B0286 12V 100A Alternator Fits Ford Transit 100, Ford Transit 120
Price range: £82.56 through £110.50
Sahibs B0286 is a replacement alternator with a listed 12V 100A rating. Listed applications include selected Ford Transit 100, Ford Transit 120, Ford Transit 150, Ford Transit 190 models. Identification references include Lucas LRB00286. Its listed 12V 100A rating provides an electrical matching point for your existing unit. Check the 6-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0286 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 100 A |
| Volt | 12 V |
| No. of Grooves | 6 qty |
| Pulley Diameter | 54 mm |
| Mounting holes | 3 qty |
| B+ | M6 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0286 | Dyno Electrics |
| 401591241 | Euro Car Part |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| A1374 | Pulley PV6/55 Without batteri sensor | Pulley PV6/65 With batteri Sensor | No |
| A0960 | 100A With W terminal Placing of terminals Pulley PV6/55 | 90A Without W terminal Placing of terminals Pulley PV6/53 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| FORD | Transit 100 | 2.0 (1998ccm) CNG (with or without Petrol) | NSHCNG | FT100L/FT100S | 1994 - 2000 | ||
| FORD | Transit 100 | 2.0 (1998ccm) Petrol | NSF/NSG/NSH | FT100L/FT100S | 1994 - 2000 | ||
| FORD | Transit 100 | 2.0 (1998ccm) Petrol | NSF/NSG | FT100L/FT100S | 1994 - 2000 | ||
| FORD | Transit 120 | 2.0 (1998ccm) Petrol | NSF/NSG | FT120S | 1994 - 2000 | ||
| FORD | Transit 150 | 2.0 (1998ccm) CNG (with or without Petrol) | NSHCNG | FT150L | 1994 - 2000 | ||
| FORD | Transit 150 | 2.0 (1998ccm) Petrol | NSF/NSG | FT150L/FT150S | 1994 - 2000 | ||
| FORD | Transit 150 | 2.0 (1998ccm) Petrol | NSF/NSG/NSH | FT150L | 1994 - 2000 | ||
| FORD | Transit 150 | 2.0 (1998ccm) Petrol | NSF/NSG/NSH | FT150L/FT150S | 1994 - 2000 | ||
| FORD | Transit 190 | 2.0 (1998ccm) Petrol | NSF/NSG | FT190EF/FT190L | 1994 - 2000 | ||
| FORD | Transit 190 | 2.0 (1998ccm) Petrol | NSF/NSG/NSH | FT190L | 1994 - 2000 | ||
| FORD | Transit 80 | 2.0 (1998ccm) Petrol | NSF/NSG/NSH | FT80S | 1994 - 2000 | ||
| FORD | Transit Tourneo | 2.0 (1998ccm) Petrol | NSF/NSG/NSH | FT100 | 1994 - 2000 |
Description
B0286 Replacement Alternator
Choose a replacement by comparing the B0286 alternator and its Lucas reference, LRB00286, with your existing unit. The listed electrical rating is 12V 100A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected Ford Transit 100 2.0 CNG (with or without Petrol) variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 100A output: compare the listed rating with the original alternator.
- 6-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M6 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Ford Transit 100 2.0 CNG (with or without Petrol) – selected applications 1994–2000 (engine code NSHCNG).
- Ford Transit 120 2.0 Petrol – selected applications 1994–2000 (engine code NSF/NSG).
- Ford Transit 150 2.0 CNG (with or without Petrol) – selected applications 1994–2000 (engine code NSHCNG).
- Ford Transit 190 2.0 Petrol – selected applications 1994–2000 (engine code NSF/NSG).
- Ford Transit 80 2.0 Petrol – selected applications 1994–2000 (engine code NSF/NSG/NSH).
- Ford Transit Tourneo 2.0 Petrol – selected applications 1994–2000 (engine code NSF/NSG/NSH).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0286. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
LRB00286
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0286 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0286 fit my Ford Transit 100?
Ford Transit 100 2.0 CNG (with or without Petrol) (1994–2000) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0286 replace Lucas LRB00286?
Lucas LRB00286 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0286?
The listed details include 12V, 100A output, 6 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0286 new or remanufactured?
Check the current product condition selection for B0286. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0286?
Compare 12V compatibility, 100A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
