S0552 12V 2.8kW Starter Motor Fits Case 1394, Case 1494, Case 1594
Price range: £313.78 through £381.79
Compare the S0552 12V 2.8kW starter motor from Sahibs Auto Electrics with the unit currently fitted. Listed applications include selected Case 1394, Case 1494, Case 1594, Case 1690 models. Identification references include Lucas LRS00552, Bosch 1362067, Hitachi S13-61. Its listed 12V 2.8kW rating provides an electrical matching point for your existing unit. Check the 10-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S0552 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2.8 kW |
| Volt | 12 V |
| Plug | M8 |
| Rotation | Clockwise |
| Teeth | 10 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 13 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS0552 | Dyno Electrics |
| UD11898(LETRIKA)S | AS-PL |
| 1362067 | BOSCH |
| 986022750 | BOSCH |
| 110462 | CARGO |
| 116137 | CARGO |
| F032110462 | CARGO |
| F032116137 | CARGO |
| K262761 | CASE |
| K308650 | CASE |
| 6005706633 | CLAAS |
| 1516712R | DAF |
| 702000150 | FORD |
| 703F-11000-AA | FORD |
| 71YB-11000-AA | FORD |
| 81AB10300UB | FORD |
| 83949348 | FORD |
| 83981923 | FORD |
| C6NF11000A | FORD |
| C7NN11000A | FORD |
| C7NN11000B | FORD |
| D0NN11000A | FORD |
| D0NN11000B | FORD |
| D1NN-11000-A | FORD |
| D2NN-11000-B | FORD |
| D4NN-11000-B | FORD |
| D7NN-11000-B | FORD |
| D8NN-11000-BA | FORD |
| D8NN-11000-CA | FORD |
| D8NN-11000-CB | FORD |
| D8NN-11000-CE | FORD |
| D8NN11000AA | FORD |
| D9NN-11000-AA | FORD |
| F0NN-11000-CA | FORD |
| FONN-11000-CA | FORD |
| GG5 | FORD |
| 8EA726026-001 | HELLA |
| 8EA737236-001 | HELLA |
| CS987 | HELLA |
| S13-61 | HITACHI |
| S13-61A | HITACHI |
| 11.130.579 | ISKRA / LETRIKA |
| AZJ3182 | ISKRA / LETRIKA |
| AZJ3198 | ISKRA / LETRIKA |
| IS0579 | ISKRA / LETRIKA |
| 63227569 | MAGNETI MARELLI |
| MSN202 | MAGNETI MARELLI |
| 9142765 | MAGNETON |
| 72735974 | MAHLE |
| MS346 | MAHLE |
| 87318759 | NEW HOLLAND |
| 205000212 | PRESTOLITE |
| 20500212 | PRESTOLITE |
| 35262480 | PRESTOLITE |
| ANM15417 | ANDEL |
| 8048 | CEVAM |
| 33379 | EAI |
| 33381 | EAI |
| STR7946 | ELECTROLOG |
| 25-0064 | ELSTOCK |
| 220737 | ERA |
| SG0148 | GHIBAUDI |
| GSLRS212L-R | GPARTS |
| LES0017-N | GPARTS |
| SSLRS212L-R | GPARTS |
| CS200 | HC PARTS |
| STB1987 | KRAUF |
| STL0200 | KRAUF |
| 10200L | KUHNER |
| 16608 | LESTER |
| 17294 | LESTER |
| 17646 | LESTER |
| 17655 | LESTER |
| 32766 | LESTER |
| 32767 | LESTER |
| 330259 | LOGISTIK |
| 330352 | LOGISTIK |
| 23669 | LUCAS |
| 26211 | LUCAS |
| 26211A | LUCAS |
| 26211D | LUCAS |
| 26211E | LUCAS |
| 26211H | LUCAS |
| 26211L | LUCAS |
| 26211N | LUCAS |
| 26211Q | LUCAS |
| 26211T | LUCAS |
| 26211U | LUCAS |
| 26227 | LUCAS |
| 26291 | LUCAS |
| 26338 | LUCAS |
| 26338A | LUCAS |
| 26338B | LUCAS |
| 26338D | LUCAS |
| 26338F | LUCAS |
| 26339 | LUCAS |
| 26339A | LUCAS |
| 26339B | LUCAS |
| 26339D | LUCAS |
| 26339E | LUCAS |
| 26339F | LUCAS |
| 26339H | LUCAS |
| 26379 | LUCAS |
| 26395 | LUCAS |
| 26395A | LUCAS |
| 26395B | LUCAS |
| 26395D | LUCAS |
| 26395E | LUCAS |
| 26395F | LUCAS |
| 26925 | LUCAS |
| 27500 | LUCAS |
| 27500B | LUCAS |
| 27500D | LUCAS |
| 27500E | LUCAS |
| 27500L | LUCAS |
| 27528 | LUCAS |
| 27569 | LUCAS |
| 27569A | LUCAS |
| 27569B | LUCAS |
| 27569D | LUCAS |
| 27569E | LUCAS |
| 27614 | LUCAS |
| LRS00115 | LUCAS |
| LRS00129 | LUCAS |
| LRS00134 | LUCAS |
| LRS00212 | LUCAS |
| LRS00552 | LUCAS |
