B0628 24V 35A Alternator Replaces Lucas LRB00628
Price range: £147.91 through £236.65
The B0628 24V 35A Alternator is a replacement charging unit from Sahibs Auto Electrics. Use the original unit reference and vehicle details to confirm the application. Identification references include Lucas LRB00628, Delco Remy DRA3599, Prestolite 1268430. Its listed 24V 35A rating provides an electrical matching point for your existing unit. Compare the pulley, connections and mounting arrangement with your existing alternator. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your B0628 replacement alternator online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| AMP | 35 A |
| Volt | 24 V |
| Mounting holes | 2 qty |
| B+ | M5 |
| Insulated Return | No |
| Water cooled | No |
| Vacuum pump | No |
| Start/Stop | No |
| Weight | 6 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYB0628 | Dyno Electrics |
| 1012219 | ERF |
| 1036120 | ERF |
| 1053046 | ERF |
| 1053052 | ERF |
| 1053069 | ERF |
| 1066152 | ERF |
| 1075994 | ERF |
| 1076001 | ERF |
| 111295 | HC-Cargo |
| 111744 | HC-Cargo |
| 111745 | HC-Cargo |
| 1266450 | CAV |
| 1266520 | CAV |
| 1266A770 | Perkins |
| 1268430 | Prestolite |
| 1268470 | CAV |
| 1268510 | CAV |
| 1268520 | CAV |
| 1268580 | Prestolite |
| 1268590 | CAV |
| 1268590C | CAV |
| 1268590M | CAV |
| 1268600M | CAV |
| 1268610 | CAV |
| 1268650 | CAV |
| 1268650M | Prestolite |
| 1268650MC | Prestolite |
| 1268660 | Prestolite |
| 1268669 | CAV |
| 1268690 | Prestolite |
| 1268720 | Prestolite |
| 1268730 | Prestolite |
| 1269730M | CAV |
| 1288590 | Prestolite |
| 1292400 | ERF |
| 2068667R | ERF |
| 21201005 | AES |
| 23511N | WAI |
| 240805 | HC-Cargo |
| 2871682 | Perkins |
| 2871723 | Perkins |
| 2871740 | Perkins |
| 2871A002 | Perkins |
| 2871A003 | Perkins |
| 2871A004 | Perkins |
| 2871A682 | Perkins |
| 3250087 | Cummins |
| 3256759 | Cummins |
| 325675900RX | Cummins |
| 3256759RX | Cummins |
| 3279007 | Cummins |
| 3297833R91 | Seddon Atkinson |
| 3304454R91 | Seddon Atkinson |
| 3309731R91 | Seddon Atkinson |
| 3311950R91 | Seddon Atkinson |
| 3910566 | Cummins |
| 391056600 | Cummins |
| 3964745 | Cummins |
| 3975139 | Cummins |
| 550117 | Cummins |
| 606981 | Dennis |
| 611992 | Dennis |
| 6200596000 | Foden Trucks |
| 66021507 | Prestolite |
| 692960 | Dennis |
| 706002055 | PSH |
| 71413500 | JCB |
| 71413500R | JCB |
| 71427300 | JCB |
| 71427300R | JCB |
| 82RB10346AA | Ford |
| 82RBAA | Ford |
| 854477 | Prestolite |
| 857594Z | Prestolite |
| 857612 | Prestolite |
| 857621 | Prestolite |
| 857621Z | Prestolite |
| 857626 | Prestolite |
| 857630 | Prestolite |
| 857633 | Prestolite |
| 857722Z | Prestolite |
| 858085 | Prestolite |
| 858085Z | Prestolite |
| 858619Z | Prestolite |
| 858693 | Prestolite |
| 858693Z | Prestolite |
| 858919 | Prestolite |
| 858919Z | Prestolite |
| 859327 | Prestolite |
| 859327Z | Prestolite |
| 859385 | Prestolite |
| 859442 | Prestolite |
| 859447 | Prestolite |
| 859544 | Prestolite |
| 859544Z | Prestolite |
| 859605PB | Cummins |
| 859605Z | Prestolite |
| 860052 | Prestolite |
| 880627 | Prestolite |
| 880628Z | Prestolite |
| 880629Z | Prestolite |
| 880648Z | Prestolite |
| 92901946 | Iveco |
| 92901947 | Iveco |
| 92901970 | Iveco |
| A4020606 | Prestolite |
| A504 | Leyland |
| A506 | Leyland |
| A508 | Leyland |
| A516 | Leyland |
| A629 | Leyland |
| AC5RS24 | Prestolite |
| AC5RS24Y2 | CAV |
| AELB633 | DAF |
| ALT17011 | Wood Auto |
| ALT21000 | Wood Auto |
| ALT21016 | Wood Auto |
| ALT32004 | Wood Auto |
| ALT32005 | Wood Auto |
| ALT32009 | Wood Auto |
| ALT32013 | Unipoint |
| ALT41005 | Unipoint |
| CA1193IR | HC-Parts |
| CCA006AX | Cummins |
| CCA00700 | Cummins |
| DRA3599 | Delco Remy |
| F032111295 | HC-Cargo |
| HCA1193IR | HC-Parts |
| LEA1182 | Lucas |
| LRA02506 | Lucas |
| LRA02511 | Lucas |
| LRA2506 | Lucas |
| LRA2511 | Lucas |
| LRB00606 | Lucas |
| LRB00607 | Lucas |
| LRB00612 | Lucas |
| LRB00614 | Lucas |
| LRB00617 | Lucas |
| LRB00618 | Lucas |
| LRB00624 | Lucas |
| LRB00626 | Lucas |
| LRB00627 | Lucas |
| LRB00628 | Lucas |
