S1142 12V 2.0kW Starter Motor Fits Gehl MG747B Road Scraper
Price range: £144.99 through £217.48
The S1142 12V 2.0kW Starter Motor is a replacement starting unit from Sahibs Auto Electrics. Listed applications include selected Gehl MG747B Road Scraper, Gehl Mini-Loader, New Holland L255 models. Identification references include Lucas LRS01142, Denso 028000-7000, Hitachi 112473. Its listed 12V 2.0kW rating provides an electrical matching point for your existing unit. Check the 9-tooth pinion, connections and mounting arrangement. Check the current condition options and availability before purchase. Match the exact engine and production details before ordering. Buy your S1142 replacement starter motor online from Sahibs Auto Electrics for UK delivery or Click & Collect.
Product Specification
| Description | Value |
|---|---|
| KW | 2 kW |
| Volt | 12 V |
| Plug | M8 |
| Rotation | Clockwise |
| Teeth | 9 qty |
| Oil Sealed | No |
| Insulated Return | No |
| Waterproof | No |
| Wet Clutch | No |
| Weight | 5.2 Kg |
Cross Reference
| Reference Number | Brand |
|---|---|
| DYS1142 | Dyno Electrics |
| UD810320(DENSO)S | AS-PL |
| 65-26201-7059 | CHEVROLET |
| 028000-7000 | DENSO |
| 028000-7001 | DENSO |
| 028000-7002 | DENSO |
| 028000-7003 | DENSO |
| 028000-7004 | DENSO |
| 128000-0020 | DENSO |
| 128000-0960 | DENSO |
| 128000-3100 | DENSO |
| 128000-3101 | DENSO |
| 228000-9690 | DENSO |
| 228080-9690 | DENSO |
| DSN2128 | DENSO |
| 112473 | HITACHI |
| 581100-0860 | ISUZU |
| 5811001660 | ISUZU |
| 5811001661 | ISUZU |
| 5811001662 | ISUZU |
| 5811001663 | ISUZU |
| 5811001664 | ISUZU |
| 8941233870 | ISUZU |
| 8973168950 | ISUZU |
| 600-813-1750 | KOMATSU |
| 8023898 | CLARK |
| 25-1106 | ELSTOCK |
| GSSN2128-N | GPARTS |
| 20552 | KUHNER |
| 20552D | KUHNER |
| 20552V | KUHNER |
| LRS01142 | LUCAS |
| LRS1142 | LUCAS |
| 130.598.092.260 | PSH |
| STX200239 | STARDAX |
| DENDSN2128 | WOODAUTO |
Alternative Parts
| Alternative Part | Current Description | Alternative Description | Direct Alternative |
|---|---|---|---|
| S1163 | 2.0KW Connection 50 screw terminal | 2.2KW Connection 50 spade terminal | No |
| S0615 | Connection 50 screw terminal | Connection 50 spade terminal | No |
Vehicle Applications
| Brand | Model | Engine | Engine Code | Series | Model Type | Type | Year |
|---|---|---|---|---|---|---|---|
| GEHL | MG747B Road Scraper | 0ccm Diesel | Isuzu QD30 | 1991 - 1994 | |||
| GEHL | Mini-Loader | 0ccm Diesel | 3D95S | ||||
| NEW HOLLAND | L255 | 0ccm Diesel | Kubota |
Description
S1142 Replacement Starter Motor
For a S1142 starter motor enquiry, use Lucas reference LRS01142 alongside the vehicle and original unit details. The listed electrical rating is 12V 2.0kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Gehl MG747B Road Scraper variants.
Key Features and Benefits
- 12V electrical system: match the vehicle voltage before selecting a unit.
- 2.0kW power: compare the listed rating with the original starter motor.
- 9-tooth pinion: compare gear engagement and pinion position.
- Clockwise rotation: check the specified direction before fitting.
- M8 connector / terminal: check the connection against the original unit.
Compatible Vehicles and Applications
- Gehl MG747B Road Scraper – selected applications 1991–1994 (engine code Isuzu QD30).
- Gehl Mini-Loader (engine code 3D95S).
- New Holland L255 (engine code Kubota).
These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.
OE Numbers and Cross-Reference Information
The following cross-reference numbers are associated with S1142. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.
028000-7000, 028000-7001, 028000-7002, 028000-7003, 028000-7004, 128000-0020, 128000-0960, 128000-3100, 128000-3101, 228000-9690, 228080-9690, DSN2128, LRS01142, LRS1142, 112473
The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.
When Should You Replace Your Starter Motor?
Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.
Why Buy from Sahibs Auto Electrics?
Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S1142 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.
Frequently Asked Questions
Will S1142 fit my Gehl MG747B Road Scraper?
Gehl MG747B Road Scraper (1991–1994) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.
Does S1142 replace Lucas LRS01142?
Lucas LRS01142 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.
What specifications are listed for S1142?
The listed details include 12V, 2.0kW power, 9 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.
Is S1142 new or remanufactured?
Check the current product condition selection for S1142. Confirm the supplier and availability of the option you want before completing the order.
What should I compare before ordering S1142?
Compare 12V compatibility, 2.0kW power, 9 pinion teeth, rotation, mounting and electrical connections with the original starter.
Does clicking prove the starter motor has failed?
No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
