B0480 12V 90A Alternator Fits VW Golf, VW Lupo, VW Polo
Price range: £79.85 through £106.88
The B0480 12V 90A Alternator is a replacement charging unit from Sahibs Auto Electrics. Listed applications include selected VW Golf, VW Lupo, VW Polo, Seat Alhambra models. Identification references include Lucas LRB00480, Bosch 124325015, Valeo 2542280. Its listed 12V 90A rating provides an electrical matching point for your existing unit. Check the 6-groove pulley, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0480 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 90 A |
| Volt | 12 V |
| No. of Grooves | 6 qty |
| Pulley Diameter | 50 mm |
| Mounting holes | 3 qty |
| Position | 80° |
| B+ | M8 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 5.6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0480 | Dyno Electrics |
| 401442481 | Euro Car Part |
| A0188 | AS-PL |
| 124325015 | BOSCH |
| 124325033 | BOSCH |
| 986041310 | BOSCH |
| 112408 | CARGO |
| F032112408 | CARGO |
| DRB1310 | DELCO |
| 8EL737814-001 | HELLA |
| IA1304 | ISKRA / LETRIKA |
| 20130117 | PRESTOLITE |
| 2542280 | VALEO |
| 2542840 | VALEO |
| 437403 | VALEO |
| 439444 | VALEO |
| SG9B023 | VALEO |
| SG9B069 | VALEO |
| 036903024L | VW |
| 036903024LX | VW |
| 037903025H | VW |
| 037903025P | VW |
| 037903025PX | VW |
| 038903018C | VW |
| 038903018CX | VW |
| 059903015H | VW |
| 36903024L | VW |
| 36903024LX | VW |
| 37903025H | VW |
| 37903025P | VW |
| 37903025PX | VW |
| 38903018C | VW |
| 38903018CX | VW |
| ALT2130 | 3EFFE |
| ALTS980 | 3EFFE |
| PRAS980 | 3EFFE |
| PRAS980V | 3EFFE |
| CGB-83914 | AINDE |
| ANM43530X | ANDEL |
| AAL2047 | APEC |
| AEA4280 | AUTOELECTRO |
| STA0408R | BOVEZ |
| CAL15281GS | CASCO |
| 4063 | CEVAM |
| 56856 | EAI |
| ALT00792 | ELECTROLOG |
| ALT1458 | ELECTROLOG |
| 28-3914 | ELSTOCK |
| 210731 | ERA |
| 9041310 | FRIESEN |
| CA1560IR | HC PARTS |
| 32041310 | HERTH+BUSS |
| 301560RI | KUHNER |
| 11.156 | LAUBER |
| 441707 | LOGISTIK |
| LRB00480 | LUCAS |
| LRB480 | LUCAS |
| NPANAL2047 | NAPA |
| 89213033 | POWERMAX |
| 9213033 | POWERMAX |
| 305.530.090.010 | PSH |
| 305.530.090.500 | PSH |
| 20179182OE | REAL |
| 310895 | RHIAG |
| RNL4131 | RNL |
| 2015281 | SANDO |
| A12BH0401A2 | SIDAT |
| A12VA0401 | SIDAT |
| ALT172810 | SIOM |
| STX100325 | STARDAX |
| STX100325R | STARDAX |
| STX100413 | STARDAX |
| STX100413R | STARDAX |
| 21480R | WAI / TRANSPO |
| ALT14238 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| B0479 | 90A | 70A | No |
| A2360 | 90A | 110A | Yes |
| A1997 | Pulley PV6/50 | Pulley PV6/56 | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| SEAT | Alhambra | 2.0 (1984ccm) Petrol | ADY/ATM | 7V8/7V9 | 1999 - 2000 | ||
| SEAT | Alhambra Van | 2.0 (1984ccm) Petrol | ADY/ATM | 7V8/7V9 | 1999 - 2000 | ||
| SEAT | Arosa | 1.0 (999ccm) Petrol | AER/ALD/ALL/ANV/AUC | 6H1 | 1999 - 1999 | ||
| SEAT | Cordoba | 1.4 (1390ccm) Petrol | BBY/BKY | 6L2 | 2002 - 2007 | ||
| SEAT | Cordoba | 1.4 (1390ccm) Petrol | BBZ | 6L2 | 2002 - 2009 | ||
| SEAT | Cordoba | 1.6 (1598ccm) Petrol | BAH | 6L2 | 2003 - 2009 | ||
| SEAT | Ibiza | 1.0 (999ccm) Petrol | AST/AVZ | II | 6K1 | 1999 - 2002 | |
| SEAT | Ibiza | 1.4 (1390ccm) Petrol | AUB/BBZ | III | 6L1 | 2001 - 2009 | |
| SEAT | Ibiza | 1.4 (1390ccm) Petrol | BXW | III | 6L1 | 2006 - 2009 | |
| SEAT | Ibiza | 1.6 (1598ccm) Petrol | BAH | III | 6L1 | 2003 - 2009 | |
| SEAT | Ibiza SC | 1.4 (1390ccm) Petrol | BXW/CGGB | IV | Sportcoupe | 6J1 | 2008 - 2015 |
| SEAT | Ibiza ST | 1.4 (1390ccm) Petrol | CGGB | IV | ST | 6J8 | 2010 - 2015 |
| SEAT | Toledo | 1.4 (1390ccm) Petrol | BXW | III | 5P2 | 2006 - 2009 | |
