A0547 12V 60A Alternator Fits Mazda 323, Mazda 323 Estate/Wagon
Price range: £130.00 through £208.00
Sahibs A0547 is a replacement alternator with a listed 12V 60A rating. Listed applications include selected Mazda 323, Mazda 323 Estate/Wagon models. Identification references include Lucas LRA00547, Bosch 120484035, Mitsubishi Electric A002T05572. Its listed 12V 60A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0547 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 60 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 45 mm |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.75 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0547 | Dyno Electrics |
| 401680051 | Euro Car Part |
| A5426S | AS-PL |
| UD21153A | AS-PL |
| 120484035 | BOSCH |
| 986036331 | BOSCH |
| 986037701 | BOSCH |
| 9120690380 | BOSCH |
| 112297 | CARGO |
| F032112297 | CARGO |
| 219053 | DELCO |
| DRA3027 | DELCO |
| 8EL726318001 | HELLA |
| 9.43E+11 | MAGNETI MARELLI |
| 9.44E+11 | MAGNETI MARELLI |
| Mar-72 | MAGNETI MARELLI |
| MRA51321 | MAGNETI MARELLI |
| B11318300 | MAZDA |
| B11318300A | MAZDA |
| B11518300 | MAZDA |
| B64J18300A | MAZDA |
| B675-18-300 | MAZDA |
| B675-18-300A | MAZDA |
| B675-18-300D | MAZDA |
| B67513300 | MAZDA |
| B67513300A | MAZDA |
| B67518300B | MAZDA |
| B67518300C | MAZDA |
| B67518300E | MAZDA |
| B67518300R | MAZDA |
| B68518300 | MAZDA |
| E8GY10346 | MAZDA |
| A002T05572 | MITSUBISHI |
| A002T05772 | MITSUBISHI |
| A002T05772X | MITSUBISHI |
| A002T07572 | MITSUBISHI |
| A005T00972 | MITSUBISHI |
| A005T01271 | MITSUBISHI |
| A2T05572 | MITSUBISHI |
| A2T05772 | MITSUBISHI |
| A2T05772X | MITSUBISHI |
| A2T07572 | MITSUBISHI |
| A5T00972 | MITSUBISHI |
| A5T01271 | MITSUBISHI |
| AB150017 | MITSUBISHI |
| ALT0466 | 3EFFE |
| ALTL573 | 3EFFE |
| ALTW213 | 3EFFE |
| PRAW213 | 3EFFE |
| CGB-13027 | AINDE |
| 002M921 | ASHIKA |
| AEA5147 | AUTOELECTRO |
| CAL35114AS | CASCO |
| 9179 | CEVAM |
| 14905 | DIXIE |
| 56372 | EAI |
| 28-1511 | ELSTOCK |
| JA173IR | HC PARTS |
| J5113021 | HERTH+BUSS |
| 40173RI | KUHNER |
| 40599RI | KUHNER |
| 445222 | LOGISTIK |
| LRA00547 | LUCAS |
| LRA0547 | LUCAS |
| 145.507.060.130 | PSH |
| 145.507.060.215 | PSH |
| 145.507.060.265 | PSH |
| 20137411BN | REAL |
| 2035114 | SANDO |
| STX101176 | STARDAX |
| STX101236 | STARDAX |
| STX102087 | STARDAX |
| 14905N | WAI / TRANSPO |
| 90-27-3038 | WILSON |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| MAZDA | 323 | 1.3 (1296ccm) Petrol | E360 | MK V | BF1 | 1987 - 1987 | |
| MAZDA | 323 | 1.3 (1324ccm) Petrol | B315/B335 | MK V | BF1 | 1987 - 1989 | |
| MAZDA | 323 | 1.3 (1324ccm) Petrol | E357 | MK V | BF1 | 1987 - 1989 | |
| MAZDA | 323 | 1.5 (1490ccm) Petrol | E5E3 | MK V | BF1 | 1987 - 1989 | |
| MAZDA | 323 | 1.5 (1490ccm) Petrol | E5E6/E5E7 | MK V | BF1 | 1987 - 1989 | |
| MAZDA | 323 | 1.5 (1490ccm) Petrol | E5E2 | MK V | BF1 | 1987 - 1989 | |
| MAZDA | 323 | 1.5 (1498ccm) Petrol | B505/B506/B535/B536 | MK V | BF1 | 1985 - 1989 | |
| MAZDA | 323 | 1.5 (1498ccm) Petrol | B505/B506/B535/B536 | MK V | BF1 | 1987 - 1989 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B616 | MK V | BF1 | 1985 - 1987 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B616/B698 | MK V | BF1 | 1985 - 1993 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B682/B6J5/B6J6 | MK V | BF1 | 1985 - 1989 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B6D3 | MK V | BF1 | 1985 - 1989 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B681 | MK V | BF1 | 1985 - 1989 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B682/B6J5/B6J6 | MK V | BF1 | 1986 - 1989 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B6T | MK V | BF | 1987 - 1989 | |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B6F2 | MK V | AWD | BF1 | 1987 - 1989 |
| MAZDA | 323 | 1.6 (1597ccm) Petrol | B6D3 | MK V | AWD | BF1 | 1987 - 1989 |
| MAZDA | 323 Estate/Wagon | 1.5 (1490ccm) Petrol | E5H5 | MK V | BW12 | 1986 - 1987 | |
| MAZDA | 323 Estate/Wagon | 1.5 (1498ccm) Petrol | B505/B506/B535/B536/D509/E5J9 | MK V | BW12 | 1987 - 1989 | |
| MAZDA | 323 Estate/Wagon | 1.6 (1597ccm) Petrol | B65M/B682/B689 | MK V | BW12 | 1986 - 1993 |
Description
A0547 Replacement Alternator
Start your A0547 alternator comparison with the linked Lucas reference LRA00547 and the specifications shown on this page. The listed electrical rating is 12V 60A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Mazda 323 1.3 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 60A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- Lucas LRA00547 reference: a starting point for identifying the replacement.
Compatible Vehicles and Applications
- Mazda 323 1.3 Petrol – selected applications 1987–1987 (engine code E360).
- Mazda 323 Estate/Wagon 1.5 Petrol – selected applications 1986–1987 (engine code E5H5).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0547. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120484035, 986036331, 986037701, 9120690380, LRA00547, LRA0547, A002T05572, A002T05772, A002T05772X, A002T07572, A005T00972, A005T01271, A2T05572, A2T05772, A2T05772X, A2T07572, A5T00972, A5T01271, AB150017, 219053, DRA3027
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0547 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0547 fit my Mazda 323?
Mazda 323 1.3 Petrol (1987–1987) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0547 replace Lucas LRA00547?
Lucas LRA00547 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0547?
The listed details include 12V, 60A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0547 new or remanufactured?
Check the current product condition selection for A0547. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0547?
Compare 12V compatibility, 60A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
