A0832 12V 45A Alternator Fits Fiat 127, Fiat Panda, Fiat Uno
Price range: £122.39 through £138.00
The A0832 12V 45A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Fiat 127, Fiat Panda, Fiat Uno, Lancia A112 models. Identification references include Lucas LRA00832, Bosch 986032340, Valeo 436113. Its listed 12V 45A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0832 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 45 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 42.5 mm |
| Mounting holes | 2 qty |
| Position | 33° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0832 | Dyno Electrics |
| 986032340 | BOSCH |
| 986032341 | BOSCH |
| 9120144228 | BOSCH |
| 9120144229 | BOSCH |
| 9120144240 | BOSCH |
| 9120144241 | BOSCH |
| 111035 | CARGO |
| 111078 | CARGO |
| F032111035 | CARGO |
| F032111078 | CARGO |
| DRA2341 | DELCO |
| DRA2341N | DELCO |
| DAN608 | DENSO |
| DAN645 | DENSO |
| 4242498 | FIAT |
| 4274759 | FIAT |
| 4274762 | FIAT |
| 4274812 | FIAT |
| 4274813 | FIAT |
| 4383593 | FIAT |
| 4384014 | FIAT |
| 4395131 | FIAT |
| 4417595 | FIAT |
| 4434084 | FIAT |
| 4450594 | FIAT |
| 4451758 | FIAT |
| 4451759 | FIAT |
| 4456152 | FIAT |
| 4458618 | FIAT |
| 4474812 | FIAT |
| 4551758 | FIAT |
| 46207934 | FIAT |
| 46231655 | FIAT |
| 46231684 | FIAT |
| 46231687 | FIAT |
| 5947366 | FIAT |
| 5947376 | FIAT |
| 5952011 | FIAT |
| 5958060 | FIAT |
| 5958394 | FIAT |
| 5958395 | FIAT |
| 5967595 | FIAT |
| 5967596 | FIAT |
| 5973034 | FIAT |
| 5973035 | FIAT |
| 7533853 | FIAT |
| 7541823 | FIAT |
| 7546342 | FIAT |
| 7546343 | FIAT |
| 7565558 | FIAT |
| 7580207 | FIAT |
| 77110410 | FIAT |
| 77110411 | FIAT |
| 77110910 | FIAT |
| 77161410 | FIAT |
| 77175410 | FIAT |
| 77176410 | FIAT |
| 77320410 | FIAT |
| 77367411 | FIAT |
| 7765558 | FIAT |
| 992235 | FIAT |
| 8EL725709-001 | HELLA |
| LT13535A | HITACHI |
| 11.201.093 | ISKRA / LETRIKA |
| AAK1128 | ISKRA / LETRIKA |
| 63303001 | MAGNETI MARELLI |
| 63303001010 | MAGNETI MARELLI |
| 63303502 | MAGNETI MARELLI |
| 63303701 | MAGNETI MARELLI |
| 63303703 | MAGNETI MARELLI |
| 63306701 | MAGNETI MARELLI |
| 63307106 | MAGNETI MARELLI |
| 63307108 | MAGNETI MARELLI |
| 63308701 | MAGNETI MARELLI |
| 63320002 | MAGNETI MARELLI |
| 63321001 | MAGNETI MARELLI |
| A002T32171 | MITSUBISHI |
| A2T32171 | MITSUBISHI |
| 20100190 | PRESTOLITE |
| 2702061013 | TOYOTA |
| 2702061100 | TOYOTA |
| 2702061130 | TOYOTA |
| 436113 | VALEO |
| VA203 | VALEO |
| 3934961 | VW |
| 076903023G | VW |
| SE141903020A | VW |
| XO39349610 | VW |
| ALTL735 | 3EFFE |
| ANM34561X | ANDEL |
| 5962646 | AUTOBIANCHI |
| AEA8132 | AUTOELECTRO |
| CAL21118GS | CASCO |
| CAL30112AS | CASCO |
| CAL30112GS | CASCO |
| 4141 | CEVAM |
| 516032 | DUCELLIER |
| 55607 | EAI |
| 13460 | EFEL |
| ALT4150 | ELECTROLOG |
| 28-0877 | ELSTOCK |
| 210225 | ERA |
| ALP12N-20 | FEMSA |
| ALP12N-24 | FEMSA |
| 9032341 | FRIESEN |
| CA252IR | HC PARTS |
| CA307IR | HC PARTS |
| 32680330 | HERTH+BUSS |
| 30307RI | KUHNER |
| 554098RI | KUHNER |
| 11.0307 | LAUBER |
| 440454 | LOGISTIK |
| 24041 | LUCAS |
| LRA00832 | LUCAS |
| LRA832 | LUCAS |
| 505.012.045 | PSH |
| 505.012.045.050 | PSH |
| 505.012.045.461 | PSH |
| 505.012.045.462 | PSH |
| 20104211BN | REAL |
| 20104211OE | REAL |
| 20119811OE | REAL |
| 2021118 | SANDO |
| 2030112 | SANDO |
| ALT1090 | SIOM |
| ALT321120 | SIOM |
| SA409 | SOVEREIGN |
| STX100296 | STARDAX |
| STX100630 | STARDAX |
