A4306 120A Alternator Fits Bobcat TL470HF, Deutz-Fahr Agrovector 37.6
Price range: £135.11 through £168.89
The A4306 120A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected Bobcat TL470HF, Deutz-Fahr Agrovector 37.6, Deutz-Fahr Agrovector 37.7, Giant V761T models. Identification references include Lucas LRA04306, Mahle 72735164, Iskra / Letrika 11.204.137. Its listed 120A rating provides an electrical matching point for your existing unit. Compare the pulley, connections and mounting arrangement with your existing alternator. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A4306 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 120 A |
| Mounting holes | 2 qty |
| Position | -60° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA4306 | Dyno Electrics |
| UD12943(LETRIKA)A | AS-PL |
| 116547 | CARGO |
| F032116547 | CARGO |
| 8EL015643-521 | HELLA |
| 11.204.137 | ISKRA / LETRIKA |
| 11.204.717 | ISKRA / LETRIKA |
| 11.204.779 | ISKRA / LETRIKA |
| AAK3869 | ISKRA / LETRIKA |
| AAK4954 | ISKRA / LETRIKA |
| AAK4990 | ISKRA / LETRIKA |
| IA1473 | ISKRA / LETRIKA |
| 1183868 | KHD |
| 1183887 | KHD |
| 4123607 | KHD |
| 4124784 | KHD |
| 72735164 | MAHLE |
| MG165 | MAHLE |
| ALTJ400 | 3EFFE |
| 3972863M1 | AGCO |
| 28-7915CT | AINDE |
| CGB-11473 | AINDE |
| ANM100044 | ANDEL |
| G104784 | BTS TURBO |
| G104785 | BTS TURBO |
| CAL21171GS | CASCO |
| 2648 | CEVAM |
| 160-84124 | DIXIE |
| 5881171202 | DRI |
| ALT79535 | ELECTROLOG |
| 28-7915 | ELSTOCK |
| 114707 | FARCOM |
| 3119663 | HENKEL PARTS |
| 20021171OV | ITAB AUTOMOTIVE |
| ALI2182 | KRAUF |
| 554951RI | KUHNER |
| 554951RIM | KUHNER |
| LEA1212 | LE PART |
| 11839 | LESTER |
| 441782 | LOGISTIK |
| LRA04306 | LUCAS |
| LRA4306 | LUCAS |
| 89216731 | POWERMAX |
| 515.005.120.090 | PSH |
| 515.005.120.311 | PSH |
| 20119171OE | REAL |
| 282-30275 | ROBERT'S |
| 282-30275NOE | ROBERT'S |
| 2021171.1 | SANDO |
| A12ML0547 | SIDAT |
| A12ML0547A2 | SIDAT |
| ALT231710 | SIOM |
| AL04176 | TMI |
| 11839N | WAI / TRANSPO |
| WG2043435 | WILMINK GROUP |
| 90-23-6586 | WILSON |
| ALT20717 | WOODAUTO |
| WOOALT20717 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A4332 | 120A | 95A | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| BOBCAT | TL470HF | 3622ccm Diesel | Deutz TCD3.6L4 | 2013 - | |||
| DEUTZ-FAHR | Agrovector 37.6 | 3622ccm Diesel | TCD 3.6L4 | 2013 - | |||
| DEUTZ-FAHR | Agrovector 37.7 | 3622ccm Diesel | TCD 3.6L4 | 2013 - | |||
| GIANT | V761T | 2900ccm Diesel | TD 2.9L04 | 2013 - | |||
| MASSEY FERGUSON TELEHANDLER | 9306 Xtra | 3622ccm Diesel | TCD 3.6L4 | 2013 - | |||
| MASSEY FERGUSON TELEHANDLER | 9407 Xtra | 3622ccm Diesel | TCD 3.6L4 | 2013 - | |||
| MASSEY FERGUSON TELEHANDLER | 9407S Xtra | 3622ccm Diesel | TCD 3.6L4 | 2013 - |
Description
A4306 Replacement Alternator
For a A4306 alternator enquiry, use Lucas reference LRA04306 alongside the vehicle and original unit details. The listed electrical rating is 120A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Bobcat TL470HF 3622ccm Diesel variants.
Key Features and Benefits
- 120A output: compare the listed rating with the original alternator.
- 2 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
- Lucas LRA04306 reference: a starting point for identifying the replacement.
Compatible Vehicles and Applications
- Bobcat TL470HF 3622ccm Diesel – selected applications 2013 – (engine code Deutz TCD3.6L4).
- Deutz-Fahr Agrovector 37.6 3622ccm Diesel – selected applications 2013 – (engine code TCD 3.6L4).
- Deutz-Fahr Agrovector 37.7 3622ccm Diesel – selected applications 2013 – (engine code TCD 3.6L4).
- Giant V761T 2900ccm Diesel – selected applications 2013 – (engine code TD 2.9L04).
- Massey Ferguson Telehandler 9306 Xtra 3622ccm Diesel – selected applications 2013 – (engine code TCD 3.6L4).
- Massey Ferguson Telehandler 9407 Xtra 3622ccm Diesel – selected applications 2013 – (engine code TCD 3.6L4).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A4306. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
LRA04306, LRA4306, 72735164, MG165, 11.204.137, 11.204.717, 11.204.779, AAK3869, AAK4954, AAK4990, IA1473
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A4306 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will A4306 fit my Bobcat TL470HF?
Bobcat TL470HF 3622ccm Diesel (2013 -) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does A4306 replace Lucas LRA04306?
Lucas LRA04306 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A4306?
The listed details include 120A output. Compare the complete specifications on this page with the unit being replaced.
Is A4306 new or remanufactured?
Check the current product condition selection for A4306. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A4306?
Compare 120A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
