A0653 12V 45A Alternator Fits Land Rover Defender 110
Price range: £71.51 through £91.19
Sahibs A0653 is a replacement alternator with a listed 12V 45A rating. Listed applications include selected Land Rover Defender 110, Land Rover Defender 130, Land Rover Defender 90 models. Identification references include Lucas LRA00653, Bosch 120339504, Valeo 2518098. Its listed 12V 45A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0653 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 45 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 71 mm |
| Mounting holes | 3 qty |
| Position | -60° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0653 | Dyno Electrics |
| 401670341 | Euro Car Part |
| 120339504 | Bosch |
| 120339506 | Bosch |
| 120339509 | Bosch |
| 120400902 | Bosch |
| 120400903 | Bosch |
| 120400906 | Bosch |
| 120489175 | Bosch |
| 120489268 | Bosch |
| 120489269 | Bosch |
| 120489589 | Bosch |
| 120489590 | Bosch |
| 120489705 | Bosch |
| 120489706 | Bosch |
| 120489805 | Bosch |
| 120489806 | Bosch |
| 120489842 | Bosch |
| 120489888 | Bosch |
| 120489889 | Bosch |
| 120489895 | Bosch |
| 120489896 | Bosch |
| 63324199 | Magneti Marelli |
| 724199000 | Magneti Marelli |
| 986030370 | Bosch Exchange |
| 986030798 | Bosch Exchange |
| 986031380 | Bosch Exchange |
| 986031381 | Bosch Exchange |
| 986044641 | Bosch Exchange |
| 0986CR0115 | Bosch Exchange |
| 0986CR0116 | Bosch Exchange |
| 0986UR0116 | Bosch Exchange |
| 110995 | HC-Cargo |
| 111185 | HC-Cargo |
| 12041N | WAI |
| 12041R | WAI |
| 12152N | WAI |
| 13201103 | AES |
| 14037N | WAI |
| 14050N | WAI |
| 18ACR | Lucas |
| 20130142 | Prestolite |
| 23617 | Lucas |
| 23622 | Lucas |
| 23684 | Lucas |
| 23709 | Lucas |
| 23721 | Lucas |
| 23737 | Lucas |
| 23759 | Lucas |
| 23765 | Lucas |
| 23766 | Lucas |
| 23779 | Lucas |
| 23808 | Lucas |
| 23811 | Lucas |
| 23891 | Lucas |
| 23925 | Lucas |
| 23929 | Lucas |
| 23983 | Lucas |
| 23985 | Lucas |
| 24065 | Lucas |
| 24096 | Lucas |
| 24112 | Lucas |
| 24131 | Lucas |
| 24134 | Lucas |
| 24181 | Lucas |
| 2518098 | Valeo |
| 26021235 | Lucas |
| 2871A139 | Perkins |
| 3129850R91 | Massey Ferguson |
| 3698017M91 | Massey Ferguson |
| 432836 | Valeo |
| 432863 | Valeo |
| 436142 | Valeo |
| 436145 | Valeo |
| 436167 | Valeo |
| 436175 | Valeo |
| 436186 | Valeo |
| 5003898 | Ford |
| 5003986 | Ford |
| 5007075 | Ford |
| 54021663 | Lucas |
| 54021986 | Lucas |
| 54022089010 | Case |
| 54022195 | Magneti Marelli |
| 595001045 | PSH |
| 6056325 | Ford |
| 61920107 | Lucas |
| 70TF10300AB | Ford |
| 70TFAB | Ford |
| 71TF10300BA | Ford |
| 71TF10300BB | Ford |
| 71TFBA | Ford |
| 71TFBB | Ford |
| 78FB10300AA | Ford |
| 78FB10300AB | Ford |
| 78FB10300BC | Ford |
| 78FB10346AB | Ford |
| 78FBAA | Ford |
| 78FBAB | Ford |
| 78FBBC | Ford |
| 7982874 | Delco Remy |
| 7982880 | Delco Remy |
| 7982940 | Delco Remy |
| 7982980 | Delco Remy |
| 81AB10300AAA | Ford |
| 81AB10300CA | Ford |
| 81GB10300AA | Ford |
| 81GBAA | Ford |
| 861000 | Prestolite |
| 90156083 | Wilson |
| 9120331863 | Bosch |
| 9124476005 | Bosch |
| 92293C1 | Case |
| 926020 | Valeo |
| 943356118 | Magneti Marelli |
| 9.44E+11 | Magneti Marelli |
| 9AR2602F | Motorola |
| 9AR2627G | Motorola |
| 9AR2683 | Motorola |
| 9AR2683G | Prestolite |
| 9AR2697G | Motorola |
| 9AR2699G | Motorola |
| 9AR2700G | Motorola |
| 9AR2707G | Motorola |
| 9AR2780K | Motorola |
| 9AR2918G | Motorola |
| 9AR2929G | Motorola |
| A13N10 | Valeo |
| AAK4135 | Mahle |
| ADU5440 | Land Rover |
| ADU5444 | Land Rover |
| AL300X | Bosch (USA) |
| ALT16003 | Wood Auto |
| ALT7006FP | Wood Auto |
| CA18 | HC-Parts |
| CA18H | HC-Parts |
| CA61IR | HC-Parts |
| DRA3015 | Delco Remy |
| DRA3293 | Delco Remy |
| F032111185 | HC-Cargo |
| GEU2206 | Land Rover |
| HCA18H | HC-Parts |
| HCA61IR | HC-Parts |
| IA0301 | Mahle |
| LEA0004 | Lucas |
