A0938 24V 55A Alternator Fits Iveco 110-13, Iveco 110-16, Iveco 65-9
Price range: £122.00 through £195.20
Identify a replacement alternator using Sahibs A0938, listed at 24V 55A. Listed applications include selected Iveco 110-13, Iveco 110-16, Iveco 130-13, Iveco 130-16 models. Identification references include Lucas LRA00938, Bosch 120469048, Valeo 2541423. Its listed 24V 55A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A0938 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 55 A |
| Volt | 24 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 80 mm |
| Mounting holes | 3 qty |
| Position | -20° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA0938 | Dyno Electrics |
| 120469048 | Bosch |
| 120469549 | Bosch |
| 120469634 | Bosch |
| 120469679 | Bosch |
| 120469849 | Bosch |
| 120469890 | Bosch |
| 4757192 | KHD |
| 986034420 | Bosch Exchange |
| 111419 | HC-Cargo |
| 11201555 | Mahle |
| 12135N | WAI |
| 2541423 | Valeo |
| 38520137A | Chrysler |
| 436417 | Valeo |
| 4757192 | Fiat Group |
| 4757193 | Fiat Group |
| 47571930 | Fiat Group |
| 4757194 | Fiat Group |
| 4844266 | Fiat Group |
| 506003055 | PSH |
| 72735398 | Mahle |
| 860576 | Prestolite |
| 90156225 | Wilson |
| 99465867 | Iveco |
| AAK4507 | Mahle |
| ALT0107 | Wood Auto |
| ALT10390 | Wood Auto |
| ALT20009 | Wood Auto |
| ALT20642 | Wood Auto |
| ALT7575 | Wood Auto |
| CA326IR | HC-Parts |
| DRA4420 | Delco Remy |
| F032111419 | HC-Cargo |
| F042301020 | Bosch |
| F042A01020 | Bosch |
| HCA326IR | HC-Parts |
| IA0555 | Mahle |
| LEA0620 | Lucas |
| LRA00938 | Lucas |
| LRA938 | Lucas |
| MAHMG399 | Wood Auto |
| MAR904 | Magneti Marelli |
| MG399 | Mahle |
| PRE860576 | Wood Auto |
| REM19025106 | Wood Auto |
| RNL3913 | RNL |
| RNL3913OER | RNL |
| RNL3913T | RNL |
| UNIALT0107 | Wood Auto |
| WOOALT10390 | Wood Auto |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0310 | Without W terminal | With W terminal | No |
| A2489 | Without W terminal Without pulley | With W terminal Pulley 1GR/83 | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| IVECO | 110-13 | 6128ccm Diesel | KHD-BF6L913T | 1986 - 1991 | |||
| IVECO | 110-16 | 6128ccm Diesel | KHD-BF6L913 | 1986 - 1991 | |||
| IVECO | 130-13 | 6128ccm Diesel | KHD-BF6L913T | 1986 - 1989 | |||
| IVECO | 130-16 | 6128ccm Diesel | KHD-BF6L913 | 1986 - 1991 | |||
| IVECO | 180-26 | 0ccm Diesel | 8210.02.371... | 1982 - 1986 | |||
| IVECO | 190-30 | 0ccm Diesel | 8210.22.175... | 1980 - 1990 | |||
| IVECO | 220-36 | 0ccm Diesel | 8210.42.115 | 1987 - 1990 | |||
| IVECO | 260-36 | 0ccm Diesel | 8210.42.115 | 1988 - 1990 | |||
| IVECO | 260-48 | 0ccm Diesel | 8280.42.001 | 1989 - 1999 | |||
| IVECO | 320-30 | 0ccm Diesel | 8210.22.235 | 1990 - 1996 | |||
| IVECO | 330-30 | 0ccm Diesel | 8210.22.235... | 1990 - | |||
| IVECO | 330-36 | 0ccm Diesel | 8210.42R.269.. | 1989 - 1998 | |||
| IVECO | 370-S24 | 0ccm Diesel | 8460.21.7… | 1987 - 1998 | |||
| IVECO | 65-9 | 0ccm Diesel | 8040.05.230 | 1990 - 1992 | |||
| IVECO | 79-14 | 0ccm Diesel | 8060.05.280 | 1990 - 1992 | |||
| IVECO | 80-13A | 6128ccm Diesel | KHD-BF6L913T | 1986 - 1991 | |||
| IVECO | 80-16A | 6128ccm Diesel | KHD-BF6L913 | 1986 - 1991 | |||
| IVECO | 90-13A | 6128ccm Diesel | KHD-BF6L913T | 1986 - 1991 | |||
| IVECO | TurboStar 190-33 | 13798ccm Diesel | 8210.22.105 | 1984 - 1987 | |||
