A4426 12V 65A Alternator Replaces Lucas LRA04426
Price range: £95.10 through £124.36
Compare the A4426 12V 65A alternator from Sahibs Auto Electrics with the unit currently fitted. Use the original unit reference and vehicle details to confirm the application. Identification references include Lucas LRA04426, Bosch 9120143227, Valeo 2518051A. Its listed 12V 65A rating provides an electrical matching point for your existing unit. Check the single-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your A4426 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 65 A |
| Volt | 12 V |
| No. of Grooves | 1 qty |
| Pulley Diameter | 62 mm |
| Mounting holes | 2 qty |
| Position | 0° |
| B+ | M5 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 4.6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYA4426 | Dyno Electrics |
| 1076690M91 | Massey Ferguson |
| 110970 | HC-Cargo |
| 111948 | HC-Cargo |
| 11201693 | Mahle |
| 11201961 | Mahle |
| 11204374 | Mahle |
| 12103N | WAI |
| 1674516M91 | Massey Ferguson |
| 1674517M1 | Massey Ferguson |
| 1691795R92 | Massey Ferguson |
| 1699872R1 | Massey Ferguson |
| 1699872T | Massey Ferguson |
| 1874616M1 | Massey Ferguson |
| 21596N | WAI |
| 23835E | Lucas |
| 23VCART | RNL |
| 2518051A | Valeo |
| 2541130 | Valeo |
| 2541131 | Valeo |
| 2541148 | Valeo |
| 2925670 | Valeo |
| 2940772 | Valeo |
| 2950700 | Valeo |
| 3581387 | Massey Ferguson |
| 3581387M1 | Massey Ferguson |
| 3581387R1 | Agco |
| 3581388M1 | Massey Ferguson |
| 3930502R91 | Massey Ferguson |
| 3930503R1 | Massey Ferguson |
| 3933144M91 | Agco |
| 436264 | Valeo |
| 51039 | Prestolite |
| 51056 | Prestolite |
| 541131 | Valeo |
| 6005003157 | Renault |
| 6005701123 | Renault |
| 61920260 | Lucas |
| 66021147 | Lucas |
| 66021147010 | Magneti Marelli |
| 66021479 | Prestolite |
| 66021583 | Prestolite |
| 705004065 | PSH |
| 72735271 | Mahle |
| 7700017041 | Renault |
| 9120143227 | Bosch |
| 9AR2826K | Prestolite |
| 9AR5070 | Motorola |
| 9AR5070K | Motorola |
| A100 | Leyland |
| A131 | Leyland |
| A132 | Leyland |
| A5002B | Prestolite |
| AAK3348 | Mahle |
| AAK4554 | Mahle |
| AAK4823 | Mahle |
| AGC3933144M91 | Wood Auto |
| ALT14569 | Wood Auto |
| ALT16010 | Wood Auto |
| ALT20674 | Wood Auto |
| CA1387IR | HC-Parts |
| CA1461IR | HC-Parts |
| CA23V | HC-Parts |
| DRA3463 | Delco Remy |
| DRA3549 | Delco Remy |
| F032110970 | HC-Cargo |
| F032111948 | HC-Cargo |
| HCA1387IR | HC-Parts |
| IA0693 | Mahle |
| IA0961 | Mahle |
| LEA0088 | Lucas |
| LEA0277 | Lucas |
| LEA0503 | Lucas |
| LETIA0693 | Wood Auto |
| LRA00220 | Lucas |
| LRA00959 | Lucas |
| LRA00961 | Lucas |
| LRA00964 | Lucas |
| LRA02621 | Lucas |
| LRA04426 | Lucas |
| LRA220 | Lucas |
| LRA2621 | Lucas |
| LRA4426 | Lucas |
| LRA959 | Lucas |
| LRA961 | Lucas |
| LRA964 | Lucas |
| MAHMG272 | Wood Auto |
| MAHMG416 | Wood Auto |
| MG272 | Mahle |
| MG416 | Mahle |
| NAB302 | Lucas |
| PRE66021147 | Wood Auto |
| PRE66021583 | Wood Auto |
| PREA5002B | Wood Auto |
| WOOALT14569 | Wood Auto |
| WOOALT16010 | Wood Auto |
| WOOALT7012 | Wood Auto |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - |
Description
A4426 Replacement Alternator
The A4426 alternator is a replacement unit identified by Lucas reference LRA04426. The listed electrical rating is 12V 65A. An alternator maintains battery charge and supplies electrical power while the engine runs. Confirm the vehicle application with the team before ordering.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 65A output: compare the listed rating with the original alternator.
- Single-groove pulley: check belt profile and alignment against the existing unit.
- 2 mounting holes: compare the fixing pattern and unit position.
- M5 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
Quote A4426 and LRA04426 with your vehicle details so the team can check the application. Compare the original part number, engine and physical unit rather than relying on a general model description.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with A4426. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
9120143227, 2518051A, 2541130, 2541131, 2541148, 2925670, 2940772, 2950700, 436264, 541131, LRA04426, 23835E, 61920260, 66021147, LEA0088, LEA0277, LEA0503, LRA00220, LRA00959, LRA00961, LRA00964, LRA02621, LRA220, LRA2621, LRA4426, LRA959, LRA961, LRA964, NAB302, DRA3463, DRA3549, 51039, 51056, 66021479, 66021583, 9AR2826K, A5002B, 11201693, 11201961, 11204374, 72735271, AAK3348, AAK4554, AAK4823, IA0693, IA0961, MG272, MG416, 6005003157, 6005701123, 7700017041, 1076690M91, 1674516M91, 1674517M1, 1691795R92, 1699872R1, 1699872T, 1874616M1, 3581387, 3581387M1, 3581388M1, 3930502R91, 3930503R1
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying A4426 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
How can I confirm the vehicle application for A4426?
Quote A4426, Lucas LRA04426, your vehicle registration and the existing unit number for an application check.
Does A4426 replace Lucas LRA04426?
Lucas LRA04426 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for A4426?
The listed details include 12V, 65A output, 1 pulley groove. Compare the complete specifications on this page with the unit being replaced.
Is A4426 new or remanufactured?
Check the current product condition selection for A4426. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering A4426?
Compare 12V compatibility, 65A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
