A1297 12V 20A Alternator Fits Bobcat Mini Loader
Price range: £116.04 through £146.07
Identify a replacement alternator using Sahibs A1297, listed at 12V 20A. Listed applications include selected Bobcat Mini Loader models. Identification references include Lucas LRA01297, Hitachi LR120-23, Delco Remy DA4923. Its listed 12V 20A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1297 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 20 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 46 mm |
| Mounting holes | 3 qty |
| Position | 0° |
| B+ | M5 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.5 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1297 | Dyno Electrics |
| UD91027A | AS-PL |
| 113347 | CARGO |
| F032113347 | CARGO |
| DA4923 | DELCO |
| DRA3813 | DELCO |
| LR120-23 | HITACHI |
| LR13586C | HITACHI |
| 5812003580 | ISUZU |
| 5812210540 | ISUZU |
| CGB-81571 | AINDE |
| CAL20172AS | CASCO |
| 140-14102 | DIXIE |
| A-8813 | DIXIE |
| ALT3157 | ELECTROLOG |
| 28-1571 | ELSTOCK |
| ALH3347 | KRAUF |
| 446841 | LOGISTIK |
| LRA01297 | LUCAS |
| LRA1297 | LUCAS |
| 89213941 | POWERMAX |
| 835.030.020.080 | PSH |
| 835.030.020.515 | PSH |
| 20145271BN | REAL |
| 204-10101 | ROBERT'S |
| 2020172 | SANDO |
| STX100697 | STARDAX |
| 12126N | WAI / TRANSPO |
| 90-25-1056 | WILSON |
| 90-25-1056N | WILSON |
| ALT23002 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| BOBCAT | Mini Loader | 0ccm Diesel | 1982 - |
Description
A1297 Replacement Alternator
For a A1297 alternator enquiry, use Lucas reference LRA01297 alongside the vehicle and original unit details. The listed electrical rating is 12V 20A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Bobcat Mini Loader variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 20A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M5 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Bobcat Mini Loader – selected applications 1982 -.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1297. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
LRA01297, LRA1297, LR120-23, LR13586C, DA4923, DRA3813
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1297 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1297 fit my Bobcat Mini Loader?
Bobcat Mini Loader (1982 -) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1297 replace Lucas LRA01297?
Lucas LRA01297 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1297?
The listed details include 12V, 20A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A1297 new or remanufactured?
Check the current product condition selection for A1297. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1297?
Compare 12V compatibility, 20A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
