S4055 24V 4.0kW Starter Motor Fits Iveco Marine N60ENTM27
Price range: £171.18 through £203.49
The S4055 24V 4.0kW Starter Motor is a replacement starting unit from Sahibs Auto Electrics. Listed applications include selected Iveco Marine N60ENTM27, Iveco Marine N60ENTM33, Iveco Marine N60ENTM37, Iveco Marine N60ENTM40 models. Identification references include Lucas LRS04055, Delco Remy DRS0028, Mahle 72735718. Its listed 24V 4.0kW rating provides an electrical matching point for your existing unit. Check the 10-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S4055 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 4 kW |
| Volt | 24 V |
| Rotation | Clockwise |
| Teeth | 10 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 10.16 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS4055 | Dyno Electrics |
| UD812392(LETRIKA)S | AS-PL |
| DRS0028 | DELCO |
| 11.131.271 | ISKRA / LETRIKA |
| AZF4572 | ISKRA / LETRIKA |
| IS1095 | ISKRA / LETRIKA |
| 8036231 | IVECO |
| 72735718 | MAHLE |
| MS90 | MAHLE |
| CST21613AS | CASCO |
| CST21613GS | CASCO |
| 8136 | CEVAM |
| 45-5218 | ELSTOCK |
| 255238M | KUHNER |
| LRS04055 | LUCAS |
| LRS4055 | LUCAS |
| 88213899 | POWERMAX |
| 501.516.103.090 | PSH |
| 501.516.103.310 | PSH |
| 20419316BN | REAL |
| 20419316OE | REAL |
| 182-30325 | ROBERT'S |
| 6021613 | SANDO |
| 6021613.1 | SANDO |
| WOOSTR60730 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S2531 | Insulated ground | Not insulated ground | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| IVECO MARINE | N60ENTM27 | 5900ccm Diesel | 2003 - | ||||
| IVECO MARINE | N60ENTM33 | 5900ccm Diesel | 2003 - | ||||
| IVECO MARINE | N60ENTM37 | 5900ccm Diesel | 2003 - | ||||
| IVECO MARINE | N60ENTM40 | 5900ccm Diesel | 2003 - | ||||
| IVECO MARINE | N60ENTM48 | 5900ccm Diesel | 2003 - |
Description
S4055 Replacement Starter Motor
The S4055 starter motor is a replacement unit identified by Lucas reference LRS04055. The listed electrical rating is 24V 4.0kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Iveco Marine N60ENTM27 5900ccm Diesel variants.
Key Features and Benefits
- 24V electrical system: match the vehicle voltage before selecting a unit.
- 4.0kW power: compare the listed rating with the original starter motor.
- 10-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M10 B+ connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Iveco Marine N60ENTM27 5900ccm Diesel – selected applications 2003 -.
- Iveco Marine N60ENTM33 5900ccm Diesel – selected applications 2003 -.
- Iveco Marine N60ENTM37 5900ccm Diesel – selected applications 2003 -.
- Iveco Marine N60ENTM40 5900ccm Diesel – selected applications 2003 -.
- Iveco Marine N60ENTM48 5900ccm Diesel – selected applications 2003 -.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S4055. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
LRS04055, LRS4055, DRS0028, 72735718, MS90, 11.131.271, AZF4572, IS1095
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S4055 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S4055 fit my Iveco Marine N60ENTM27?
Iveco Marine N60ENTM27 5900ccm Diesel (2003 -) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S4055 replace Lucas LRS04055?
Lucas LRS04055 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S4055?
The listed details include 24V, 4.0kW power, 10 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S4055 new or remanufactured?
Check the current product condition selection for S4055. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S4055?
Compare 24V compatibility, 4.0kW power, 10 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