| LEA0010 | Lucas |
| LEA0028 | Lucas |
| LEA0043 | Lucas |
| LEA0098 | Lucas |
| LEA0135 | Lucas |
| LEA0578 | Lucas |
| LEA0757 | Lucas |
| LRA00103 | Lucas |
| LRA00129 | Lucas |
| LRA00226 | Lucas |
| LRA00228 | Lucas |
| LRA00230 | Lucas |
| LRA00359 | Lucas |
| LRA00653 | Lucas |
| LRA01032 | Lucas |
| LRA01035 | Lucas |
| LRA103 | Lucas |
| LRA1032 | Lucas |
| LRA1035 | Lucas |
| LRA129 | Lucas |
| LRA226 | Lucas |
| LRA228 | Lucas |
| LRA230 | Lucas |
| LRA359 | Lucas |
| LRA653 | Lucas |
| MAHMG426 | Wood Auto |
| MG197 | Mahle |
| MG426 | Mahle |
| NA036 | Valeo |
| NA065 | Valeo |
| NAB100 | Lucas |
| OAN10448 | Optimum |
| OAN10456 | Optimum |
| OAN10515 | Optimum |
| OAN10583 | Optimum |
| OAN10599 | Optimum |
| PRE20130142 | Wood Auto |
| RTC5682 | Land Rover |
| RTC5682E | Land Rover |
| RTC5682N | Land Rover |
| WOOALT16003 | Wood Auto |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| LAND ROVER | Defender 110 | 2.5 (2495ccm) Diesel | 11L/16L/23L | MK II | Wagon Cabine | LDH | 1990 - 1998 |
| LAND ROVER | Defender 130 | 2.5 (2495ccm) Diesel | 16L | MK II | Crewcab | LDK | 1995 - 1998 |
| LAND ROVER | Defender 90 | 2.5 (2495ccm) Diesel | 11L/16L/23L | MK II | LDV | 1990 - 1998 |
Description
A0653 Replacement Alternator
The A0653 alternator is a replacement unit identified by Lucas reference LRA00653. The listed electrical rating is 12V 45A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Land Rover Defender 110 2.5 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 45A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Land Rover Defender 110 2.5 Diesel – selected applications 1990–1998 (engine code 11L/16L/23L).
- Land Rover Defender 130 2.5 Diesel – selected applications 1995–1998 (engine code 16L).
- Land Rover Defender 90 2.5 Diesel – selected applications 1990–1998 (engine code 11L/16L/23L).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0653. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120339504, 120339506, 120339509, 120400902, 120400903, 120400906, 120489175, 120489268, 120489269, 120489589, 120489590, 120489705, 120489706, 120489805, 120489806, 120489842, 120489888, 120489889, 120489895, 120489896, 986030370, 986030798, 986031380, 986031381, 986044641, 0986CR0115, 0986CR0116, 0986UR0116, 9120331863, 9124476005, 2518098, 432836, 432863, 436142, 436145, 436167, 436175, 436186, 926020, A13N10, NA036, NA065, LRA00653, 18ACR, 23617, 23622, 23684, 23709, 23721, 23737, 23759, 23765, 23766, 23779, 23808, 23811, 23891, 23925, 23929, 23983, 23985, 24065, 24096, 24112, 24131, 24134, 24181, 26021235, 54021663, 54021986, 61920107, LEA0004, LEA0010, LEA0028, LEA0043, LEA0098, LEA0135, LEA0578, LEA0757, LRA00103, LRA00129, LRA00226, LRA00228, LRA00230, LRA00359, LRA01032, LRA01035, LRA103, LRA1032, LRA1035, LRA129, LRA226, LRA228, LRA230, LRA359, LRA653, NAB100, 7982874, 7982880, 7982940, 7982980, DRA3015, DRA3293, 20130142, 861000, 9AR2683G, AAK4135, IA0301, MG197, MG426, 5003898, 5003986, 5007075, 6056325, 70TF10300AB, 70TFAB, 71TF10300BA, 71TF10300BB, 71TFBA, 71TFBB, 78FB10300AA, 78FB10300AB, 78FB10300BC, 78FB10346AB, 78FBAA, 78FBAB, 78FBBC, 81AB10300AAA, 81AB10300CA, 81GB10300AA, 81GBAA, 2871A139, 3129850R91, 3698017M91
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0653 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0653 fit my Land Rover Defender 110?
Land Rover Defender 110 2.5 Diesel (1990–1998) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0653 replace Lucas LRA00653?
Lucas LRA00653 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0653?
The listed details include 12V, 45A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0653 new or remanufactured?
Check the current product condition selection for A0653. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0653?
Compare 12V compatibility, 45A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
