formula | 0ccm Diesel | 1000.6WT | 1989 - 1999 | |||
| LAMBORGHINI TRACTOR | 674-70 | 0ccm Diesel | 1000.4W | 1986 - 1999 | |||
| LAMBORGHINI TRACTOR | 774-80 | 0ccm Diesel | 1000.4W | 1986 - 1999 | |||
| LAMBORGHINI TRACTOR | 874-90 | 0ccm Diesel | 1000.4W | 1986 - 1999 | |||
| LAMBORGHINI TRACTOR | R613 DT | 0ccm Diesel | 105.3P | 1982 - 1988 | |||
| LAMBORGHINI TRACTOR | R724 F | 0ccm Diesel | 100.4P | 1986 - 1986 | |||
| LAMBORGHINI TRACTOR | R754 | 0ccm Diesel | 105.4P | 1982 - 1985 | |||
| LAMBORGHINI TRACTOR | R955 DT | 0ccm Diesel | 105.5P | 1979 - 1985 | |||
| SAME | Antares 110 | 0ccm Diesel | 1000.6A | 1989 - 1994 | |||
| SAME | Antares 130 | 0ccm Diesel | 1000.6AT | 1989 - 1994 | |||
| SAME | Explorer 75 | 0ccm Diesel | 916.4A | 1985 - 1986 | |||
| SAME | Explorer 85 | 0ccm Diesel | 916.4TA | 1985 - 1986 | |||
| SAME | Galaxy 170 | 0ccm Diesel | 105.6 PTI | 1983 - 1991 | |||
| SAME | Hercules 160 | 0ccm Diesel | 105.6PT | 1979 - 1983 | |||
| SAME | Laser 110 | 0ccm Diesel | 100.6P | 1983 - 1987 | |||
| SAME | Laser 130 | 0ccm Diesel | 105.6P | 1983 - 1987 | |||
| SAME | Laser 150 | 0ccm Diesel | 105.6PS | 1983 - 1987 | |||
| SAME | Titan 160 | 0ccm Diesel | 1000.6 ATI | 1992 - 1994 | |||
| SAME | Titan 190 | 0ccm Diesel | 1000.6 WTIR | 1992 - 1994 |
Description
S0932 Replacement Starter Motor
Choose a replacement by comparing the S0932 starter motor and its Lucas reference, LRS00932, with your existing unit. The listed electrical rating is 12V 3.0kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected HÜRlimann HÜRLIMANN variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 3.0kW power: compare the listed rating with the original starter motor.
- 11-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M10 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- HÜRlimann HÜRLIMANN – selected applications 1984–1989 (engine code H-1104/9T).
- Lamborghini Tractor 115 Formula – selected applications 1989–1999 (engine code 1000.6W).
- Lamborghini Tractor 135 Formula – selected applications 1989–1999 (engine code 1000.6WT).
- Lamborghini Tractor 674-70 – selected applications 1986–1999 (engine code 1000.4W).
- Lamborghini Tractor 774-80 – selected applications 1986–1999 (engine code 1000.4W).
- Lamborghini Tractor 874-90 – selected applications 1986–1999 (engine code 1000.4W).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0932. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1358020, 1358051, 1359108, 1367013, 1367035, 986012710, 406090009, LRS00932, LRS932, 19024238, DRS2710, MS58, 11.130.201, AZJ3537, IS0201
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0932 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0932 fit my HÜRlimann HÜRLIMANN?
HÜRlimann HÜRLIMANN (1984–1989) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0932 replace Lucas LRS00932?
Lucas LRS00932 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0932?
The listed details include 12V, 3.0kW power, 11 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0932 new or remanufactured?
Check the current product condition selection for S0932. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0932?
Compare 12V compatibility, 3.0kW power, 11 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
