A1572 12V 65A Alternator Fits Peugeot Expert, Citroën Jumpy
Price range: £91.95 through £121.81
The A1572 12V 65A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Peugeot Expert, CitroËN Jumpy, Fiat Brava, Fiat Bravo models. Identification references include Lucas LRA01572, Bosch 124215002, Valeo 437815. Its listed 12V 65A rating provides an electrical matching point for your existing unit. Check the 6-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A1572 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 65 A |
| Volt | 12 V |
| No. of Grooves | 6 qty |
| Pulley Diameter | 62 mm |
| Mounting holes | 3 qty |
| Position | 20° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.12 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA1572 | Dyno Electrics |
| 401650181 | Euro Car Part |
| 124215002 | BOSCH |
| 111416 | CARGO |
| F032111416 | CARGO |
| DA4516 | DELCO |
| DA4516N | DELCO |
| DRA3406 | DELCO |
| DRA3406N | DELCO |
| DRA3406X | DELCO |
| RAA14517 | DELCO |
| 46000357 | FIAT |
| 46231699 | FIAT |
| 46407645 | FIAT |
| 46420961 | FIAT |
| 46420964 | FIAT |
| 46420965 | FIAT |
| 46434932 | FIAT |
| 46434935 | FIAT |
| 46464275 | FIAT |
| 46464276 | FIAT |
| 5895029 | FIAT |
| 7721122 | FIAT |
| 7778020 | FIAT |
| 8EL011710-111 | HELLA |
| 63320511 | MAGNETI MARELLI |
| 63321367 | MAGNETI MARELLI |
| 63321615 | MAGNETI MARELLI |
| 63321660 | MAGNETI MARELLI |
| 63321661 | MAGNETI MARELLI |
| 9.43E+11 | MAGNETI MARELLI |
| 9.44E+11 | MAGNETI MARELLI |
| MAN807 | MAGNETI MARELLI |
| MAR807 | MAGNETI MARELLI |
| MRA90067 | MAGNETI MARELLI |
| 46540293 | PEUGEOT |
| 57057Q | PEUGEOT |
| 5705GV | PEUGEOT |
| 437815 | VALEO |
| ALTL142 | 3EFFE |
| PRAL142 | 3EFFE |
| CGB-82706 | AINDE |
| AEA2216 | AUTOELECTRO |
| CAL30102AS | CASCO |
| CAL30102GS | CASCO |
| CAL30102OS | CASCO |
| 4502 | CEVAM |
| 56989 | EAI |
| 28-2706 | ELSTOCK |
| 210251 | ERA |
| AG0220 | GHIBAUDI |
| CA1084IR | HC PARTS |
| ALE1084 | KRAUF |
| 301084RI | KUHNER |
| 301084RIM | KUHNER |
| 301084RIR | KUHNER |
| LRA01572 | LUCAS |
| LRA1572 | LUCAS |
| 5530072 | MEAT & DORIA |
| 89212947 | POWERMAX |
| 505.515.065.050 | PSH |
| 20104201BN | REAL |
| 20104201OE | REAL |
| 20104201RE | REAL |
| 4G0859R | RIDEX |
| ALT122 | ROLLCO |
| 2030102 | SANDO |
| 2030102.1 | SANDO |
| 2030102.4 | SANDO |
| A12MA1191A2 | SIDAT |
| ALT2340 | SIOM |
| ALT2340A | SIOM |
| ALT2340RS | SIOM |
| STX100320 | STARDAX |
| STX100588 | STARDAX |
| STX100588R | STARDAX |
| 21216N | WAI / TRANSPO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A1581 | 65A | 85A | Yes |
| A1771 | Pulley | No | |
| B0216 | Pulley | No | |
| A1864 | 65A | 75A | Yes |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CITROËN | Jumpy | 1.6 (1581ccm) Petrol | 220A2000 | U6UG | 1995 - 2000 | ||
| CITROËN | Jumpy | 1.6 (1581ccm) Petrol | 220A2000 | U6UT | 1995 - 2000 | ||
| FIAT | Brava | 1.9 (1929ccm) Diesel | 160A7000 | 182BE | 1995 - 1998 | ||
| FIAT | Bravo | 1.9 (1929ccm) Diesel | 160A7000 | 182AE | 1995 - 1998 | ||
| FIAT | Palio | 1.0 (994ccm) Petrol | 178A1000 | 178BXA1A | 1996 - 2001 | ||
