A1350 12V 70A Alternator Fits Nissan Pick Up (King Cab), Nissan Urvan
Price range: £133.71 through £169.71
The A1350 12V 70A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Nissan Pick Up (King Cab), Nissan Urvan models. Identification references include Lucas LRA01350, Bosch 986046421, Valeo 437876. Its listed 12V 70A rating provides an electrical matching point for your existing unit. Check the 2-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1350 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 70 A |
| Volt | 12 V |
| No. of Grooves | 2 qty |
| Pulley Diameter | 55 mm |
| Mounting holes | 3 qty |
| Position | 0° |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | Yes |
| Start/Stop | No |
| Weight | 7.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1350 | Dyno Electrics |
| A2014 | AS-PL |
| 986046421 | BOSCH |
| 986046431 | BOSCH |
| 112093 | CARGO |
| F032112093 | CARGO |
| DRA3216 | DELCO |
| DRA3216N | DELCO |
| RAA14327 | DELCO |
| 8EL726393-001 | HELLA |
| 2506114 | HITACHI |
| LR170-407 | HITACHI |
| LR170-407B | HITACHI |
| LR170-407E | HITACHI |
| LR170-407S | HITACHI |
| LR170-407T | HITACHI |
| LR170-408 | HITACHI |
| LR170-408B | HITACHI |
| LR170-408C | HITACHI |
| LR170-408S | HITACHI |
| LR170-408T | HITACHI |
| LR170-412 | HITACHI |
| LR170-412S | HITACHI |
| LR170-412T | HITACHI |
| LR170-413 | HITACHI |
| LR170407F | HITACHI |
| LR190-511 | HITACHI |
| LR190-511B | HITACHI |
| 23100-02N14 | NISSAN |
| 23100-02N15 | NISSAN |
| 23100-02N15-EP | NISSAN |
| 23100-02N18 | NISSAN |
| 23100-02N19 | NISSAN |
| 23100-02N22 | NISSAN |
| 23100-02N23 | NISSAN |
| 23100-20N01 | NISSAN |
| 2310002N13RE | NISSAN |
| 2310002N2B | NISSAN |
| 2310086N01 | NISSAN |
| 20110341 | PRESTOLITE |
| 20130132 | PRESTOLITE |
| 437876 | VALEO |
| ALTS129 | 3EFFE |
| PRAS129 | 3EFFE |
| CGB-13208 | AINDE |
| ANM35436X | ANDEL |
| HXA007 | ASHDOWN INGRAM |
| 002-D392 | ASHIKA |
| AEA3242 | AUTOELECTRO |
| CAL20150AS | CASCO |
| 9363 | CEVAM |
| 65-3014 | CIVIC/DA PARTS |
| 56585 | EAI |
| 28-1732 | ELSTOCK |
| 28-3933 | ELSTOCK |
| 210020 | ERA |
| 9090019 | FRIESEN |
| JA678IR | HC PARTS |
| ALD392 | JAPANPARTS |
| 2D392 | JAPKO |
| 40678RI | KUHNER |
| 11.0678 | LAUBER |
| 445727 | LOGISTIK |
| LRA00556 | LUCAS |
| LRA01350 | LUCAS |
| LRA1350 | LUCAS |
| LRA556 | LUCAS |
| LRB00341 | LUCAS |
| LRB341 | LUCAS |
| 14-044 | PAN PACIFIC |
| 89212408 | POWERMAX |
| 9212408 | POWERMAX |
| 165.811.070.080 | PSH |
| 165.811.070.088 | PSH |
| 165.811.070.360 | PSH |
| 20145051BN | REAL |
| 311924 | RHIAG |
| RNLLR170-407 | RNL |
| 2020150 | SANDO |
| A12HT0160A2 | SIDAT |
| ALT221140 | SIOM |
| ALT5390 | SIOM |
| STX101160 | STARDAX |
| STX101210 | STARDAX |
| 22394N | WAI / TRANSPO |
| ALT32061 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0341 | Large vacuum pump | Small vacuum pump | No |
| A1479 | 70A | 60A | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| NISSAN | Pick Up (King Cab) | 2.5 (2494ccm) Diesel | TD25 | D21 | 1996 - 1998 | ||
| NISSAN | Urvan | 2.3 (2289ccm) Diesel | SD23 | E23 | 1982 - 1988 | ||
| NISSAN | Urvan | 2.3 (2289ccm) Diesel | TD23 | E24 | 1988 - 1989 | ||
| NISSAN | Urvan | 2.5 (2494ccm) Diesel | TD25 | E24 | 1988 - 1997 |
Description
A1350 Replacement Alternator
The A1350 alternator is a replacement unit identified by Lucas reference LRA01350. The listed electrical rating is 12V 70A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Nissan Pick Up (King Cab) 2.5 Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 70A output: compare the listed rating with the original alternator.
- 2-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Nissan Pick Up (King Cab) 2.5 Diesel – selected applications 1996–1998 (engine code TD25).
- Nissan Urvan 2.3 Diesel – selected applications 1982–1988 (engine code SD23).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1350. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
986046421, 986046431, 437876, LRA01350, LRA00556, LRA1350, LRA556, LRB00341, LRB341, 2506114, LR170-407, LR170-407B, LR170-407E, LR170-407S, LR170-407T, LR170-408, LR170-408B, LR170-408C, LR170-408S, LR170-408T, LR170-412, LR170-412S, LR170-412T, LR170-413, LR170407F, LR170412, LR170412S, LR170412T, LR170413, LR190-511, LR190-511B, LR190511, DRA3216, DRA3216N, RAA14327, 20110341, 20130132
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1350 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1350 fit my Nissan Pick Up (King Cab)?
Nissan Pick Up (King Cab) 2.5 Diesel (1996–1998) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1350 replace Lucas LRA01350?
Lucas LRA01350 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1350?
The listed details include 12V, 70A output, 2 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1350 new or remanufactured?
Check the current product condition selection for A1350. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1350?
Compare 12V compatibility, 70A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
