A1543 12V 40A Alternator Fits Solè Diesel Mini-11, Vetus Marine M2.06
Price range: £137.93 through £175.06
The A1543 12V 40A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected SolÈ Diesel Mini-11, SolÈ Diesel Mini-17, SolÈ Diesel Mini-26, SolÈ Diesel Mini-48 models. Identification references include Lucas LRA01543, Bosch F032111832, Mitsubishi Electric A000T25171. Its listed 12V 40A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1543 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 40 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 45.5 mm |
| Mounting holes | 3 qty |
| Position | 0° |
| B+ | M5 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 3.12 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1543 | Dyno Electrics |
| UD30018A | AS-PL |
| F032111832 | BOSCH |
| 111832 | CARGO |
| 138008 | CATERPILLAR |
| 1038008 | CATERPILLAR |
| A000T25171 | MITSUBISHI |
| A000T25271 | MITSUBISHI |
| A000T25371 | MITSUBISHI |
| A000T25373 | MITSUBISHI |
| A000T25471 | MITSUBISHI |
| A0T25171 | MITSUBISHI |
| A0T25271 | MITSUBISHI |
| A0T25371 | MITSUBISHI |
| A0T25373 | MITSUBISHI |
| A0T25471 | MITSUBISHI |
| MM131020 | MITSUBISHI |
| MM432804 | MITSUBISHI |
| MM435081 | MITSUBISHI |
| MM435752 | MITSUBISHI |
| MM438844 | MITSUBISHI |
| 99021126M | PRESTOLITE |
| AC-CBA5041 | ACAUTO |
| 10442064 | ALANKO |
| AMT0133 | ARROWHEAD |
| AMI165A | AUTOTEAM |
| L610953 | BTS TURBO |
| L611607 | BTS TURBO |
| CAL35165AS | CASCO |
| 143-01101 | DIXIE |
| A-8574 | DIXIE |
| 28-2645 | ELSTOCK |
| 3112199 | HENKEL PARTS |
| ALM5371 | KRAUF |
| 553044RI | KUHNER |
| 446872 | LOGISTIK |
| LRA01543 | LUCAS |
| LRA1543 | LUCAS |
| 5535974 | MEAT & DORIA |
| 155.008.040.130 | PSH |
| 20137561OE | REAL |
| 4G1312 | RIDEX |
| 230-00100NOE | ROBERT'S |
| 2035165 | SANDO |
| A12MH0358 | SIDAT |
| A12MH0358A2 | SIDAT |
| PL8338 | SNRA |
| SKGN-03221535 | STARK |
| 12231N | WAI / TRANSPO |
| 70-27-12231 | WILSON |
| ALT31112 | WOODAUTO |
| WOOALT31112 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| SOLÈ DIESEL | Mini-11 | 464ccm Diesel | |||||
| SOLÈ DIESEL | Mini-17 | 635ccm Diesel | |||||
| SOLÈ DIESEL | Mini-26 | 952ccm Diesel | |||||
| SOLÈ DIESEL | Mini-48 | 1994ccm Diesel | |||||
| VETUS MARINE | M2.06 | 635ccm Diesel | |||||
| VETUS MARINE | M3.10 | 979ccm Diesel | 1995 - |
Description
A1543 Replacement Alternator
The Sahibs A1543 alternator is associated with Lucas reference LRA01543 for replacement identification. The listed electrical rating is 12V 40A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected SolÈ Diesel Mini-11 464ccm Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 40A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M5 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- SolÈ Diesel Mini-11 464ccm Diesel.
- SolÈ Diesel Mini-17 635ccm Diesel.
- SolÈ Diesel Mini-26 952ccm Diesel.
- SolÈ Diesel Mini-48 1994ccm Diesel.
- Vetus Marine M2.06 635ccm Diesel.
- Vetus Marine M3.10 979ccm Diesel – selected applications 1995 -.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1543. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
F032111832, LRA01543, LRA1543, A000T25171, A000T25271, A000T25371, A000T25373, A000T25471, A0T25171, A0T25271, A0T25371, A0T25373, A0T25471, MM131020, MM432804, MM435081, MM435752, MM438844, 99021126M
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1543 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1543 fit my SolÈ Diesel Mini-11?
SolÈ Diesel Mini-11 464ccm Diesel is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1543 replace Lucas LRA01543?
Lucas LRA01543 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1543?
The listed details include 12V, 40A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A1543 new or remanufactured?
Check the current product condition selection for A1543. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1543?
Compare 12V compatibility, 40A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
