T0170 12V 2.2kW Starter Motor Fits Land Rover Range Rover, BMW 324d
Price range: £118.91 through £141.36
Identify a replacement starter motor using Sahibs T0170, listed at 12V 2.2kW. Listed applications include selected Land Rover Range Rover, BMW 324d, BMW 524d, Opel Omega models. Identification references include Lucas LRT00170, Bosch 1109025, Valeo 436040. Its listed 12V 2.2kW rating provides an electrical matching point for your existing unit. Check the 9-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your T0170 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.2 kW |
| Volt | 12 V |
| Plug | M8 |
| Rotation | Clockwise |
| Teeth | 9 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 5.8 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYT0170 | Dyno Electrics |
| 402110101 | Euro Car Part |
| S0493 | AS-PL |
| UD90011S | AS-PL |
| 12411285081 | BMW |
| 12411287788 | BMW |
| 12411288166 | BMW |
| 12411289520 | BMW |
| 12412242231 | BMW |
| 12412242619 | BMW |
| 12412242702 | BMW |
| 12412242703 | BMW |
| 12412244344 | BMW |
| 12412246570 | BMW |
| 12412446570 | BMW |
| 1241285081 | BMW |
| 12414371646 | BMW |
| 12419069808 | BMW |
| 1287788 | BMW |
| 1288166 | BMW |
| 1289520 | BMW |
| 2244344 | BMW |
| 9.43222E+11 | BMW |
| 9.43252E+11 | BMW |
| 1109025 | BOSCH |
| 1218009 | BOSCH |
| 1218026 | BOSCH |
| 1218134 | BOSCH |
| 1218171 | BOSCH |
| 1218771 | BOSCH |
| 986012620 | BOSCH |
| 112533 | CARGO |
| F032112533 | CARGO |
| 8EA726126-001 | HELLA |
| 63222035010 | MAGNETI MARELLI |
| 63222035 | MAGNETI MARELLI |
| 943222035 | MAGNETI MARELLI |
| 943251687 | MAGNETI MARELLI |
| 9.4428E+11 | MAGNETI MARELLI |
| MRS12620 | MAGNETI MARELLI |
| MSN320 | MAGNETI MARELLI |
| 20513030 | PRESTOLITE |
| ERR5445 | ROVER |
| NAD10037 | ROVER |
| NAD100370 | ROVER |
| 436040 | VALEO |
| 726057 | VALEO |
| STRL047 | 3EFFE |
| STRL106 | 3EFFE |
| STRW219 | 3EFFE |
| STA0117R | BOVEZ |
| CST30133 | CASCO |
| CST30133AS | CASCO |
| CST30133ES | CASCO |
| CST30133GS | CASCO |
| CST30133OS | CASCO |
| CST30133RS | CASCO |
| 3535 | CEVAM |
| S-6074 | DIXIE |
| 11148 | EAI |
| STR1340 | ELECTROLOG |
| STR1570 | ELECTROLOG |
| STR1571 | ELECTROLOG |
| 25-1023 | ELSTOCK |
| 220091 | ERA |
| SG0748 | GHIBAUDI |
| CS378 | HC PARTS |
| STB0378 | KRAUF |
| 10378 | KUHNER |
| 10984 | KUHNER |
| LRT00170 | LUCAS |
| LRT170 | LUCAS |
| 210.501.092 | PSH |
| 20404331RC | REAL |
| 6030133 | SANDO |
| S12BH0172A2 | SIDAT |
| S12BH0426A2 | SIDAT |
| MAV122100 | SIOM |
| MAV321330 | SIOM |
| STX200028 | STARDAX |
| STX200141 | STARDAX |
| STX200141R | STARDAX |
| STX200166 | STARDAX |
| STX200166R | STARDAX |
| 31170N | WAI / TRANSPO |
| 31171R | WAI / TRANSPO |
| 91-15-6995 | WILSON |
| STR50184 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S1475 | 2.2KW With out thread in front housing | 2.2kw With 2x M10 x 1.5 thread in front housing | No |
| S1792 | 2.2 kW, Ø10 in mounting holes, long | 2.1 kW, M10 thread in mounting holes, short | No |
| S1382 | 2.2 kW, Ø10 in mounting holes | 2.0KW M10 thread in mounting holes | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| BMW | 324d | 2.4 (2443ccm) Diesel | M21D246DA/M21D246DB | E30 | 1985 - 1990 | ||
| BMW | 324d | 2.4 (2443ccm) Diesel | M21D246TB | E30 | 1987 - 1990 | ||
| BMW | 524d | 2.4 (2443ccm) Diesel | M21D246TA | E28 | 1982 - 1987 | ||
| BMW | 524d | 2.4 (2443ccm) Diesel | M21D246DA | E28 | 1986 - 1987 | ||
| BMW | 524d | 2.4 (2443ccm) Diesel | M21D246TB | E34 | 1988 - 1991 | ||
| LAND ROVER | Range Rover | 2.5 (2497ccm) Diesel | M51256T | MK II | P38A | 1994 - 2002 | |
| OPEL | Omega | 2.5 (2498ccm) Diesel | U25DT/U25TD/X25DT/X25TD | B | F35/M35/P35 | 1994 - 1996 | |
| OPEL | Omega | 2.5 (2498ccm) Diesel | U25DT/U25TD/X25DT/X25TD | B | F69/M69/P69 | 1994 - 1996 |
Description
T0170 Replacement Starter Motor
Choose a replacement by comparing the T0170 starter motor and its Lucas reference, LRT00170, with your existing unit. The listed electrical rating is 12V 2.2kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Land Rover Range Rover 2.5 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.2kW power: compare the listed rating with the original starter motor.
- 9-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Land Rover Range Rover 2.5 Diesel – selected applications 1994–2002 (engine code M51256T).
- BMW 324d 2.4 Diesel – selected applications 1985–1990 (engine code M21D246DA/M21D246DB).
- BMW 524d 2.4 Diesel – selected applications 1982–1987 (engine code M21D246TA).
- Opel Omega 2.5 Diesel – selected applications 1994–1996 (engine code U25DT/U25TD/X25DT/X25TD).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with T0170. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1109025, 1218009, 1218026, 1218134, 1218171, 1218771, 986012620, 436040, 726057, LRT00170, LRT170, 20513030, ERR5445, NAD10037, NAD100370
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying T0170 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will T0170 fit my Land Rover Range Rover?
Land Rover Range Rover 2.5 Diesel (1994–2002) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does T0170 replace Lucas LRT00170?
Lucas LRT00170 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for T0170?
The listed details include 12V, 2.2kW power, 9 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is T0170 new or remanufactured?
Check the current product condition selection for T0170. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering T0170?
Compare 12V compatibility, 2.2kW power, 9 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