| STX100859 | STARDAX |
| STX100904 | STARDAX |
| STX100977 | STARDAX |
| STX101379 | STARDAX |
| STX101379R | STARDAX |
| 20264N | WAI / TRANSPO |
| 21188N | WAI / TRANSPO |
| ALT12032 | WOODAUTO |
| 46621396 | ZASTAVA |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0188 | 45A Pulley 1GR/53 | 55A Pulley 1GR/66 | No |
| A0271 | 45A M6 B+ Pulley 1GR/53 | 33A Plug B+ Pulley 1GR/73 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| FIAT | 127 | 0.9 (903ccm) Petrol | 100GL000/141A300 | 127A | 1982 - 1983 | ||
| FIAT | Panda | 0.9 (903ccm) Petrol | 141A300/146A048 | 141A/141AL | 1982 - 1985 | ||
| FIAT | Uno | 0.9 (903ccm) Petrol | 146A000/146A048 | 146A/146E | 1983 - 1992 | ||
| FIAT | Uno | 0.9 (903ccm) Petrol | 146A048 | Cargo | 146A/146E | 1987 - 1996 | |
| LANCIA | A112 | 1.0 (965ccm) Petrol | A112B1000 | A112 | 1984 - 1984 | ||
| SEAT | Fura | 0.9 (903ccm) Petrol | 100GL7000 | 25A | 1984 - 1986 | ||
| SEAT | Ibiza | 0.9 (903ccm) Petrol | 09NCA/146A000 | I | 21A | 1986 - 1993 | |
| SEAT | Ibiza | 0.9 (903ccm) Petrol | 903A | I | 21A | 1986 - 1993 | |
| SEAT | Marbella | 0.8 (843ccm) Petrol | 850 | 28A | 1986 - 1991 | ||
| SEAT | Marbella | 0.8 (843ccm) Petrol | 850 | Commercial | 28A | 1987 - 1993 | |
| SEAT | Marbella | 0.9 (903ccm) Petrol | 903/903E | 28A | 1987 - 1996 | ||
| SEAT | Marbella | 0.9 (903ccm) Petrol | 09NCA/09NCB | Commercial | 28A | 1987 - 1993 | |
| SEAT | Panda | 0.9 (903ccm) Petrol | 903A | 141A | 1980 - 1986 | ||
| SEAT | Terra | 0.9 (903ccm) Petrol | 09NCA/09NCB | 24A | 1987 - 1996 | ||
| SEAT | Terra | 0.9 (903ccm) Petrol | 09NCA/09NCB | 24 | 1987 - 1996 |
Description
A0832 Replacement Alternator
Start your A0832 alternator comparison with the linked Lucas reference LRA00832 and the specifications shown on this page. The listed electrical rating is 12V 45A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Fiat 127 0.9 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 45A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Fiat 127 0.9 Petrol – selected applications 1982–1983 (engine code 100GL000/141A300).
- Fiat Panda 0.9 Petrol – selected applications 1982–1985 (engine code 141A300/146A048).
- Fiat Uno 0.9 Petrol – selected applications 1983–1992 (engine code 146A000/146A048).
- Lancia A112 1.0 Petrol – selected applications 1984–1984 (engine code A112B1000).
- Seat Fura 0.9 Petrol – selected applications 1984–1986 (engine code 100GL7000).
- Seat Ibiza 0.9 Petrol – selected applications 1986–1993 (engine code 09NCA/146A000).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0832. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986032340, 986032341, 9120144228, 9120144229, 9120144240, 9120144241, 436113, VA203, DAN608, DAN645, LRA00832, 24041, LRA832, A002T32171, A2T32171, LT13535A, DRA2341, DRA2341N, 20100190, 11.201.093, AAK1128
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0832 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0832 fit my Fiat 127?
Fiat 127 0.9 Petrol (1982–1983) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0832 replace Lucas LRA00832?
Lucas LRA00832 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0832?
The listed details include 12V, 45A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0832 new or remanufactured?
Check the current product condition selection for A0832. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0832?
Compare 12V compatibility, 45A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