| LRS115 | LUCAS |
| LRS129 | LUCAS |
| LRS134 | LUCAS |
| LRS212 | LUCAS |
| LRS552 | LUCAS |
| S5012 | LUCAS |
| 5025711 | MEAT & DORIA |
| 88212669 | POWERMAX |
| 590.001.103.016 | PSH |
| 590.001.103.100 | PSH |
| 590.001.103.108 | PSH |
| 590.001.103.110 | PSH |
| 590.001.103.310 | PSH |
| 590.001.103.321 | PSH |
| 590.001.103.325 | PSH |
| 311562 | RHIAG |
| 182-30396 | ROBERT'S |
| STM2003 | ROLLCO |
| S12LU0154 | SIDAT |
| S12LU0154A2 | SIDAT |
| STX200568 | STARDAX |
| STX200677 | STARDAX |
| 16608N-M127 | WAI / TRANSPO |
| 16608N-M50 | WAI / TRANSPO |
| 17646N | WAI / TRANSPO |
| 91-17-8862 | WILSON |
| 91-17-8882 | WILSON |
| STR25012 | WOODAUTO |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| CASE | 1394 | 3594ccm Diesel | Case 4T | 1984 - 1988 | |||
| CASE | 1494 | 3594ccm Diesel | Case 4T | 1984 - 1988 | |||
| CASE | 1594 | 0ccm Diesel | 33002 | 1984 - 1988 | |||
| CASE | 1690 | 0ccm Diesel | 330001 | 1980 - 1983 | |||
| CASE | 1694 | 3301ccm Diesel | 1984 - 1988 |
Description
S0552 Replacement Starter Motor
The S0552 starter motor is a replacement unit identified by Lucas reference LRS00552. The listed electrical rating is 12V 2.8kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Case 1394 3594ccm Diesel variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.8kW power: compare the listed rating with the original starter motor.
- 10-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Case 1394 3594ccm Diesel – selected applications 1984–1988 (engine code Case 4T).
- Case 1494 3594ccm Diesel – selected applications 1984–1988 (engine code Case 4T).
- Case 1594 – selected applications 1984–1988 (engine code 33002).
- Case 1690 – selected applications 1980–1983 (engine code 330001).
- Case 1694 3301ccm Diesel – selected applications 1984–1988.
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S0552. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
1362067, 986022750, LRS00552, 23669, 26211, 26211A, 26211D, 26211E, 26211H, 26211L, 26211N, 26211Q, 26211T, 26211U, 26227, 26291, 26338, 26338A, 26338B, 26338D, 26338F, 26339, 26339A, 26339B, 26339D, 26339E, 26339F, 26339H, 26379, 26395, 26395A, 26395B, 26395D, 26395E, 26395F, 26925, 27500, 27500B, 27500D, 27500E, 27500L, 27528, 27569, 27569A, 27569B, 27569D, 27569E, 27614, LRS00115, LRS00129, LRS00134, LRS00212, LRS115, LRS129, LRS134, LRS212, LRS552, S5012, S13-61, S13-61A, 205000212, 20500212, 35262480, 72735974, MS346, 11.130.579, AZJ3182, AZJ3198, IS0579, 702000150, 703F-11000-AA, 71YB-11000-AA, 81AB10300UB, 83949348, 83981923, C6NF11000A, C7NN11000A, C7NN11000B, D0NN11000A, D0NN11000B, D1NN-11000-A, D2NN-11000-B, D4NN-11000-B, D7NN-11000-B, D8NN-11000-BA, D8NN-11000-CA, D8NN-11000-CB, D8NN-11000-CE, D8NN11000AA, D9NN-11000-AA, F0NN-11000-CA, FONN-11000-CA, GG5, 1516712R
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S0552 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S0552 fit my Case 1394?
Case 1394 3594ccm Diesel (1984–1988) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S0552 replace Lucas LRS00552?
Lucas LRS00552 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S0552?
The listed details include 12V, 2.8kW power, 10 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S0552 new or remanufactured?
Check the current product condition selection for S0552. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S0552?
Compare 12V compatibility, 2.8kW power, 10 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
