S0540 12V 0.8kW Starter Motor Fits Austin Maestro, Austin Montego
Price range: £139.99 through £209.98
The S0540 12V 0.8kW Starter Motor is a replacement starting unit from Sahibs Auto Electrics. Listed applications include selected Austin Maestro, Austin Montego, Rover Maestro, Rover Montego models. Identification references include Lucas LRS00540, Bosch 1211223, Valeo 432656. Its listed 12V 0.8kW rating provides an electrical matching point for your existing unit. Check the 9-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0540 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 0.8 kW |
| Volt | 12 V |
| Plug | M8 |
| Teeth | 9 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 4.4 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0540 | Dyno Electrics |
| 402440101 | Euro Car Part |
| 1211223 | Bosch |
| 1211224 | Bosch |
| 1211255 | Bosch |
| 1211256 | Bosch |
| 055911023B | Volkswagen AG |
| 055911023BX | Volkswagen AG |
| 986010370 | Bosch Exchange |
| 986010377 | Bosch Exchange |
| 986010378 | Bosch Exchange |
| 986012337 | Bosch Exchange |
| 986053151 | Bosch Exchange |
| 986053171 | Bosch Exchange |
| 110410 | HC-Cargo |
| 11130334 | Mahle |
| 175911023B | Volkswagen AG |
| 25349 | Lucas |
| 25349A | Lucas |
| 25350 | Lucas |
| 25350A | Lucas |
| 25351 | Lucas |
| 26604 | Lucas |
| 26604E | Lucas |
| 26604F | Lucas |
| 26604G | Lucas |
| 26604H | Lucas |
| 26604J | Lucas |
| 26606 | Lucas |
| 26647 | Lucas |
| 26647A | Lucas |
| 26647D | Lucas |
| 27029 | Lucas |
| 300003092 | PSH |
| 432656 | Valeo |
| 433266 | Valeo |
| 63227029 | Magneti Marelli |
| 66925343 | Prestolite |
| 9000042031 | Bosch |
| 9000692015 | Bosch |
| 9004475044 | Bosch |
| 9004475315 | Bosch |
| 9004475316 | Bosch |
| 9004475317 | Bosch |
| 91156891 | Wilson |
| 943251624 | Magneti Marelli |
| ADU9356 | Land Rover |
| ADU9357 | Land Rover |
| AUU1233 | Land Rover |
| AUU1237 | Land Rover |
| AZF3527 | Mahle |
| BBW911023B | Volkswagen AG |
| BX5315 | Bosch (USA) |
| BX5317 | Bosch (USA) |
| CS116 | HC-Parts |
| D9E111 | Valeo |
| DRS0370 | Delco Remy |
| DRS3633 | Delco Remy |
| F00E100305 | Bosch |
| F00E100311 | Bosch |
| HCS116 | HC-Parts |
| IS0334 | Mahle |
| LRS00268 | Lucas |
| LRS00401 | Lucas |
| LRS00402 | Lucas |
| LRS00538 | Lucas |
| LRS00540 | Lucas |
| LRS268 | Lucas |
| LRS401 | Lucas |
| LRS402 | Lucas |
| LRS538 | Lucas |
| LRS540 | Lucas |
| MSR112 | Magneti Marelli |
| MSR463 | Magneti Marelli |
| NSB106 | Lucas |
| NSB110 | Lucas |
| PBNS0401 | Prestolite |
| PBNS0402 | Prestolite |
| PBNS0538 | Prestolite |
| PBNS0540 | Prestolite |
| S23659 | Hitachi |
| S23660 | Hitachi |
| S23865 | Hitachi |
| SR69X | Bosch (USA) |
| SR85X | Bosch (USA) |
| STR56015 | Wood Auto |
| WOOSTR56015 | Wood Auto |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| AUSTIN | Maestro | 1.3 (1275ccm) Petrol | 12H | Fastback | XC | 1983 - 1990 | |
| AUSTIN | Montego | 1.3 (1275ccm) Petrol | 12HL | XE | 1984 - 1988 | ||
| ROVER | Maestro | 1.3 (1275ccm) Petrol | 12HE | TC | 1990 - 1994 | ||
| ROVER | Montego | 1.3 (1275ccm) Petrol | 12HL | XE | 1984 - 1988 | ||
| VW | Caddy Pick-Up | 1.6 (1595ccm) Petrol | EW/HN | I | 147/148/1AE | 1983 - 1986 | |