| IVECO | TurboStar 190-36 | 13798ccm Diesel | 8210.42.. | 1987 - 1993 | |||
| IVECO | TurboStar 190-42 | 17173ccm Diesel | 8280.22.20.. | 1984 - 1986 | |||
| IVECO | TurboStar 190-48 | 17173ccm Diesel | 8280.42.... | 1989 - 1993 | |||
| IVECO | TurboStar 240-36 | 0ccm Diesel | 8210.42.115 | 1987 - 1990 | |||
| IVECO | TurboStar 240-48 | 0ccm Diesel | 8280.42.001 | 1989 - 1999 | |||
| IVECO | TurboStar 260-36 | 0ccm Diesel | 8210.42.115... | 1988 - 1990 | |||
| IVECO | TurboTech 190-24 | 9500ccm Diesel | 8460.21.202.. | 1988 - 1998 | |||
| IVECO | TurboTech 190-26 | 9500ccm Diesel | 8460.21.102.. | 1987 - 1994 | |||
| IVECO | TurboTech 190-30 | 13798ccm Diesel | 8210.22.175 | 1987 - 1999 | |||
| IVECO | TurboTech 190-32 | 9500ccm Diesel | 8460.41.102 | 1988 - 1998 | |||
| IVECO | TurboTech 220-32 | 9500ccm Diesel | 8460.41.102 | 1989 - 1999 | |||
| IVECO | TurboTech 240-26 | 9500ccm Diesel | 8460.21.102 | 1990 - 2000 | |||
| IVECO | TurboTech 240-32 | 9500ccm Diesel | 8460.41.102 | 1989 - 1998 | |||
| IVECO | TurboTech 240-36 | 13798ccm Diesel | 8210.42.115 | 1987 - 1990 | |||
| IVECO | TurboTech 260-32 | 9500ccm Diesel | 8460.41.124 | 1990 - 2000 | |||
| IVECO ENGINES | Aifo 5.9L | 5861ccm Diesel | 8061.05… | 1986 - | |||
| LAVERDA | 3400 | 0ccm Diesel | 8061.05.000.L | 1989 - | |||
| LAVERDA | 3500 | 0ccm Diesel | 8061.05.000.L | 1989 - |
Description
A0938 Replacement Alternator
Choose a replacement by comparing the A0938 alternator and its Lucas reference, LRA00938, with your existing unit. The listed electrical rating is 24V 55A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Iveco 110-13 6128ccm Diesel variants.
Key Features and Benefits
- 24V electrical system: match the vehicle voltage before selecting a unit.
- 55A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Iveco 110-13 6128ccm Diesel – selected applications 1986–1991 (engine code KHD-BF6L913T).
- Iveco 110-16 6128ccm Diesel – selected applications 1986–1991 (engine code KHD-BF6L913).
- Iveco 130-13 6128ccm Diesel – selected applications 1986–1989 (engine code KHD-BF6L913T).
- Iveco 130-16 6128ccm Diesel – selected applications 1986–1991 (engine code KHD-BF6L913).
- Iveco 180-26 – selected applications 1982–1986 (engine code 8210.02.371…).
- Iveco 190-30 – selected applications 1980–1990 (engine code 8210.22.175…).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A0938. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
120469048, 120469549, 120469634, 120469679, 120469849, 120469890, 986034420, F042301020, F042A01020, 2541423, 436417, LRA00938, LEA0620, LRA938, DRA4420, 860576, 11201555, 72735398, AAK4507, IA0555, MG399, 38520137A
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A0938 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A0938 fit my Iveco 110-13?
Iveco 110-13 6128ccm Diesel (1986–1991) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A0938 replace Lucas LRA00938?
Lucas LRA00938 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A0938?
The listed details include 24V, 55A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A0938 new or remanufactured?
Check the current product condition selection for A0938. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A0938?
Compare 24V compatibility, 55A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
