A1097 Alternator Replaces Lucas LRA01097
Price range: £108.67 through £143.30
The A1097 Alternator is a replacement charging unit from Sahibs Auto Electrics. Use the original unit reference and vehicle details to confirm the application. Identification references include Lucas LRA01097, Valeo 2625958, Denso 1002102120. Compare the existing electrical rating with the current product specifications before choosing a replacement. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1097 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| No. of Grooves | 2 qty |
| Pulley Diameter | 77 mm |
| Mounting holes | 3 qty |
| Position | 15° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 6.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1097 | Dyno Electrics |
| 986034552 | Bosch Exchange |
| 986042971 | Bosch Exchange |
| 1002102120 | Denso |
| 1002103250 | Denso |
| 1002103270 | Denso |
| 1002103350 | Denso |
| 1002103360 | Denso |
| 1002103400 | Denso |
| 1002103460 | Denso |
| 1002103580 | Denso |
| 1002103680 | Denso |
| 1002103760 | Denso |
| 1002103770 | Denso |
| 1002103810 | Denso |
| 1002103840 | Denso |
| 1002108160 | Denso |
| 1002115900 | Denso |
| 1002131710 | Denso |
| 111483 | HC-Cargo |
| 1210000660 | Denso |
| 1210008230 | Denso |
| 195807055 | PSH |
| 20130104 | Prestolite |
| 22096N | WAI |
| 2625958 | Valeo |
| 2702054250 | Toyota |
| 2702054351 | Toyota |
| 2702054352 | Toyota |
| 2702054353 | Toyota |
| 2702054354 | Toyota |
| 2702054382 | Toyota |
| 2702054383 | Toyota |
| 2702054400 | Toyota |
| 2702054700 | Toyota |
| 2702056220 | Toyota |
| 2703054190 | Toyota |
| 2703054241 | Toyota |
| 2703054242 | Toyota |
| 2703054243 | Toyota |
| 2703054244 | Toyota |
| 2703054250 | Toyota |
| 2703054253 | Toyota |
| 2703054260 | Toyota |
| 2703054261 | Toyota |
| 2703054262 | Toyota |
| 2703057081 | Toyota |
| 2706054101 | Toyota |
| 437705 | Valeo |
| 9.44E+11 | Magneti Marelli |
| 9612109820 | PSA |
| ADT31156 | Mando |
| ATA479 | ATK |
| ATA916 | ATK |
| DRA3518 | Delco Remy |
| DRA3518N | Delco Remy |
| F032111483 | HC-Cargo |
| HJA777IR | HC-Parts |
| J2702054352 | Volkswagen AG |
| JA777 | HC-Parts |
| JA777IR | HC-Parts |
| JA800 | HC-Parts |
| LEA1091 | Lucas |
| LRA01096 | Lucas |
| LRA01097 | Lucas |
| LRA1096 | Lucas |
| LRA1097 | Lucas |
| RNL777JA | RNL |
| RNL777JAT | RNL |
Description
A1097 Replacement Alternator
Choose a replacement by comparing the A1097 alternator and its Lucas reference, LRA01097, with your existing unit. An alternator maintains battery charge and supplies electrical power while the engine runs. Confirm the vehicle application with the team before ordering.
Key Features and Benefits
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
- Lucas LRA01097 reference: a starting point for identifying the replacement.
Compatible Vehicles and Applications
Quote A1097 and LRA01097 with your vehicle details so the team can check the application. Compare the original part number, engine and physical unit rather than relying on a general model description.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1097. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986034552, 986042971, 2625958, 437705, 1002102120, 1002103250, 1002103270, 1002103350, 1002103360, 1002103400, 1002103460, 1002103580, 1002103680, 1002103760, 1002103770, 1002103810, 1002103840, 1002108160, 1002115900, 1002131710, 1210000660, 1210008230, LRA01097, LEA1091, LRA01096, LRA1096, LRA1097, DRA3518, DRA3518N, 20130104
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1097 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
How can I confirm the vehicle application for A1097?
Quote A1097, Lucas LRA01097, your vehicle registration and the existing unit number for an application check.
Does A1097 replace Lucas LRA01097?
Lucas LRA01097 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1097?
The listed details include 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1097 new or remanufactured?
Check the current product condition selection for A1097. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1097?
Compare pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