| FIAT | Palio | 1.7 (1698ccm) Diesel | 176B3000 | 178BXN1AAM | 1996 - 2002 | ||
| FIAT | Palio | 1.7 (1698ccm) Diesel | 176A5000 | 178BXN1A | 2001 - 2012 | ||
| FIAT | Palio | 1.7 (1698ccm) Diesel | 176A3000 | 178B | 2002 - 2012 | ||
| FIAT | Palio Weekend | 1.7 (1698ccm) Diesel | 176A3000 | 173/178DXH1A | 1996 - 2000 | ||
| FIAT | Punto | 1.7 (1698ccm) Diesel | 176A3000 | 176AG/176CG | 1994 - 1999 | ||
| FIAT | Punto | 1.7 (1698ccm) Diesel | 176A5000 | 176AF | 1994 - 1997 | ||
| FIAT | Punto | 1.7 (1698ccm) Diesel | 176B3000 | 176AI | 1994 - 1997 | ||
| FIAT | Punto | 1.7 (1698ccm) Diesel | 176B7000 | 176AT | 1996 - 1999 | ||
| FIAT | Punto Van | 1.7 (1698ccm) Diesel | 176B3000 | 176AI | 1996 - 2000 | ||
| FIAT | Punto Van | 1.7 (1698ccm) Diesel | 176A5000 | 176AF | 1996 - 1999 | ||
| FIAT | Punto Van | 1.7 (1698ccm) Diesel | 176B7000 | 176AT | 1997 - 2000 | ||
| FIAT | Siena | 1.7 (1698ccm) Diesel | 176A3000 | 178 | 2006 - 2012 | ||
| PEUGEOT | Expert | 1.6 (1581ccm) Petrol | 220A2000 | 222AA2 | 1995 - 2000 | ||
| PEUGEOT | Expert | 1.6 (1581ccm) Petrol | 220A2000 | Plancher | 223AA2 | 1995 - 2000 | |
| PEUGEOT | Expert | 1.6 (1581ccm) Petrol | 220A2000 | 224AA2 | 1996 - 2000 |
Description
A1572 Replacement Alternator
For a A1572 alternator enquiry, use Lucas reference LRA01572 alongside the vehicle and original unit details. The listed electrical rating is 12V 65A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Peugeot Expert 1.6 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 65A output: compare the listed rating with the original alternator.
- 6-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Peugeot Expert 1.6 Petrol – selected applications 1995–2000 (engine code 220A2000).
- CitroËN Jumpy 1.6 Petrol – selected applications 1995–2000 (engine code 220A2000).
- Fiat Brava 1.9 Diesel – selected applications 1995–1998 (engine code 160A7000).
- Fiat Bravo 1.9 Diesel – selected applications 1995–1998 (engine code 160A7000).
- Fiat Palio 1.0 Petrol – selected applications 1996–2001 (engine code 178A1000).
- Fiat Palio Weekend 1.7 Diesel – selected applications 1996–2000 (engine code 176A3000).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A1572. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
124215002, 437815, LRA01572, LRA1572, DA4516, DA4516N, DRA3406, DRA3406N, DRA3406X, RAA14517, 46540293, 57057Q, 5705GV
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A1572 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A1572 fit my Peugeot Expert?
Peugeot Expert 1.6 Petrol (1995–2000) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A1572 replace Lucas LRA01572?
Lucas LRA01572 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A1572?
The listed details include 12V, 65A output, 6 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is A1572 new or remanufactured?
Check the current product condition selection for A1572. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A1572?
Compare 12V compatibility, 65A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
