A0568 12V 40A Alternator Fits Toyota Corolla
Price range: £130.00 through £208.00
Sahibs A0568 is a replacement alternator with a listed 12V 40A rating. Listed applications include selected Toyota Corolla, Toyota Corolla Estate/Wagon models. Identification references include Lucas LRA00568, Valeo 436532, Denso 21000669. Its listed 12V 40A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0568 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 40 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 75 mm |
| Mounting holes | 3 qty |
| Position | -25° |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0568 | Dyno Electrics |
| 21000669 | Denso |
| 210006691 | Denso |
| 210006692 | Denso |
| 21000788 | Denso |
| 210007880 | Denso |
| 21000795 | Denso |
| 21000798 | Denso |
| 210007980 | Denso |
| 21000822 | Denso |
| 210008220 | Denso |
| 210008221 | Denso |
| 21000926 | Denso |
| 210009260 | Denso |
| 986033421 | Bosch Exchange |
| 986035591 | Bosch Exchange |
| 110251 | HC-Cargo |
| 14342R | WAI |
| 14576R | WAI |
| 195007050 | PSH |
| 2702013040 | Toyota |
| 2702013041 | Toyota |
| 2702013140 | Toyota |
| 2.70E+12 | Daihatsu |
| 2702024100 | Toyota |
| 2702024101 | Toyota |
| 2702024102 | Toyota |
| 2702025105 | Toyota |
| 436532 | Valeo |
| 436608 | Valeo |
| 8LHA2024R | Prestolite |
| 90059123 | Wilson |
| ATA392 | ATK |
| ATA396 | ATK |
| DRA3421 | Delco Remy |
| DRA5591 | Delco Remy |
| JA134 | HC-Parts |
| LRA00568 | Lucas |
| LRA568 | Lucas |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A0167 | Screw terminal | Multi plug E-F-N | No |
| A0679 | 40A Screw terminal | 50A Multi plug E-F-N | No |
| A0342 | 40A Screw terminal | 45/50A Multi plug E-F-N | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| TOYOTA | Corolla | 1.3 (1290ccm) Petrol | 4K | KE70 | 1979 - 1981 | ||
| TOYOTA | Corolla | 1.3 (1290ccm) Petrol | 4K | KE70 | 1979 - 1983 | ||
| TOYOTA | Corolla | 1.3 (1290ccm) Petrol | 4K | KE70 | 1982 - 1983 | ||
| TOYOTA | Corolla Estate/Wagon | 1.3 (1290ccm) Petrol | 4KC | KE70 | 1979 - 1982 |
Description
A0568 Replacement Alternator
The A0568 alternator is a replacement unit identified by Lucas reference LRA00568. The listed electrical rating is 12V 40A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Toyota Corolla 1.3 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 40A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
Compatible Vehicles and Applications
- Toyota Corolla 1.3 Petrol – selected applications 1979–1981 (engine code 4K).
- Toyota Corolla Estate/Wagon 1.3 Petrol – selected applications 1979–1982 (engine code 4KC).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0568. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986033421, 986035591, 436532, 436608, 21000669, 210006691, 210006692, 21000788, 210007880, 21000795, 21000798, 210007980, 21000822, 210008220, 210008221, 21000926, 210009260, LRA00568, LRA568, DRA3421, DRA5591, 8LHA2024R
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0568 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0568 fit my Toyota Corolla?
Toyota Corolla 1.3 Petrol (1979–1981) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0568 replace Lucas LRA00568?
Lucas LRA00568 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0568?
The listed details include 12V, 40A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0568 new or remanufactured?
Check the current product condition selection for A0568. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0568?
Compare 12V compatibility, 40A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