| LRB00629 | Lucas |
| LRB00648 | Lucas |
| LRB00653 | Lucas |
| LRB00655 | Lucas |
| LRB606 | Lucas |
| LRB607 | Lucas |
| LRB612 | Lucas |
| LRB614 | Lucas |
| LRB617 | Lucas |
| LRB618 | Lucas |
| LRB624 | Lucas |
| LRB626 | Lucas |
| LRB627 | Lucas |
| LRB628 | Lucas |
| LRB629 | Lucas |
| LRB648 | Lucas |
| LRB653 | Lucas |
| LRB655 | Lucas |
| OD167172 | Perkins |
| OD174991 | Perkins |
| OD174992 | Perkins |
| OD174993 | Perkins |
| OD174994 | Perkins |
| OD182651 | Perkins |
| OD18580 | Perkins |
| OD195281 | Perkins |
| OE52770 | Perkins |
| OE52771 | Perkins |
| PRE1268590 | Wood Auto |
| PRE1268650M | Wood Auto |
| PRE1268690 | Wood Auto |
| PRE1268720 | Wood Auto |
| PRE66021507 | Wood Auto |
| RNL66021507 | RNL |
| WOOALT21016 | Wood Auto |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| - | - | - | - | - | - | - |
Description
B0628 Replacement Alternator
For a B0628 alternator enquiry, use Lucas reference LRB00628 alongside the vehicle and original unit details. The listed electrical rating is 24V 35A. An alternator maintains battery charge and supplies electrical power while the engine runs. Confirm the vehicle application with the team before ordering.
Key Features and Benefits
- 24V electrical system: match the vehicle voltage before selecting a unit.
- 35A output: compare the listed rating with the original alternator.
- 2 mounting holes: compare the fixing pattern and unit position.
- M5 B+ terminal: check the connection against the original unit.
Compatible Vehicles and Applications
Quote B0628 and LRB00628 with your vehicle details so the team can check the application. Compare the original part number, engine and physical unit rather than relying on a general model description.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with B0628. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
LRB00628, LEA1182, LRA02506, LRA02511, LRA2506, LRA2511, LRB00606, LRB00607, LRB00612, LRB00614, LRB00617, LRB00618, LRB00624, LRB00626, LRB00627, LRB00629, LRB00648, LRB00653, LRB00655, LRB606, LRB607, LRB612, LRB614, LRB617, LRB618, LRB624, LRB626, LRB627, LRB628, LRB629, LRB648, LRB653, LRB655, DRA3599, 1268430, 1268580, 1268650M, 1268650MC, 1268660, 1268690, 1268720, 1268730, 1288590, 66021507, 854477, 857594Z, 857612, 857621, 857621Z, 857626, 857630, 857633, 857722Z, 858085, 858085Z, 858619Z, 858693, 858693Z, 858919, 858919Z, 859327, 859327Z, 859385, 859442, 859447, 859544, 859544Z, 859605Z, 860052, 880627, 880628Z, 880629Z, 880648Z, A4020606, AC5RS24, 82RB10346AA, 82RBAA, 1266A770, 2871682, 2871723, 2871740, 2871A002, 2871A003, 2871A004, 2871A682, OD167172, OD174991, OD174992, OD174993, OD174994, OD182651, OD18580, OD195281, OE52770, OE52771, AELB633
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Alternator?
Charging warning lights, repeated loss of battery charge, dim or fluctuating lights and inconsistent electrical operation can indicate a charging-system problem. Battery condition, wiring and the drive belt can produce similar symptoms; arrange a diagnostic check before replacing the alternator.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying B0628 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
How can I confirm the vehicle application for B0628?
Quote B0628, Lucas LRB00628, your vehicle registration and the existing unit number for an application check.
Does B0628 replace Lucas LRB00628?
Lucas LRB00628 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for B0628?
The listed details include 24V, 35A output. Compare the complete specifications on this page with the unit being replaced.
Is B0628 new or remanufactured?
Check the current product condition selection for B0628. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering B0628?
Compare 24V compatibility, 35A output, pulley configuration, mounting points and electrical connections with the original alternator.
Does a battery warning light prove the alternator has failed?
No. Battery, belt, wiring and control faults can also affect charging. Use a charging-system test to establish the cause before ordering a replacement.