| SKODA | Fabia | 1.4 (1390ccm) Petrol | BKY | I | Praktik | 6Y5 | 2004 - 2007 |
| SKODA | Fabia | 1.4 (1390ccm) Petrol | BUD | I | 6Y5 | 2006 - 2007 | |
| SKODA | Fabia | 1.4 (1390ccm) Petrol | BUD | I | 6Y3 | 2006 - 2007 | |
| SKODA | Fabia | 1.4 (1390ccm) Petrol | BXW/CGGB | II | 545 | 2007 - 2014 | |
| SKODA | Fabia Scout | 1.4 (1390ccm) Petrol | CGGB | II | 545 | 2010 - 2014 | |
| SKODA | Roomster | 1.4 (1390ccm) Petrol | BXW/CGGB | 5J7 | 2006 - 2015 | ||
| SKODA | Roomster Praktik | 1.4 (1390ccm) Petrol | BXW/CGGB | Praktik | 5J7 | 2007 - 2015 | |
| SKODA | Roomster Scout | 1.4 (1390ccm) Petrol | BXW/CGGB | 5J7 | 2006 - 2015 | ||
| VW | Golf | 1.4 (1390ccm) Petrol | BUD | V | Variant | 1K5 | 2007 - 2009 |
| VW | Golf | 2.0 (1984ccm) Petrol | CCZA | VI | Variant | AJ5 | 2009 - 2013 |
| VW | Lupo | 1.0 (999ccm) Petrol | AER/ALD/ALL/ANV/AUC | I | 6X1 | 1998 - 2005 | |
| VW | Polo | 1.0 (999ccm) Petrol | AER/ALD/ALL/AUC | III | 6N1/6N2 | 1995 - 2001 | |
| VW | Polo | 1.4 (1390ccm) Petrol | AEX/AKK/AKV/APQ/AUD | III | 6N1/6N2 | 1995 - 2001 | |
| VW | Polo | 1.4 (1390ccm) Petrol | AFH/AFK/AQQ/AUB | III | 6N1/6N2 | 2001 - 2001 | |
| VW | Polo | 1.4 (1390ccm) Petrol | ANX | III | 6V5 | 1998 - 1999 | |
| VW | Polo | 1.4 (1390ccm) Petrol | AUA/BBY/BKY | IV | Cross | 9N1/9N3 | 2001 - 2008 |
| VW | Polo | 1.4 (1390ccm) Petrol | AUB/BBZ | IV | Cross | 9N1/9N3 | 2001 - 2008 |
| VW | Polo | 1.4 (1390ccm) Petrol | BUD | IV | Cross | 9N3 | 2006 - 2009 |
| VW | Polo | 1.4 (1390ccm) Petrol | CGGB/CLPA | V | Cross | 6R1 | 2009 - 2014 |
Description
B0480 Replacement Alternator
Start your B0480 alternator comparison with the linked Lucas reference LRB00480 and the specifications shown on this page. The listed electrical rating is 12V 90A. An alternator maintains battery charge and supplies electrical power while the engine runs. Applications include selected VW Golf 1.4 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 90A output: compare the listed rating with the original alternator.
- 6-groove pulley: check belt profile and alignment against the existing unit.
- 3 mounting holes: compare the fixing pattern and unit position.
- M8 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- VW Golf 1.4 Petrol – selected applications 2007–2009 (engine code BUD).
- VW Lupo 1.0 Petrol – selected applications 1998–2005 (engine code AER/ALD/ALL/ANV/AUC).
- VW Polo 1.0 Petrol – selected applications 1995–2001 (engine code AER/ALD/ALL/AUC).
- Seat Alhambra 2.0 Petrol – selected applications 1999–2000 (engine code ADY/ATM).
- Seat Alhambra Van 2.0 Petrol – selected applications 1999–2000 (engine code ADY/ATM).
- Seat Arosa 1.0 Petrol – selected applications 1999–1999 (engine code AER/ALD/ALL/ANV/AUC).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0480. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
124325015, 124325033, 986041310, 2542280, 2542840, 437403, 439444, SG9B023, SG9B069, LRB00480, LRB480, DRB1310, 20130117, IA1304
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0480 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will B0480 fit my VW Golf?
VW Golf 1.4 Petrol (2007–2009) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does B0480 replace Lucas LRB00480?
Lucas LRB00480 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0480?
The listed details include 12V, 90A output, 6 pulley grooves. Compare the complete specifications on this page with the unit being replaced.
Is B0480 new or remanufactured?
Check the current product condition selection for B0480. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0480?
Compare 12V compatibility, 90A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
