S1279 12V 2.2kW Starter Motor Fits Atlas Copco XAS45
Price range: £118.96 through £142.24
The S1279 12V 2.2kW Starter Motor is a replacement starting unit from Sahibs Auto Electrics. Listed applications include selected Atlas Copco XAS45, Khd Engines BF4L1011, Khd Engines F2L1011, Khd Engines F3L1011 models. Identification references include Lucas LRS01279, Bosch 1362700, Delco Remy DRS5420. Its listed 12V 2.2kW rating provides an electrical matching point for your existing unit. Check the 11-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S1279 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.2 kW |
| Volt | 12 V |
| Plug | M10 |
| Rotation | Clockwise |
| Teeth | 11 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 11.77 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS1279 | Dyno Electrics |
| 402770931 | Euro Car Part |
| S0496 | AS-PL |
| UD90023S | AS-PL |
| 1362700 | BOSCH |
| 986015420 | BOSCH |
| 112020 | CARGO |
| 112041 | CARGO |
| F032112020 | CARGO |
| F032112041 | CARGO |
| DRS5420 | DELCO |
| DRS5420N | DELCO |
| 8EA737792-001 | HELLA |
| 11.130.565 | ISKRA / LETRIKA |
| AZJ3177 | ISKRA / LETRIKA |
| 1177441 | KHD |
| 1178670 | KHD |
| 1179470 | KHD |
| 1178620 | KHD |
| MS 219 | MAHLE |
| 20513051 | PRESTOLITE |
| 2904386 | VOLVO |
| STRS253 | 3EFFE |
| CGB-25420 | AINDE |
| ANM17640X | ANDEL |
| CST10271 | CASCO |
| CST10271AS | CASCO |
| CST10271ES | CASCO |
| CST10271GS | CASCO |
| CST10271OS | CASCO |
| CST10271RS | CASCO |
| 8467 | CEVAM |
| 8628 | CEVAM |
| 33887 | EAI |
| STR1116 | ELECTROLOG |
| 25-1489 | ELSTOCK |
| 8815420 | FRIESEN |
| CS1184 | HC PARTS |
| 101184 | KUHNER |
| 22.1184 | LAUBER |
| 331336 | LOGISTIK |
| LRS01279 | LUCAS |
| LRS1279 | LUCAS |
| 5010418 | MEAT & DORIA |
| 8212676 | POWERMAX |
| 560.003.113 | PSH |
| 20401172BN | REAL |
| 6010271 | SANDO |
| S12BH0361A2 | SIDAT |
| MAV122710 | SIOM |
| 17318N | WAI / TRANSPO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| ATLAS COPCO | XAS45 | 0ccm Diesel | KHD F2L1011 | 1989 - | |||
| KHD ENGINES | BF4L1011 | 2732ccm Diesel | 1989 - 1994 | ||||
| KHD ENGINES | F2L1011 | 0ccm Diesel | 1989 - 1994 | ||||
| KHD ENGINES | F3L1011 | 0ccm Diesel | 1989 - 1994 | ||||
| KHD ENGINES | F4L1011 | 0ccm Diesel | 1989 - 1994 |
Description
S1279 Replacement Starter Motor
The Sahibs S1279 starter motor is associated with Lucas reference LRS01279 for replacement identification. The listed electrical rating is 12V 2.2kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Atlas Copco XAS45 variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.2kW power: compare the listed rating with the original starter motor.
- 11-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M10 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Atlas Copco XAS45 – selected applications 1989 – (engine code KHD F2L1011).
- Khd Engines BF4L1011 2732ccm Diesel – selected applications 1989–1994.
- Khd Engines F2L1011 – selected applications 1989–1994.
- Khd Engines F3L1011 – selected applications 1989–1994.
- Khd Engines F4L1011 – selected applications 1989–1994.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S1279. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1362700, 986015420, LRS01279, LRS1279, DRS5420, DRS5420N, 20513051, MS 219, 11.130.565, AZJ3177
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S1279 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S1279 fit my Atlas Copco XAS45?
Atlas Copco XAS45 (1989 -) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S1279 replace Lucas LRS01279?
Lucas LRS01279 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S1279?
The listed details include 12V, 2.2kW power, 11 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S1279 new or remanufactured?
Check the current product condition selection for S1279. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S1279?
Compare 12V compatibility, 2.2kW power, 11 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
