A0926 24V 35A Alternator Fits Hanomag 22C, Hanomag 33C, Hanomag 400D
Price range: £99.86 through £125.70
Compare the A0926 24V 35A alternator from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Hanomag 22C, Hanomag 33C, Hanomag 400D, Pegaso 1331.36 models. Identification references include Lucas LRA00926, Bosch 120489192, Delco Remy DRA1250. Its listed 24V 35A rating provides an electrical matching point for your existing unit. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0926 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 35 A |
| Volt | 24 V |
| No. of Grooves | 2 qty |
| Pulley Diameter | 44 mm |
| Mounting holes | 2 qty |
| Position | 180° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.5 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0926 | Dyno Electrics |
| UD30191A | AS-PL |
| 120489192 | BOSCH |
| F00E100024 | BOSCH |
| DRA1250 | DELCO |
| DRA1251 | DELCO |
| 8EL725584-001 | HELLA |
| 7464496 | IVECO |
| 858772Z | PRESTOLITE |
| 326353 | SCANIA |
| 571500 | SCANIA |
| 571501 | SCANIA |
| 571503 | SCANIA |
| L31250 | ATL AUTOTECHNIK |
| ABO636A | AUTOTEAM |
| G102626 | BTS TURBO |
| CAL10636AS | CASCO |
| CAL10636ES | CASCO |
| 2015 | CEVAM |
| 232101354 | DRI |
| 48-0590 | ELSTOCK |
| 118547 | FARCOM |
| 9931250 | FRIESEN |
| 30130RI | KUHNER |
| LRA00926 | LUCAS |
| LRA926 | LUCAS |
| 916.006.035.010 | PSH |
| 916.006.035.216 | PSH |
| 916.006.035.340 | PSH |
| 916.006.035.508 | PSH |
| 220-10154 | ROBERT'S |
| AL03875 | TMI |
| 12167N | WAI / TRANSPO |
| 90-15-6417 | WILSON |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A2774 | 35A | 55A | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| HANOMAG | 22C | 0ccm Diesel | Perkins 4.248 | 1980 - | |||
| HANOMAG | 33C | 0ccm Diesel | Perkins A6.354 | 1980 - | |||
| HANOMAG | 400D | 0ccm Diesel | Perkins A6.354 | 1980 - | |||
| PEGASO | 1331.36 | 1194ccm Diesel | 96T1CX | 1987 - | |||
| PEGASO | 1331.38 | 1194ccm Diesel | 96T1CX | 1987 - | |||
| PEGASO | 2331.26 | 1194ccm Diesel | 96T1CV | 1987 - | |||
| PEGASO | 2331.38 | 1194ccm Diesel | 96T1CX | 1987 - | |||
| PEGASO | 2431.36 | 1194ccm Diesel | 96T1CV | 1987 - | |||
| PEGASO | 2431K | 1194ccm Diesel | 9156.17 | 1982 - 1987 | |||
| RENAULT TRUCK | G210 | 0ccm Diesel | MIDS 06.20.30N | 1983 - 1986 | |||
| RENAULT TRUCK | S130 | 0ccm Diesel | 797 | 1983 - 1990 | |||
| RENAULT TRUCK | S150 | 0ccm Diesel | 798-10 | 1983 - 1986 | |||
| RENAULT TRUCK | S150 Ti Midliner | 0ccm Diesel | MIDS 06.02.12B | 1987 - 1990 | |||
| RVI | JN60/75/80/90 | 0ccm Diesel | 1979 - 1984 | ||||
| RVI | JN95 | 0ccm Diesel | 1980 - 1984 | ||||
| RVI | JP13A/B | 0ccm Diesel | 1979 - 1984 | ||||
| RVI | JP13C | 0ccm Diesel | 1979 - 1984 | ||||
| RVI | JP14/B | 0ccm Diesel | 1979 - 1984 | ||||
| RVI | S110/S130-06/08/09 | 5496ccm Diesel | 1983 - 1990 | ||||
| RVI | S150 | 0ccm Diesel | 1983 - 1986 | ||||
| RVI | S150ti/S170-11/13/14 | 0ccm Diesel | 1986 - 1990 | ||||
| SCANIA | 111 | 0ccm Diesel | D/DS11.. | 1978 - 1980 | |||
| SCANIA | 112 | 0ccm Diesel | D/DN/DS/DSC11.. | 1978 - 1988 | |||
| SCANIA | 141 | 0ccm Diesel | DS14 | 1978 - 1980 | |||
| SCANIA | 142 | 0ccm Diesel | DS/DSC14.. | 1980 - 1988 | |||
| SCANIA | 145 | 0ccm Diesel | D/DS14 | 1978 - 1984 | |||
| SCANIA | 146 | 0ccm Diesel | DS14 | 1978 - 1980 | |||
| SCANIA | 81 | 0ccm Diesel | D/DS8.. | 1978 - 1980 | |||
| SCANIA | 82 | 0ccm Diesel | DN/DS/DSI8.. | 1980 - 1988 | |||
| SCANIA | 86 | 0ccm Diesel | D/DS8.. | 1978 - 1982 | |||
| SCANIA | 92 | 0ccm Diesel | DN/DS/DSC9.. | 1988 - 1989 | |||
| SCANIA ENGINES | DSI14 | 14200ccm Diesel | 1980 - 1989 |
Description
A0926 Replacement Alternator
Start your A0926 alternator comparison with the linked Lucas reference LRA00926 and the specifications shown on this page. The listed electrical rating is 24V 35A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Hanomag 22C variants.
Key Features and Benefits
- 24V electrical system: match the vehicle voltage before selecting a unit.
- 35A output: compare the listed rating with the original alternator.
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Hanomag 22C – selected applications 1980 – (engine code Perkins 4.248).
- Hanomag 33C – selected applications 1980 – (engine code Perkins A6.354).
- Hanomag 400D – selected applications 1980 – (engine code Perkins A6.354).
- Pegaso 1331.36 1194ccm Diesel – selected applications 1987 – (engine code 96T1CX).
- Pegaso 1331.38 1194ccm Diesel – selected applications 1987 – (engine code 96T1CX).
- Pegaso 2331.26 1194ccm Diesel – selected applications 1987 – (engine code 96T1CV).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0926. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120489192, F00E100024, LRA00926, LRA926, DRA1250, DRA1251, 858772Z
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0926 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0926 fit my Hanomag 22C?
Hanomag 22C (1980 -) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0926 replace Lucas LRA00926?
Lucas LRA00926 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0926?
The listed details include 24V, 35A output, 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A0926 new or remanufactured?
Check the current product condition selection for A0926. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0926?
Compare 24V compatibility, 35A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
