S1150 12V 0.9kW Starter Motor Fits Kia Carens, Kia Clarus, Kia Credos

Description

S1150 Replacement Starter Motor

Start your S1150 starter motor comparison with the linked Lucas reference LRS01150 and the specifications shown on this page. The listed electrical rating is 12V 0.9kW. A starter motor turns the engine during starting; the electrical rating and mechanical engagement must suit the application. Applications include selected Kia Carens 1.8 Petrol variants.

Key Features and Benefits

• 12V electrical system: match the vehicle voltage before selecting a unit.
• 0.9kW power: compare the listed rating with the original starter motor.
• 8-tooth pinion: compare gear engagement and pinion position.
• Clockwise rotation: check the specified direction before fitting.
• M8 connector / terminal: check the connection against the original unit.

Compatible Vehicles and Applications

• Kia Carens 1.8 Petrol – selected applications 2000–2002 (engine code T8D).
• Kia Clarus 1.8 Petrol – selected applications 1996–2001 (engine code T8).
• Kia Credos 1.8 Petrol – selected applications 1996–1998 (engine code T8).
• Kia Mentor 1.5 Petrol – selected applications 1996–1998 (engine code B5).
• Kia Retona 2.0 Petrol – selected applications 1999–2001 (engine code FE(16V)).
• Kia Sephia 1.5 Petrol – selected applications 1996–1997 (engine code B5).

These are selected applications, not the complete fitment list. Check the detailed vehicle compatibility table, engine code and production year, then compare the original unit before ordering.

OE Numbers and Cross-Reference Information

The following cross-reference numbers are associated with S1150. Compare them with the original unit and technical specifications; a number match alone does not establish vehicle compatibility.

986014991, 455606, M000A0240Z, MC109028, MC109036, VS305, LRS01150, LRS00557, LRS00627, LRS00688, LRS01723, LRS02055, LRS1150, LRS1723, LRS2055, LRS557, LRS627, LRS688, M003T21874, M003T24481, M003T24482, M003T24482A, M003T24482H, M003T24482HC, M003T24482J, M003T24482K, M003T24482L, M003T24483, M003T24485, M003T24486, M003T24486A, M003T24486H, M003T24487, M003T24488, M003T30281, M003T30282, M003T30285, M003T30286, M003T30881, M003T30882, M003T33281, M003T33282, M003T33283, M003T33581, M003T33582, M003T33582A, M003T33583, M003T33585, M003T33586, M003T33586A, M003T33586D, M003T33587, M003T33588, M003T34082, M003T38881, M003T38881A, M003T38881B, M003T38881C, M003T38882, M003T38882A, M003T38882B, M003T38882C, M003T38883, M003T38884, M003T38885, M003T39385, M003T39481, M003T39981, M003T43581, M003T49381, M003T49481, M003T49581, M003T49585, M003T49781, M003Y24482, M3T21874, M3T24481, M3T24482, M3T24482A, M3T24482H, M3T24482HC, M3T24482J, M3T24482K, M3T24482L, M3T24483, M3T24485, M3T24486, M3T24486A, M3T24486H, M3T24487, M3T24488, M3T30281, M3T30282, M3T30285, M3T30286, M3T30881, M3T30882, M3T33281, M3T33282, M3T33283, M3T33581, M3T33582, M3T33582A, M3T33583, M3T33585, M3T33586, M3T33586A, M3T33586D, M3T33587, M3T33588, M3T34082, M3T38862, M3T38881, M3T38881A, M3T38881B, M3T38881C, M3T38882, M3T38882A, M3T38882B, M3T38882C, M3T38883, M3T38884, M3T38885, M3T39385, M3T39481, M3T39981, M3T43581, M3T49381, M3T49481, M3T49581, M3T49585, M3T49781, M3Y24482, MC109015, 111089, 112816, DRS3501, DRS3511, DRS4991, 66925114, 66925181, B50518400

The full manufacturer cross-reference and OE listings are available elsewhere on this page. Confirm whether a number is an OE or aftermarket reference when comparing the original unit.

When Should You Replace Your Starter Motor?

Failure to crank, clicking during a start request or intermittent cranking can indicate a starting-system problem. A weak battery, poor connections or control-circuit faults can produce similar symptoms; test the system before replacing the starter motor.

Why Buy from Sahibs Auto Electrics?

Sahibs Auto Electrics is a UK automotive electrical parts specialist supplying alternators and starter motors. Ask for help identifying S1150 using the existing part number and vehicle details. Check the current condition options and availability before purchase. Buy online for UK delivery or Click & Collect, checking the current order arrangements.

Frequently Asked Questions

Will S1150 fit my Kia Carens?

Kia Carens 1.8 Petrol (2000–2002) is a listed application. Confirm the engine code and original unit configuration in the detailed fitment table.

Does S1150 replace Lucas LRS01150?

Lucas LRS01150 is a listed identification reference. Compare it with the original unit and specifications; a cross-reference does not guarantee compatibility by itself.

What specifications are listed for S1150?

The listed details include 12V, 0.9kW power, 8 pinion teeth, clockwise rotation. Compare the complete specifications on this page with the unit being replaced.

Is S1150 new or remanufactured?

Check the current product condition selection for S1150. Confirm the supplier and availability of the option you want before completing the order.

What should I compare before ordering S1150?

Compare 12V compatibility, 0.9kW power, 8 pinion teeth, rotation, mounting and electrical connections with the original starter.

Does clicking prove the starter motor has failed?

No. Battery voltage, wiring and control-circuit faults can also cause clicking or no cranking. Have the starting system tested before choosing a replacement.
