S1422 12V 2.2kW Starter Motor Fits Atlas Copco XAS125
Price range: £138.75 through £161.70
Sahibs S1422 is a replacement starter motor with a listed 12V 2.2kW rating. Listed applications include selected Atlas Copco XAS125, Khd Engines BF4L1011, Khd Engines F2L1011, Khd Engines F3L1011 models. Identification references include Lucas LRS01422, Bosch 1109370, Delco Remy DRS7430. Its listed 12V 2.2kW rating provides an electrical matching point for your existing unit. Check the 11-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S1422 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.2 kW |
| Volt | 12 V |
| Plug | M8 |
| Rotation | Clockwise |
| Teeth | 11 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 5.7 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS1422 | Dyno Electrics |
| S0066 | AS-PL |
| 1109370 | BOSCH |
| 1218172 | BOSCH |
| 1218772 | BOSCH |
| 1223002 | BOSCH |
| 986017430 | BOSCH |
| 986018290 | BOSCH |
| 111855 | CARGO |
| F032111855 | CARGO |
| DRS7430 | DELCO |
| 2934505 | DEUTZ |
| 3045250 | DEUTZ |
| 8EA737793-001 | HELLA |
| 11.131.951 | ISKRA / LETRIKA |
| IS1072 | ISKRA / LETRIKA |
| 1180995 | KHD |
| 01180995KZ | KHD |
| 2934613 | KHD |
| 2934631 | KHD |
| 11180180 | KHD |
| 1180180 | KHD |
| 1180995KZ | KHD |
| 2934505 | KHD |
| MS 30 | MAHLE |
| 20500534 | PRESTOLITE |
| 20513069 | PRESTOLITE |
| 35261130 | PRESTOLITE |
| 9002904386 | VOLVO |
| VOE9002908534 | VOLVO |
| 069911023F | VW |
| STRS048 | 3EFFE |
| CGB-27430 | AINDE |
| ANM19650X | ANDEL |
| AEU1185 | AUTOELECTRO |
| STA0341R | BOVEZ |
| CST10142AS | CASCO |
| CST10142GS | CASCO |
| CST10443AS | CASCO |
| 8505 | CEVAM |
| 33887 | EAI |
| STR1162 | ELECTROLOG |
| STR1181 | ELECTROLOG |
| STR7873 | ELECTROLOG |
| 25-2321 | ELSTOCK |
| 25-2390 | ELSTOCK |
| 220333 | ERA |
| 8817430 | FRIESEN |
| CS1185 | HC PARTS |
| 101185 | KUHNER |
| 101185B | KUHNER |
| 10347 | KUHNER |
| 22.1185 | LAUBER |
| 28.1185 | LAUBER |
| 28.1185M | LAUBER |
| LRS01422 | LUCAS |
| LRS1422 | LUCAS |
| 5010338 | MEAT & DORIA |
| 8212215 | POWERMAX |
| 510.501.112 | PSH |
| 510.501.112.460 | PSH |
| 510.501.112.461 | PSH |
| 510.501.112.605 | PSH |
| 20401241BN | REAL |
| 20401241OE | REAL |
| 20401344BN | REAL |
| RNL1829 | RNL |
| 6010142 | SANDO |
| 6010443 | SANDO |
| S12BH0266A2 | SIDAT |
| S12BH0268 | SIDAT |
| S12BH0268A2 | SIDAT |
| S12ML0667A2 | SIDAT |
| MAV121420 | SIOM |
| STX200236 | STARDAX |
| STX200236R | STARDAX |
| STX210088 | STARDAX |
| 18230N | WAI / TRANSPO |
| STR22027 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S1457 | 2.2KW, Length: 261MM | 2.3KW, Length: 190MM | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| ATLAS COPCO | XAS125 | 0ccm Diesel | KHD BF46 | ||||
| KHD ENGINES | BF4L1011 | 2732ccm Diesel | 1995 - | ||||
| KHD ENGINES | F2L1011 | 0ccm Diesel | 1995 - | ||||
| KHD ENGINES | F3L1011 | 0ccm Diesel | 1995 - | ||||
| KHD ENGINES | F4L1011 | 0ccm Diesel | 1995 - |
Description
S1422 Replacement Starter Motor
Choose a replacement by comparing the S1422 starter motor and its Lucas reference, LRS01422, with your existing unit. The listed electrical rating is 12V 2.2kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Atlas Copco XAS125 variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.2kW power: compare the listed rating with the original starter motor.
- 11-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Atlas Copco XAS125 (engine code KHD BF46).
- Khd Engines BF4L1011 2732ccm Diesel – selected applications 1995 -.
- Khd Engines F2L1011 – selected applications 1995 -.
- Khd Engines F3L1011 – selected applications 1995 -.
- Khd Engines F4L1011 – selected applications 1995 -.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S1422. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1109370, 1218172, 1218772, 1223002, 986017430, 986018290, LRS01422, LRS1422, DRS7430, 20500534, 20513069, 35261130, MS 30, MS30, 11.131.951, IS1072
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S1422 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S1422 fit my Atlas Copco XAS125?
Atlas Copco XAS125 is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S1422 replace Lucas LRS01422?
Lucas LRS01422 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S1422?
The listed details include 12V, 2.2kW power, 11 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S1422 new or remanufactured?
Check the current product condition selection for S1422. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S1422?
Compare 12V compatibility, 2.2kW power, 11 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