| VW | Golf | 1.5 (1457ccm) Petrol | JB | I | 171/172/173/174 | 1977 - 1983 | |
| VW | Golf | 1.5 (1457ccm) Petrol | JB | I | 154/155 | 1979 - 1983 | |
| VW | Golf | 1.6 (1588ccm) Petrol | EM/FN/FP | I | 171/172/173/174 | 1975 - 1984 | |
| VW | Jetta | 1.5 (1457ccm) Petrol | JB | I | 161/163/164 | 1978 - 1984 | |
| VW | Jetta | 1.6 (1588ccm) Petrol | FR | I | 161/163/164 | 1978 - 1984 | |
| VW | Scirocco | 1.5 (1457ccm) Petrol | JB | I | 531/532 | 1979 - 1980 | |
| VW | Scirocco | 1.5 (1457ccm) Petrol | JB | II | 533/534 | 1981 - 1983 | |
| VW | Scirocco | 1.6 (1588ccm) Petrol | EM/FN/FP | I | 531/532 | 1975 - 1980 | |
| VW | Scirocco | 1.6 (1588ccm) Petrol | FR | I | 531 | 1975 - 1981 | |
| VW | Scirocco | 1.6 (1588ccm) Petrol | EG | I | 531 | 1976 - 1980 |
Description
S0540 Replacement Starter Motor
The S0540 starter motor is a replacement unit identified by Lucas reference LRS00540. The listed electrical rating is 12V 0.8kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Austin Maestro 1.3 Petrol variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 0.8kW power: compare the listed rating with the original starter motor.
- 9-tooth pinion: compare gear engagement and pinion position.
- Counter Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Austin Maestro 1.3 Petrol – selected applications 1983–1990 (engine code 12H).
- Austin Montego 1.3 Petrol – selected applications 1984–1988 (engine code 12HL).
- Rover Maestro 1.3 Petrol – selected applications 1990–1994 (engine code 12HE).
- Rover Montego 1.3 Petrol – selected applications 1984–1988 (engine code 12HL).
- VW Caddy Pick-Up 1.6 Petrol – selected applications 1983–1986 (engine code EW/HN).
- VW Golf 1.5 Petrol – selected applications 1977–1983 (engine code JB).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0540. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1211223, 1211224, 1211255, 1211256, 986010370, 986010377, 986010378, 986012337, 986053151, 986053171, 9000042031, 9000692015, 9004475044, 9004475315, 9004475316, 9004475317, F00E100305, F00E100311, 432656, 433266, D9E111, LRS00540, 25349, 25349A, 25350, 25350A, 25351, 26604, 26604E, 26604F, 26604G, 26604H, 26604J, 26606, 26647, 26647A, 26647D, 27029, LRS00268, LRS00401, LRS00402, LRS00538, LRS268, LRS401, LRS402, LRS538, LRS540, NSB106, NSB110, S23659, S23660, S23865, DRS0370, DRS3633, 66925343, PBNS0401, PBNS0402, PBNS0538, PBNS0540, 11130334, AZF3527, IS0334
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0540 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0540 fit my Austin Maestro?
Austin Maestro 1.3 Petrol (1983–1990) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0540 replace Lucas LRS00540?
Lucas LRS00540 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0540?
The listed details include 12V, 0.8kW power, 9 pinion teeth, counter clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0540 new or remanufactured?
Check the current product condition selection for S0540. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0540?
Compare 12V compatibility, 0.8kW power, 9 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
